Summary of Contents for Anaheim Scientific N625
- Page 1 INSTRUCTION MANUAL Models: N625, N630 & N650 Professional Infrared Thermometers 1.800.561.8187 information@itm.com www. .com...
-
Page 2: Table Of Contents
Table of Content 1. Product Introduction 1-1 Features 1-2 Appl i cations 2. Safety Information 2-1 Cautions 2-2 Safety Symbols 3. Specifications 4. Operation Instructions 4-1 Quick Start 4-2 Unit Diagram 4-3 LCD Display 4-4 °C/°F Switch 4-5 Advanced Functions 4-6 Remarks 5. -
Page 3: Product Introduction
Temperature data storage (not ava ilab le on model N625) 10 Points of measure ment me mory (not available on N625) Max/ Min/ Avg/Δ T Funct ion (not ava ilab le on model N625) Audible a lar ms (not available on mode l N625) 1 - 2 A p p l i c a t i o n s ... -
Page 4: Safety Information
2. Safety Information Read the following safety information carefully before attempting to operate or service the meter. Only qualified personnel should perform repairs or servicing not covered in this manual. LASER WARNING NOTE! Do not aim laser spot directly at human eyes. Do not aim this product in any direction where people will be present. -
Page 5: Specifications
3. Specifications MODEL N625 N630 N650 Distance/Spot Ratio 12:1 -25~999˚ F -58~1830˚ F Temperature Range (-32~535˚ C) (-50~999˚ C) Accuracy (Assumes From-50~20˚ C(-58~-4˚ F) = ±3˚ C (±5˚ F) Operation Ambient From-20~100˚ C(-4~-21 2˚ F) = ±2˚ C (±3˚ F) Temp. -
Page 6: Operation Instructions
4. Operation of Instrument 4-1 Quick Start To measure a temperature, point the unit at the target you want to measure, pull the trigger and hold on t ill the end of shot. In SCAN mode, the LCD disp lays e ither the cur rent temperature in Celsius o r Fahrenheit. -
Page 7: Lcd Display
4-3 LCD Display 4-4 °C/°F Switch The unit is powered by 9V battery d isp la ys temperatures in either °C or ° F. The user has to rep lace the battery when the battery voltage drops below voltage for reliable operation and at the same time the low battery symbol w ill... -
Page 8: Advanced Functions
4-5 Advanced Functions (models N630 & N650) Operating more advanced fun ction s is done by pre ssing the "F " button . The seque nt ia l operation s and the corre spond ing explanat ions are shown in the follow ing f low -cha rt. Scan and display the temperature during measurement. -
Page 9: Remarks
4-6 Remarks For more deta ils on use r ope rat ion, p lea se read the follow ing conten ts. No mat ter whe ther you pu sh the mea su rin g tr igge r o r not, when t he un it 's power is on , you can change the function s o r adju st the pa ramete rs. -
Page 10: Techniques Of Ir Thermometer
5. Techniques of Infrared (IR) Thermometers 5-1 Field of View (FOV) Ratio = Distance to Spot (D:S) Ratio The field of view is the angle of vision at which the instrument operates, and is determined by the optics of the unit. The F OV is the ratio of the distance from the target to the target diameter. -
Page 11: Emissivity
5-2 Emissivity Emissivit y is the abilit y of an object to emit or absorb IR energy. Perfect emitter s have an emissivit y of 1, emitt ing 100% of incident energy. An object w ith an emissivity of 0.8 will absorb 80% and reflect 20% of the incident energy. -
Page 12: Emissivity Table
7. Emissivity Table 1.800.561.8187 information@itm.com www. .com... -
Page 13: Service Information
For the most c urrent repair charges please visit and clic k on “service/repair”. Return all merchandise to Anaheim Scientific with pre- paid s hippi ng. The flat-rate repair charge for Non- Warranty Ser vice does not incl ude retur n shipping. -
Page 14: Warranty Information
Anaheim Scientific distributor. Anahei m Scientific will, without c harge, repair or replace, at its option, defecti ve product or component parts.
