Summary of Contents for Algo 1203
- Page 1 1203 Call Switch GETTING STARTED SHEET Need Help? (604) 454-3792 support@algosolutions.com Document 90-00092C Algo Communication Products Ltd (604) 454-3792 2019-09-19 4500 Beedie St Burnaby BC Canada V5J 5L2 support@algosolutions.com www.algosolutions.com...
- Page 2 (for endpoints equipped with a microphone). The 1203 Call Switch connects to the 'Relay Input' port of the SIP Endpoint. This port is capable of detecting a dry contact closure (normally open or normally closed) for which the input is named.
- Page 3 2. Install the 1203 by connecting a single pair twisted 24 AWG wire to its terminal block and wire it to the Relay Input on the Algo SIP Endpoint’s terminal block. The connection is polarity independent. If the endpoint is configured for the 1203 Call Switch the blue LED should illuminate immediately upon connection.
-
Page 4: Important Safety Information
Additional Features -> Input/Output. Set Relay Input Mode to “Relay Normally Open/with Supervision (e.g. Algo 1203 Call Switch)”. 4. Set the action to be performed when the 1203 Call Switch is pressed under the “Action When Input Triggered” Section and/or set “Action when Tamper Detected” if “Relay Normally Open with Supervision”...
