    Eventys IP Keyboard User Manual Doc ID.: C-301412 Edition: 05.04.2017...
  • Page 2 Copyright Technical specifications and availability subject to change without notice. © Vanderbilt 2017 We reserve all rights in this document and in the subject thereof. By acceptance of the document the recipient acknowledges these rights and undertakes not to publish the...
  • Page 3: Table Of Contents

    DVR by IP ......................28 MAG by RS-422 ....................29 DVR by RS-485 ....................31 Dome by RS-485 ....................32 Shortcut Operation ..................... 32 System Menu Configuration ................33 Version ........................ 33 User Management ....................33 RS-485/RS-422 Settings ..................34 © Vanderbilt 2017...
  • Page 4 Table of contents Hardware ......................34 Time Settings ...................... 35 Maintenance ....................... 35 Appendix ......................36 Specifications ..................... 36 © Vanderbilt 2017...
  • Page 5: About This Manual

    JURISDICTION BEFORE USING THIS PRODUCT IN ORDER TO ENSURE THAT YOUR USE CONFORMS THE APPLICABLE LAW. OUR COMPANY SHALL NOT BE LIABLE IN THE EVENT THAT THIS PRODUCT IS USED WITH ILLEGITIMATE PURPOSES. IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATER PREVAILS. © Vanderbilt 2017...
  • Page 6: Regulatory Information

    The battery is marked with this symbol, which may include lettering to indicate cadmium (Cd), lead (Pb), or mercury (Hg). For proper recycling, return the battery to your supplier or to a designated collection point. For more information see: www.recyclethis.info © Vanderbilt 2017...
  • Page 7: Safety Instruction

    Please make sure that the plug is firmly connected to the power socket. ● If smoke, odor or noise rise from the device, turn off the power at once and unplug the power cable, and ● then please contact the service center. © Vanderbilt 2017...
  • Page 8: Preventive And Cautionary Tips

    (UPS) to ensure a continuous function of the unit in the event of power dips on the AC mains supply. Suitable UPS devices can be ordered within the local IT market, e.g. APC SMT2200I or others. • Eventys IP Keyboard (CKN3910): Ensure that the total length of the power cable is less than 3m. © Vanderbilt 2017...
  • Page 9: Product Key Features

    The RS485 interface of the IP Keyboard works with the analogue Speed Dome only.  Vanderbilt recommend setting keyboard parameters, storing or loading configuration data, and setup of all connected devices (IP cameras, Speed Domes, and NVR/DVR) through the Web browser. This method is more convenient than using the built-in LCD display on the IP Keyboard.
  • Page 10: Introduction

    Introduction Front Panel Eventys IP Keyboard Figure 3-1 Eventys IP Keyboard Interfaces and Joystick Refer to Figure 3-2 Interfaces for the interfaces and joystick of the keyboard. Figure 3-2 Interfaces © Vanderbilt 2017...
  • Page 11 Universal Serial Bus (USB 2.0) port for additional devices such as USB- flash disk RS-422 serial interface Connect with the matrix, video access gateway device, etc. RS-485 serial interface Connect with the speed dome unit for PTZ control Power supply 12V DC Power Input © Vanderbilt 2017...
  • Page 12: Functional Buttons

    SCENE In the shortcut operation mode, use with the numeric buttons to switch the scenes. Use with the numeric buttons to select the device ID. CAM-G In the shortcut operation mode, use with the numeric buttons to © Vanderbilt 2017...
  • Page 13 ZOOM-  In PTZ control mode, operate the zoom out. MAIN/SPOT  In DVR operation mode, the same with the MAIN/SPOT button on the DVR panel. 128 x 64 pixel screen for display of menu. LCD Display © Vanderbilt 2017...
  • Page 14: Getting Started

    When the device is activated, you need to adjust the date and time settings. Logging in Purpose: You must log in to the device before configuring the keyboard, and operating the menu and other functions. Local login and remote login (by Web browser) are optional. © Vanderbilt 2017...
  • Page 15: Local Login

    4.2.2 Open the web browser, and enter the address (https://IP address) to enter the device Login page. Figure 4-3 Login Interface 2. Enter the user name and password. 3. Click Login to log in to the device. © Vanderbilt 2017...
  • Page 16: System Menu

    System RS-422 Hardware Upgrade Time Import Maintenance Export Menu Default Keyboard MAG by IP DVR by IP Shortcut MAG by RS- DVR by RS- Dome by RS-485 Figure 4-4 System Menu (MAG is for 3 party product) © Vanderbilt 2017...
  • Page 17: Basic Configuration

    Device Management Managing Devices by Web Browser 5.2.1 Purpose: You must add the devices to the keyboard via Web browser before realizing the operation and control of the devices on the keyboard. 1. Log in to the device. © Vanderbilt 2017...
  • Page 18 4. Click OK to save the settings. The successfully added device is shown in the list. Figure 5-3 Successfully Added Device You can also click the Add SADP to add the online devices in the same network segment. IPDome_MEGA200 is an example for a PTZ dome as 3 party product. © Vanderbilt 2017...
  • Page 19: Managing Input/Output Channels

