USER MANUAL ISIS ICE Industrial Compact Enclosure (ICE) Issue A – December 2009 – ETH_ISIS_ICE_USM DIGITAL TECHNOLOGIES FOR A BETTER WORLD www.eurotech.com...
Page 2
ISIS ICE - user manual WARRANTY For Warranty terms and conditions users should contact their local Eurotech Sales Office. TRADEMARKS All trademarks both marked and not marked appearing in this document are the property of their respective owners. REVISION HISTORY Issue no.
Eurotech reserves the right to revise this document and to change its contents at any time without obligation to notify any person of such revision or changes.
To avoid damage caused by ESD (Electro Static Discharge), always use appropriate antistatic precautions when handing any electronic equipment. Life support policy Eurotech products are not authorized for use as critical components in life support devices or systems without the express written approval of Eurotech. CE notice...
Device labelling The ISIS ICE serial label is affixed to the end panel of the enclosure this contains the Eurotech part number which in turn contains information on the version and issue of this product the label also contains a serial number which is unique to each individual ISIS ICE.
For all detailed information on the setting up and use of the ISIS please refer to the ISIS Single Board Computer user manual available on the Eurotech website: www.eurotech.com. The ISIS ICE is available fitted with an optional hard disc drive. This option is also available as an after market accessory available from Eurotech.
Page 8
ISIS ICE - user manual Interface PCB All variants of the ISIS ICE contain the main ISIS ICE interface PCB. The ISIS plugs directly into the ISIS ICE interface PCB which acts as the main PC interface to the PC/104 stack. Any expansion boards that are required in the system plug into the PC/104 stack connectors.
Wi-Fi and GPRS are optional. The PC section is common to all three variants. The rear panel of the ISIS ICE variants differs due to the amount of I/O breakout that is available with each. All I/O positions are normally fitted with blanking covers, as in the High-Low variant shown on the next page.
Page 10
ISIS ICE - user manual ISIS ICE High-Low variant Front view Rear view ISIS ICE Low-Low variant Front view Rear view I/O is not available on this variant. ETH_ISIS_ICE_USM...
ISIS ICE power supply The ISIS ICE runs from a DC power-supply in the range 9-36V DC, taking a maximum of 5.5A at the lower DC voltage. The unit is over voltage protected and will shut down if the protection current is exceeded.
ISIS ICE - user manual Connectors RS232 connectors COM1 and COM2 Signal name Signal name Data Carrier Receive Data Detect (DCD) (RX) Transmit Data Data Terminal (TX) Ready (DTR) Ground Data Set ready (DSR) Request To Clear To Send Send (RTS)
Page 13
Connectors LAN (Ethernet) RJ-45 10/100Mb/s. Signal name No Connect No Connect No Connect No Connect USB connectors Two USB type A dual stacked connectors. Signal name Signal name VBUS1 VBUS2...
To add the optional Wi-Fi, GPRS and PC/104 I/O modules, access to the inside of the enclosure is required. The following describes how to dismantle the ISIS ICE in order to gain access to the connection points for these options.
Page 15
6. Remove the ISIS board assembly: The assembly is still attached to the front panel and should not be dismantled further. Access to all serviceable parts is now available. It should not be necessary to further dismantle the ISIS ICE.
ISIS ICE - user manual Adding the optional hard disc drive Observe antistatic precautions when dismantling the ISIS ICE and handling the Hard Disc Drive. To add the optional hard disk drive, follow these steps: 1. Remove the bottom extrusion and rear panel as described in steps 1-4 of...
Page 17
Adding the optional hard disc drive 4. Slide the hard disk drive assembly onto the base: The hard disk drive assembly position can be adjusted to suit alignment. 5. Fit the IDE cable pin to pin, so that when the enclosures are joined the cable is not twisted: 6.
This section provides dimensional drawings with mounting detail for all three ISIS ICE variants. The ISIS ICE is fitted with four M4 threaded nuts. These nuts slide into the grooves in the underside of the enclosures. The measurement Mounting Centres shown below (105mm) is the distance between the centres of the M4 mounting nuts.
Page 19
ISIS ICE dimensional drawings ISIS ICE High-Low variant Fitted with 1 off low profile extrusion and 1off high profile extrusion Mounting Centres...
Page 20
ISIS ICE - user manual ISIS ICE Low-Low variant Fitted with 2 off low profile extrusions Mounting Centres ETH_ISIS_ICE_USM...
4KV on contact and 8KV across an air gap The ISIS ICE is designed to carry Radio transmitting equipment such as the Wi-Fi and GPRS and has been tested to meet the R&TTE requirements for equipment fitted with intentional radiators.
