- Page 1 Installation Instructions...
- Page 2 INSTALLATION OF LENS ATTACHMENTS & ACCESSORIES All lens attachments, Resolv4K core Zooms and Resolv4K Fixed lenses have been designed with a standard dovetail size for ease of modularity across the product line. For installation of the zoom, simply insert the dovetail end of the zoom into the bottom of the rear adapter and secure it with the (3) M4 screws supplied with the rear adapter.
- Page 3 USING THE MOUNT WITH THE RESOLV4K SYSTEM It is important that the Resolv4K Zoom be properly installed onto the mount. All flat mounts (1-80370, 1-80371, 1-80270, 1-80271) have a ledge on the backplate. This ledge is to sit within the notch located at the center of the Resolv4K Zoom or Fixed body tube (see diagram below).
- Page 4 Pair a Navitar Resolv4K lens with a Pixelink CMOS machine vision camera for excellent image quality and outstanding value. Pixelink® PL-D Camera Features: • High frame rate CMOS technology • USB 3.0 high speed data throughput • Global/Rolling shutter and trigger •...
