Accu-Tab
The PowerBase® 3070AT Chlorinator is
NSF
®
NSF-Listed for pool applications.
ONLY Axiall Corp. Accu-Tab® Blue SI
Tablets for commercial pool applications
STD 50
are permitted for NSF installations.
Use of tablets will void NSF certification.
DANGER:
DO NOT MIX CHEMICALS!
The PowerBase 3070AT chlorinator
system is designed for use with Axiall
Corp. approved tablets only. Do not use
Cal-Hypo tablets with stabilized chlorine
or bromine products, or other sanitizing
chemicals.
Fire or explosion could result.
®
PowerBase
by Axiall Corporation
Installation and Operating Instructions
®
3070AT
Rev 05/08/18
Advertisement
Table of Contents
Summary of Contents for Axiall Accu-Tab PowerBase 3070AT
- Page 1 Use of tablets will void NSF certification. DANGER: DO NOT MIX CHEMICALS! The PowerBase 3070AT chlorinator system is designed for use with Axiall Corp. approved tablets only. Do not use Cal-Hypo tablets with stabilized chlorine or bromine products, or other sanitizing chemicals.
- Page 2 Axiall erosion feeder technology that erodes only the bottom layer of tablets on the sieve plate, while keeping tablets above the sieve plate dry and ready for use. Tablets other than Axiall Accu-Tab Blue SI tablets will have different delivery rates, resulting in improper chlorine delivery.
-
Page 3: Installation Instructions
Installation Instructions Place the chlorination system in a location near the place of application. Level the system. This is important for proper chlorine delivery. Connect the inlet flow meter assembly to the solution tank. The parts were shipped separately to prevent breakage in shipping. Connect the inlet water supply with 1-1/2”... - Page 4 If a chemical controller is utilized, plug the controller cord into the controller’s 120v switched output. NOTE: IF A HIGH PRESSURE WEBTROL PUMP IS ORDERED, A LARGER CAPACITY PUMP CONTACTOR IS INSTALLED IN THE ELECTRICAL BOX AND NO CORD/PLUG IS PROVIDED AS A 25 AMP CIRCUIT IS REQUIRED.
- Page 5 Model 3070AT Using Accu - Tab ® Blue and Blue SI Tablets For pool use only ® Standard 50 Flow Through Chlorinator (gpm) Start Up 1. Close the discharge gate valve. 2. Open the feed and discharge isolation valves. Water will begin to fill the solution tank.
-
Page 6: Operation
Operation 1. Remove lid from chlorinator and fill with the appropriate amount of Accu-Tab Blue SI tablets. Add no more than the amount of tablets that will be used within one week. 2. Check pool water for desired chlorine level and adjust flow through chlorinator as needed. - Page 7 Preparation for cleaning 1. Prepare 2 gallons of muriatic acid. 2. Always use appropriate safety equipment while servicing the unit or handling chemicals. 3. Clean the feeder in a well-ventilated area. Chlorine gas may be released during the cleaning process! Inlet/Outlet Bypass To facilitate the cleaning process a Bypass may be installed between the inlet and outlet lines to/from the chlorination system.
-
Page 8: Troubleshooting
Troubleshooting System overflows. 1. Debris in the float valve. 2. Debris in the check valve. 3. Float valve stuck in down position. Clean float valve. Pump will not run. 1. Check power supply and connections, and controller 110v signal. 2. Check for 110 voltage across terminals #2 and #5. If voltage present, wiring or pump motor failure. - Page 11 Level Switch M8710 9500084 Option 1 ½” Discharge Swing Check Valve S1720C-15 9500077 1” Gate Valve GVG-1000-S 9500011 1 ½” Inlet Filter 1-1/2-60-F 9500000 1” Kerick Float Valve PS-100SS 9500007 For other questions, contact Axiall Technical Service (855-934-3570) for assistance...
- Page 12 Axiall or not; and, (iii) the failure to comply with laws, rules and regulations governing storage, unloading, installation, handling, and use of the System. You will indemnify, hold...
