  • Page 1 Smart Lifter User & Installation Manual LP Range...
  • Page 2 Safety Guidelines WARNING! - Authorised Autochair technicians & installers are to complete the initial set up of this device. All Installation instructions must be followed. The following symbols are used to identify warnings and important details throughout this manual. Please read them and ensure you are aware of their meaning.
  • Page 3: Table Of Contents

    5. REMOVING & REPLACING ..................15 6. TROUBLESHOOTING ....................17 7. LIFTING ACCESSORIES ..................18 8. CARE AND MAINTENANCE ..................20 9. WARRANTY ....................... 21 SMART LIFTER INSTALLATION MANUAL 10. INSTALLATION INSTRUCTIONS ................22 11. WIRING ........................26 Smart Lifter – LP Range www.autochair.co.uk...
  • Page 4: Introduction

    Autochair to enhance or preserve the safe use of this product.
  • Page 5: Safety

    Wear goggles and gloves when handling batteries and wash hands after handling. Disposal and recycling. Contact your Accredited Autochair Dealer for information on proper disposal of your Smart Lifter and its packaging. Smart Lifter – LP Range...
  • Page 6 Smart Lifter and the related fitting kit instructions before installing the lift system. WARNING! The Smart Lifter is only intended to be installed by an Accredited Autochair Dealer or qualified technician. Separate installation instructions are provided with the Smart Lifter and the installation kit.
  • Page 7 Smart Lifter operates. Any adjustment to the Smart Lifter settings must only be carried out by an Accredited Autochair Dealer. Your Smart Lifter should be serviced every year to ensure it is in good working order.
  • Page 8: Technical

    Powder coated - grey, red, blue or pink BOOM CONTROL BOX A - FRAME HANDSET IN/OUT ACTUATOR PIVOT POST IN/OUT ACTUATOR FIXING PLATE UP/DOWN ACTUATOR ACTUATOR PIN HANDSET CABLE RETAINING PIN SPREADER BAR STRAP SPREADER BAR KEYHOLE PLATE Smart Lifter – LP Range www.autochair.co.uk...
  • Page 9: Operation

    Smart Lifter and it’s path of operation. 5. Press and hold the left or right button 6. Release the button when the boom is at its (depending on the side of installation) to swing outmost position. the Smart Lifter outwards. Smart Lifter – LP Range www.autochair.co.uk...
  • Page 10 11. Release the up button once the scooter 10. Press and hold the up button to raise the has reached the upmost position. scooter from the ground. Smart Lifter – LP Range www.autochair.co.uk...
  • Page 11 *Do not continue to hold the down button once the scooter is grounded. Do not attempt to maneuver the mobility device once it is grounded. **Autochair strongly recommend the mobility equipment is restrained whilst traveling. Failure to restrain your mobility equipment could result in injury and damage to the vehicle or passengers.
  • Page 12 Stand Here 6. Press and hold the up button to raise the 5. Keeping hold of the handset, move clear of scooter/chair from the vehicle floor. the Smart Lifter and it’s path of operation. Smart Lifter – LP Range www.autochair.co.uk...
  • Page 13 Smart Lifter by placing your hand boom fully upwards. beneath the actuator. This is a pinch point and *WARNING! Do not continue to may cause injury. hold the down button once the scooter is grounded. Smart Lifter – LP Range www.autochair.co.uk...
  • Page 14 *WARNING! Ensure the boom is rotated sufficiently into the boot to avoid contact with the boot lid when closed. Failure to ensure the boom is fully rotated could result in damage to the vehicle. **WARNING! Never leave the system switched on when not in use. Smart Lifter – LP Range www.autochair.co.uk...
  • Page 15: Removing & Replacing

    5. Slide the Smart Lifter upwards to remove it 6. Store the Smart Lifter in a dry, safe place when from the mounting lugs. TAKE CARE when not in use. lifting. Smart Lifter – LP Range www.autochair.co.uk...
  • Page 16 Smart Lifter and align the bottom mount with all the way down. This will secure the in/out the actuator arm. actuator. 4. IMPORTANT - Fully insert the Retaining Clip 5. Push the power connectors securely together. into the top pin. Smart Lifter – LP Range www.autochair.co.uk...
  • Page 17: Troubleshooting

    If you can’t find a solution to your problem, before operating the Smart Lifter please contact your Accredited Autochair Dealer as soon as possible. Their details will be written on the inside cover and the back page of this manual. If you do not have their contact details, get in touch with us and we’ll let you know who your Accredited Dealer is and how to get in touch with them.
  • Page 18: Lifting Accessories

    Please identify your lifting accessory below and ensure it is correct for your individual needs. If your scooter changes or you would like to see or discuss our entire range of lifting accessories, please contact your Accredited Autochair Agent and discuss possible options with them. Spreader Bar with Keyhole Brackets The standard Smart Lifter lifting accessory The general purpose spreader bar &...
  • Page 19 MANDATORY! Smart Lifters are set up specific to your mobility device. If you change your scooter or powerchair in any way, contact your Accredited Autochair Dealer to have your Smart Lifter adjusted to suit your new mobility device.
  • Page 20: Care And Maintenance

    If in doubt contact your Accredited Autochair Dealer. Perform every 12 months: • It is recommended that the Smart Lifter is serviced every year by Autochair or your Accredited Autochair Dealer. Cleaning: •...
  • Page 21: Warranty

    Please keep a note of the following: Serial Number: Date Supplied: Details of the Supplier: Postcode: Telephone: Fitting Kit Rating: Lifting Accessory Rating: Signed: Scooter/Chair Weight: If this changes, please check with your Accredited Autochair Dealer. Smart Lifter – LP Range www.autochair.co.uk...
  • Page 22: Installation Instructions

    355mm Maximum 37mm Minimum 137mm Maximum ACTUATOR BRACKET BOOM ASSEMBLY Refer to Torque settings before making HORIZONTAL any adjustments! EXTENSION MAIN CLAMP VERTICAL EXTENSION 8 " (410mm) Minimum 24" (610mm) Maximum SPREADER BAR ASSEMBLY Smart Lifter – LP Range www.autochair.co.uk...
  • Page 23 The limits of the adjustments are shown on the previous page diagrams. The maximum settings must not be exceeded. When correctly set, the top part of the Smart Lifter must be parallel with the vehicle floor at the point when the actuator is fully retracted. Smart Lifter – LP Range www.autochair.co.uk...
  • Page 24 The following table shows the lower actuator bracket positions and the reference used in the actuator setting chart; DO NOT The following table shows the lower actuator bracket positions recommended for various actuator loads: 100kg 125kg 150kg 200kg Actuator Stroke Recommended positions Additional adjustment zone DO NOT USE Smart Lifter – LP Range www.autochair.co.uk...
  • Page 25 Do not tighten each screw, from loose, to the full torque setting before tightening the next, the brackets clamps will be unevenly loaded and may not clamp fully. After reaching the torque setting, repeat the tightening sequence checking that all screws are at the desired torque setting. Smart Lifter – LP Range www.autochair.co.uk...
  • Page 26: Wiring

    Securely fix the control box in a position which is easily accessible when the vehicle is both loaded and unloaded. CONTROL BOX CABLES Power Button Fixing Holes Power status indicator light Power On Power Off Handset In/Out Actuator 12v D/C In Red Connectors Up/Down Actuator Black Connectors Smart Lifter – LP Range www.autochair.co.uk...
  • Page 27 Wiring CONNECTING ACTUATORS Test operation with handset. If the movement is opposite to expected then reverse the polarity of the connector/s. REVERSING POLARITY Smart Lifter – LP Range www.autochair.co.uk...
