S é c u r i t é d e s p i s c i n e s e t b a s s i n s
DIRECTIONS FOR USE AND INSTALLATION
IMMERSION DETECTORS FOR SWIMMING POOLS
READ CAREFULLY AND KEEP THIS INFORMATION FOR FUTURE USE
We thank you to have acquired an immersion detector for swimming pool from Aquasensor range.
Read carefully and entirely the following directions and keep it for future use.
This immersion detector for swimming-pools comply with the French official standard NF P 90-307
• This alarm system does not substitute for individual responsibility. It does not aim at substituting for
the parents or responsible adult's vigilance, which remains the main factor for children under five
protection.
• This alarm is a protection device which signals danger or risk of danger. A fast intervention in less
than 3 minutes of a responsible adult is obligatory when the alarm signal sounds.
In any way, your retailer or the alarm system manufacturer shall not be held responsible for the fall or
the drowning for any person or animal. In no case, the installation of your alarm system shall decrease
your vigilance or replace an active monitoring of the swimming-pool and its accesses.
1 Packaging check list
In spite of the particular care taken to the quality of our products and to their packaging, we invite you to check
the contents of the kit.
Central unit
2 magnetic keys (To get some other magnets, please ask your retailer)
1 alkaline battery 9V (Sensor Premium) or 1 lithium battery (Sensor Solar and Sensor Elite)
1 fixing kit (screws and bolts)
1 test sheet
Terms of the guarantee at the end of this document
SensorDomo (standard remote siren delivered with SensorSolar and SensorElite)
Necessary tools for installation:
•
A screwdriver
•
A drill
•
A Ø8 mm drill bit
•
A hacksaw
A water jerry can (6 to 8 litres) which will be used as mannequin for the tests and later controls
•
contact@comodo.fr
SENSOR PREMIUM / SOLAR / ELITE
WARNING
Installation and using guide – Page 1/15
www.alarme-piscine.com
Advertisement
Table of Contents
Summary of Contents for MG International SENSOR SOLAR
- Page 1 Central unit 2 magnetic keys (To get some other magnets, please ask your retailer) 1 alkaline battery 9V (Sensor Premium) or 1 lithium battery (Sensor Solar and Sensor Elite) 1 fixing kit (screws and bolts) 1 test sheet...
-
Page 2: Operating Principle
S é c u r i t é d e s p i s c i n e s e t b a s s i n s contact@comodo.fr www.alarme-piscine.com... - Page 3 Locate the swimmer symbol situated in the activation zone of the device: SensorPremium: on the top of the lid Sensor Solar and SensorElite: At the back side of the base During the installation steps and for a daily use, you will have to apply the magnet on that symbol.
- Page 4 S é c u r i t é d e s p i s c i n e s e t b a s s i n s 4 Installation, tests and adjustments 4.1 Position choice • Depending on the location of the house from the swimming-pool, it might be necessary to displace the security signals, warning and failure signals so that they can be clearly audible from the house.
- Page 5 S é c u r i t é d e s p i s c i n e s e t b a s s i n s 4.2 Activation – Tests 4.2.1 Activation • Unscrew and withdraw the lid •...
-
Page 6: Basic Tests
S é c u r i t é d e s p i s c i n e s e t b a s s i n s Your device is not yet operational, after the installation of the battery you have 30 minutes to carry out the tests and adjustments specified hereafter. -
Page 7: Advanced Tests
S é c u r i t é d e s p i s c i n e s e t b a s s i n s 4.2.3 Advanced tests Tests are to be carried out only if the basic tests were not carried out successfully. •... - Page 8 S é c u r i t é d e s p i s c i n e s e t b a s s i n s • Test 3 : Fall testing • Simulate the fall of a body in the pool by making a child or a 6-8 litres water jerry can or the dummy from your retailer, fall from the curb stone.
- Page 9 S é c u r i t é d e s p i s c i n e s e t b a s s i n s 4.3 How to fix your device to the curb stone • Set your device in « inactive monitoring » mode •...
-
Page 10: Daily Use
S é c u r i t é d e s p i s c i n e s e t b a s s i n s 5 Daily use 5.1 Normal use • Switch to inactive monitoring mode: Apply the magnet on the swimmer symbol until you obtain 10 short beeps. - Page 11 5.4 Monthly tests In order to check the good operating of your Sensor Premium, Sensor Solar or Sensor Elite, it is imperative to proceed monthly to the basic tests (paragraph 4.2.2) and to note the results in the form provided in the installation guide.
- Page 12 S é c u r i t é d e s p i s c i n e s e t b a s s i n s Anticipate! > have an accessible phone near the pool so you don’t have to leave your children without monitoring to answer the phone >...
- Page 13 If writing, the client must clearly describe the problem, the date and place of the purchase and clearly state his personal details. MG International reserves the right to replace the repairable parts by new or as new parts. In case the device or its parts are unserviceable for more than 7 days in a workshop or at the place of installation, the guarantee will be prolonged for the unserviceable period.
- Page 14 Regularly check the correct operation of your device by carrying out the tests indicated in this guide. MG International‘s obligation is only to provide the client with an operational device, without any fault of material or manufacture. MG International can’t be held responsible for the fall, the drowning of a child, adult or any animal. The monitoring of parents remains the best security solution for children.
