1 INTRODUCTION 1.1 Overview 1.2 Intended Use And Foreseeable Misuse Congratulations on your choice of a Baumalight The tree puller is designed to be used by an Incisor Tree Puller to complement your operation. experienced operator. Operator must be trained This equipment been...
2 SAFETY 2.1 Safety Alert Symbol 2.2 Operational Hazards And Safety Words You must read, understand and follow the ^ WARNING instructions given operating unit manufacturers, as well as the instructions in this Prevent death or serious injury� manual. Read and understand this manual before The safety information in this manual is denoted operating tree puller�...
Prepare For Emergencies ^ WARNING Prevent death or serious injury� • Be prepared in case of emergencies. • Keep a fire extinguisher and first aid kit close Verify tree puller is locked to quick attach to the machine. hitch before operation or transport� •...
Lower Operating Speed Detach Tree Puller Safely Keep tree puller low and move at slow speeds on Detach tree puller on a firm and level surface. Tree rough or uneven terrain. puller may fall over if detached on unlevel or soft surface.
Page 8
Avoid Loud Noise Avoid High Pressure Fluids ^ WARNING ^ WARNING Prolonged exposure to loud noise can Pressurized fluids can penetrate the cause impairment or loss of hearing� skin� Wear a suitable hearing protective device Hydraulic hoses can fail from age, such as earmuffs or earplugs to protect damage and exposure�...
2.3 Maintenance Hazards Before servicing, park machine on a firm and ^ WARNING level surface, set parking brake and place a “Do Entanglement hazard� Not Operate” tag on control panel. Read and understand this manual. If you do not understand Keep clear of moving components�...
4 OPERATION 4.1 Preparation For Use 4.2 Machine Components Although the tree puller has been carefully A. Hose Holder inspected and checked prior to shipment from B. Relief Valve manufacturer, it is recommended that the unit be C. Clamp Cylinder thoroughly inspected.
4.3 Attach To Skid Steer 4.4 Detach From Skid Steer ^ WARNING ^ WARNING To prevent injury or machine damage Prevent death or serious injury caused put transmission in park� by unexpected movement: Park skid steer on a level surface� 1�...
4.5 Transporting 4.6 First Time User Tips 1. Verify all reflectors and Slow Moving Vehicle Operate all functions in an open area with skid (SMV) sign are visible. steer at idle to get a good feel for the controls. 2. Raise tree puller slightly off ground. Run throttle only at half speed for first time users.
4.7 Field Operation 4.8 Relief Valve ^ WARNING ^ WARNING Prevent serious injury or death caused Prevent serious injury or death caused by unexpected movement: by unexpected movement: Park skid steer on a level surface� Park skid steer on a level surface� 1�...
5 SERVICE AND MAINTENANCE 5.1 Lubrication 5.2 Inspect Hoses ^ WARNING ^ WARNING Pressurized fluids can penetrate the Prevent serious injury or death caused skin� by unexpected movement: Park skid steer on a level surface� 1� Hydraulic hoses can fail from age, Lower puller to ground�...
6 TROUBLESHOOTING PROBLEM CHECK SOLUTION Clamps do not close. Clamps jammed. Remove material from clamps. Low oil. Check oil level in skid steer. Add oil if necessary. Not enough oil flow. Check flow control on skid steer. See your dealer. Clamps do not have much power.
7 WARRANTY This product is warranted to be free of defects in materials and workmanship under normal use and service, for a period of one year from the date of purchase, when operated and maintained in accordance with the Operating and Maintenance Instructions supplied with this unit. This warranty does not cover misuse or negligence.
Page 20
For parts, specifications and the latest machine information please visit our website. www�baumalight�com MTB MFG INC. CORPORATE HEADQUARTERS 4575 Powell Rd., Wallenstein, Ontario Canada N0B 2S0 Phone - 519.698.9864 Toll Free - 866.820.7603 Fax - 519.698.1087 www�baumalight�com...
