Summary of Contents for Mustang Sampling Pony
- Page 1 Pony Heated Probe Enclosure ® Installation, Operation & Maintenance PONY ®...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Safety Warnings Product Features Technical Specifications Product Dimensions & Parts Electrical Wiring Diagrams Installation Instructions Operation Instructions Maintenance Instructions... -
Page 3: Safety Warnings
SAFETY WARNINGS Failure to abide by any of the safety warnings could result in serious injury or death. • Standard for Safety Electrical Equipment for Measurement, Control, and Laboratory Use; Part 1: General Requirements (ANSI/UL 61010-1, 07/12/2004, Ed. 2). • Standard for Safety Electrical Equipment for Measurement, Control , and Laboratory Use; Part 1: General Requirements (CAN/CSA C22.2 No. -
Page 4: Product Features
APPLICATION FEATURES BENEFITS • Patented technology utilizing • Protects probes from temperature The Pony enclosure installs between existing power supplied by heat and weather fluctuations 6” center-to-center threadolets trace tube bundle • Helps preserve sample integrity as an integral component in an •... -
Page 5: Technical Specifications
TECHNICAL SPECIFICATIONS Heating Components 80 watt self-limiting block heater (optional 50 watt self-limiting block heater for warmer climates) Maintains Sample Gas 98ºF (37ºC) Cabinet Construction Hotpressed Glass Fiber Reinforced Polyester Input Supply Voltage Options 120 VAC, 80 Watts 240 VAC, 80 Watts 24 VDC, 25 Watts... -
Page 6: Product Dimensions & Parts
PRODUCT DIMENSIONS & PARTS Intertec Enclosure Item Description Number Insulated Clamshell Enclosure Heat Trace Tube Bundle Connection Location Self-Limiting Block Heater Probe Location O’Brien Enclosure Stainless Steel Enclosure... - Page 7 Intertec Enclosure Front View Side View O’Brien Enclosure Front View Side View Stainless Steel Enclosure Front View Side View...
-
Page 8: Electrical Wiring Diagrams
ELECTRICAL & WIRING DIAGRAMS... -
Page 9: Installation Instructions
3. Verify the unit that you are hooking up to matches voltage wise with the power supply that you are connecting. Damage to the unit can occur if the wrong source power is applied. 4. A seal fitting is required for the power input connection to the Pony conduit fitting to maintain its electrical hazard classification rating. - Page 10 1/4-20 bolts. ™ 17. Once the enclosure is secured, determine the best place for the Heat Trace Bundle Tube to come into the Pony ® Probe Enclosure. With a 1-1/2” conduit hole saw, drill a hole into the side of the enclosure making sure the lid will be able to shut.
-
Page 11: Operation Instructions
OPERATION INSTRUCTIONS 1. Verify that sample stream supply is shut off. 2. Verify that power to the heat tracing is off. 3. Connect the heat trace tube bundle to the Pony Probe Enclosure block heater. ® 4. Turn power on to the heat tracing. - Page 12 Mustang Sampling, LLC 43 Ritmore Glen Ravenswood, WV 26164 P: +1 304 273 5357 F: +1 304 273 2531 info@MustangSampling.com www.MustangSampling.com Copyright © 2019 Mustang Sampling. All rights reserved. Mustang Sampling , Mustang , Pony ® ® ®...
