cns-enocean Batteryless CO2 Sensor User Guide
Control Network Solutions, (CNS) creates market disruptive SMART web based
solutions for building and lighting controls.
"Energy
harvesting
interoperable device international standards properly applied to
smart building controls, offer highly energy efficient, low operating
cost and sustainable solutions"
Introduction
devices through Ethernet connected wireless interfaces, via any suitable Niagara or Web
Supervisor™ platform.
This enables Niagara Community and System Integrator Partners to leverage their
existing Niagara tools, skills and knowledge to offer advanced wireless energy
harvesting switching and sensing solutions to their customers: For further information
visit www.cns-enocean.com.
wireless
cns-enocean™ for Niagara, is a web based solution, globally
available today, that enables the simple commissioning and
operation of networks of EnOcean® wireless energy harvesting
Page 1 of 8
solutions
based
Website:
www.control-network-solutions.co.uk
www.cns-enocean.com
upon
open
Rev 1.1
Advertisement
Table of Contents
Summary of Contents for Control Network Solution cns-enocean Series
- Page 1 www.cns-enocean.com cns-enocean Batteryless CO2 Sensor User Guide Control Network Solutions, (CNS) creates market disruptive SMART web based solutions for building and lighting controls. “Energy harvesting wireless solutions based upon open interoperable device international standards properly applied to smart building controls, offer highly energy efficient, low operating cost and sustainable solutions”...
- Page 2 www.cns-enocean.com cns-enocean Batteryless CO2 Sensor User Guide EnOcean Batteryless CO2 Sensor This world first CO2 sensor is the totally maintenance free, requires no batteries and is powered by harvesting energy from ambient indoor light making it straightforward and low cost to install. The sensor supports the open EnOcean standard (ISO/IEC 14543-3-10)
- Page 3 www.cns-enocean.com cns-enocean Batteryless CO2 Sensor User Guide EnOcean Batteryless CO2 Sensor Dimensions, mm Page 3 of 8 Rev 1.1 Website: www.control-network-solutions.co.uk...
- Page 4 www.cns-enocean.com cns-enocean Batteryless CO2 Sensor User Guide Product Installation It is recommended the CO2 sensor is installed in an environment where: 1. The local CO2 level is representative of the complete area being measured i.e. do not place the unit close to a frequently opened window or A/C unit. 2.
- Page 5 www.cns-enocean.com cns-enocean Batteryless CO2 Sensor User Guide Product Operation The CO2 Sensor needs to be commissioned before use. There are 4 stages to the commissioning process. 1. Selection of Sampling Rate As the unit is designed to harvest energy from ambient light, it may be favourable (where applicable) to reduce the unit’s sampling frequency in prolonged low level light conditions.
- Page 6 www.cns-enocean.com cns-enocean Batteryless CO2 Sensor User Guide 2. Calibration The CO2 sensor has been factory calibrated prior to supply. Like all CO2 sensors, it does need to update its calibration status periodically. In normal environments, background CO2 levels are typically 450ppm. Auto Calibration ON/OFF Auto calibration ON calibrates the reported background level of CO2 against the lowest measured values of CO2 taken over an 8 day period.
- Page 7 www.cns-enocean.com cns-enocean Batteryless CO2 Sensor User Guide 3. Connection of battery The unit is pre-installed with a non-rechargeable 3.6v Lithium “A” type battery. To enable commissioning and provide battery back-up operation in continuously low level light conditions, the battery must be connected by switching DIP Switch 4 on. Battery Unit Status Dip Switch 4...
- Page 8 www.cns-enocean.com cns-enocean Batteryless CO2 Sensor User Guide CNS can also supply additional cns-enocean compatible EnOcean wireless energy harvesting products click here for more details. Contact Details Control Network Solutions Ltd Studio 7, Intec 2, Intec Business Park, Wade Road BASINGSTOKE, Hampshire, RG24 8NE, England Tel: +44 (0) 1256 818700 Fax:...