    3. Edit the group name, set the auto-switch interval (10-10000 sec) and select the input channels from the list to the group. Up to 16 input groups can be added. IPDome_MEGA200 is an example for a PTZ dome as 3 party product. © Vanderbilt 2017...
  • Page 20 4. You can modify the group information or delete the group by Modify Group and Delete Group access. Managing Output Channel 1. Enter the Device Management > Output Channel page. 2. You can check the output channel information, or select an output channel from the list and edit the channel ID. © Vanderbilt 2017...
  • Page 21: User And User-Related Device Management

    3. Select the linked device (s) from the list for the user. 4. Click OK to save the settings. © Vanderbilt 2017...
  • Page 22: Keyboard Operation

    RS-485 serial port, and realize PTZ control. * MAG is an example for a Access device as 3 party product 3. Use the joystick to select an operation mode and press OK button to enter the operation. © Vanderbilt 2017...
  • Page 23: Keyboard Operation

    PREV/NEXT buttons to switch to the previous or next camera / camera group ID. You can press the 0 + CAM buttons to stop decoding of the current camera, or press the 0 + CAM-G buttons to stop cycle decoding of the camera group. © Vanderbilt 2017...
  • Page 24: Preset/Patrol/Pattern Calling

    Press the Num + PATTERN buttons on the keyboard panel to call the defined pattern. You can press PATTERN directly or 0 + PATTERN to call the auto scanning. Figure 6-4 Preset Calling The preset/patrol/pattern must be pre-configured. © Vanderbilt 2017...
  • Page 25: Scene Calling

    2. Log in to keyboard via Web browser (https://ip address), and enter the Aux Key Settings page (System Management > Aux Key Settings). 3. Set the Aux key function to Screen Jointing. 4. Click Save to save the settings. © Vanderbilt 2017...
  • Page 26 5. Press the AUX/F2 button on the keyboard panel to capture the picture. The picture is saved in the USB stick / disk in FAT32 format. You can also use the central button of the joystick to capture the picture in keyboard operation mode. © Vanderbilt 2017...
  • Page 27: Mag By Ip

    ID of the MAG. Please refer to the user manual of MAG for details. The input/output channel ID is used for switching on the video wall or PTZ control during keyboard operation. 7. Operate the PTZ control on the video wall. Refer to 6.1.1 Video Wall Control for details. © Vanderbilt 2017...
  • Page 28: Dvr By Ip

    Management > Device List > DVR/NVR). Figure 6-11 DVR by IP 5. Operate the buttons on the keyboard panel to realize the corresponding functions. Please refer to 3.3 Functional Buttons to check the description of the DVR control buttons. © Vanderbilt 2017...
  • Page 29: Mag By Rs-422

    2. Press the Num + MON buttons to select the display window for the output channel. 3. Press the Num + WIN buttons to set the window to play the decoded video. 4. Press the Num + CAM buttons to select the input channel. © Vanderbilt 2017...
  • Page 30 For the initial use of MAG, you must use the configuration kits software to configure the input/output channel ID of the MAG. Please refer to the user manual of MAG for details. The input/output channel ID is used for switching on the video wall or PTZ control during keyboard operation. © Vanderbilt 2017...
  • Page 31: Dvr By Rs-485

    Please refer to 3.3 Functional Buttons to check the description of the DVR control buttons. The baud rate, protocol and other parameters of RS-485 of the keyboard must be configured to 9600, 8, 1 and none parity. © Vanderbilt 2017...
  • Page 32: Dome By Rs-485

    1. On the login interface, enter the user name and password to log in to the device. Figure 6-17 Menu 2. Use the joystick to select the Shortcut to enter the shortcut operation mode. 3. Press the Num+DEV/MON/CAM/CAM-G/PRESET/PATROL/PATTERN/WIN/MULT/SCENE on the keyboard buttons to realize the corresponding device operation and control. © Vanderbilt 2017...
  • Page 33: System Menu Configuration

    1. Select User to enter the user management interface. You can change the password (admin), add new user, edit user or delete the user. 2. Click OK button or the central button of joystick to save the settings. Figure 7-2 User Management Only the admin user is allowed to add/edit/user the user (operator). © Vanderbilt 2017...
  • Page 34: Rs-485/Rs-422 Settings

    OFF. Click OK button or the central button of joystick to save the settings. When the auto-logoff is set to ON, the system will automatically log off after the device is not operated for 30 minutes. Figure 7-4 Auto-Logoff Settings © Vanderbilt 2017...
  • Page 35: Time Settings

    You should connect the U-flash disk to the keyboard before upgrading, and importing/exporting the files.  The upgrade file and configuration file must be located in the root directory of the U-flash disk.  The upgrade file must be in digicap.dav; and the configuration file in kbCfg.bin. © Vanderbilt 2017...
  • Page 36: Appendix

    1 × USB 2.0 Power supply 12V DC ≤ 4.5W Consumption Working temperature -10 to +55°C (14 to 131°F) General Working humidity 10% to 90% Dimensions (W × D × H) 435 × 193 × 110mm Weight 0.8kg © Vanderbilt 2017...
  • Page 37 Appendix © Vanderbilt 2017...
  • Page 38 © Vanderbilt 2017 Issued by Vanderbilt International (IRL) Ltd. Data and design subject to change without notice Clonshaugh Business and Technology Park Supply subject to availability Clonshaugh Dublin D17 KV84 Document no : C-301412 Ireland Document version: 1.0 www.vanderbiltindustries.com Edition: 05.04.2017...
