General Installation Manual
Photovoltaic Module HIT
VBHNxxxSJ25 series
VBHNxxxSJ47 series
Model No.
VBHN240SJ25, VBHN245SJ25, VBHN250SJ25
VBHN320SJ47, VBHN325SJ47, VBHN330SJ47
VBHNxxxSJ25 series
Thank you for choosing Panasonic photovoltaic module HIT
Please read this manual completely before you install or use of
TM
HIT
. With proper operation and maintenance, HIT
provide you with clean, renewable solar electricity for many
years. This manual contains important installation, mainte-
nance and safety information. The word "module" as used in
this manual refers to one or more PV modules. Retain this
manual for future reference.
TM
VBHNxxxSJ47 series
TM
TM
will
CONTENTS
･GENERAL INFORMATION
･SPECIAL CONDITIONS
.
"HIT" is a trademark of the Panasonic Group.
Other product and service names listed in this
manual are trademarks or registered trademarks
of respective companies.
2
3
6
7
8
10
11
12

Advertisement

Table of Contents
loading

Related Manuals for Panasonic Photovoltaic Module HIT VBHN SJ25 Series

Summary of Contents for Panasonic Photovoltaic Module HIT VBHN SJ25 Series

  • Page 1: Table Of Contents

    ･DISPOSAL OF OLD EQUIPMENT DISCLAIMER OF LIABILITY CUSTOMER SERVICES Thank you for choosing Panasonic photovoltaic module HIT “HIT” is a trademark of the Panasonic Group. Please read this manual completely before you install or use of Other product and service names listed in this .

  • Page 2: Safety Precautions

     vices such as ground fault, fuses, Do not puncture or damage the installed by Panasonic. There are no and disconnects may be required. back sheet of a module. Do not use user serviceable parts within the the PV module and make a replace- ...

  • Page 3: Module Specifications

    1000W/m , 25±2℃ cell tempera- ductor capacities, fuse sizes, and MODULE SPECIFICATIONS ture, AM1.5 and solar spectral irra- size of controls connected to the  Module specifications are shown in diance according to IEC 60904-3. module output. Table 1-1, 1-2 and Figure 1-1, 1-1-a, Under normal conditions, a module The current output for the modules 1-1-b, 1-2.
  • Page 4 Dimension in mm Front side Side Back side * The positions of the holes are all symmetrical against the center of the module. Section A-A’ Section B-B’ Note) A module is installed using 4 points, symmetrical Enlarged view mounting within setting range (shaded). Figure 1-1.
  • Page 5 Table 1-2. Model Specifications Model VBHN320SJ47 VBHN325SJ47 VBHN330SJ47 Maximum Power (Pmax) +10/-0 % Open Circuit Voltage (Voc) ±10 % 69.4 69.6 69.7 Short Circuit Voltage (Isc) ≧90 % 5.98 6.03 6.07 Maximum Power Voltage (Vpm) 57.3 57.6 58.0 Maximum Power Current (Ipm) 5.59 5.65 5.70...

  • Page 6: Standards

     voltage, so that you do not need STANDARDS Modules equipped with one junc- any other additional bypass diodes. tion box contain terminals for both VBHNxxxSJ series comply with the re- positive and negative polarity, and  Specifications of bypass diode for quirements IEC61215, IEC61730-1,...

  • Page 7: Installation

    GENERAL Please read this guide completely before installation or use of the modules. OPERATING CONDITIONS Panasonic recommends that modules be operated within the following Operat- ing Conditions. An installation location with conditions beyond the Operating Conditions or with other Special Condi- tions (see below) should be avoided.

  • Page 8: Module Installation

      Clearance 100mm between the roof Please contact your Panasonic Au- steeper than the water gradient. surface and module frame is re- thorized Representative with ques-  quired to allow cooling air to circu-...
  • Page 9 Installation (reference) 38mm 11mm Solar Module Metal clamp B 38mm (2 places) 35mm Metal clamp A (2 places) Mounting Structure Rail Solar Module M8 Bolt Spring washer Flat washer Flat washer Module Spring washer Mounting Structure Rail M8 Nut Figure 5-2. Module Installation (VBHNxxxSJ47)

  • Page 10: Wiring

    Star washer (stainless steel) Modules are equipped with SMK Round crimping terminal connectors (P51-5H/R51-5) as a ter-  Ground wire (5.5mm , green) Please contact your Panasonic Au- Ground hole minal enclosure. Use these SMK thorized Representative with ques- connectors electrical connec-...

  • Page 11: Maintenance

    The return of any modules will not be  In order to maintain the optimum which forms a protective layer on accepted by Panasonic unless prior the surface of the glass to clean output of the module, quality and written authorization has been given any part of the module.

  • Page 12: Customer Services

    Tel: +84-8-3813-4591 Fax: +84-8-3813-4595 © SANYO Electric Co., Ltd. 2019 Panasonic Manufacturing Philippines Corporation SANYO is part of the Panasonic Group and is in charge of the manufacturing process for HIT Tel: +63-2-886-6291 Fax: +63-2-886-6295 IM001-0419-3 Panasonic Life Solutions Sales (Thailand) Co., Ltd.
