Summary of Contents for AirLive Smart Home Kit
- Page 1 Smart Life For Home Smart Home Kit QIG...
-
Page 2: Table Of Contents
Setup the IoT Package Start to use IoT Gateway Start to use IoT Device Start to use AirLive SmartLife Plus Appendix Exclude Devices Include Sensors and Smart Plug (Option) Include SmartCube 300W (Option) Page 00... -
Page 3: Setup The Iot Package
Download the AirLive Smart Life Plus APP Please visit App Store or Google Play Smart Life to download AirLive SmartLife Plus For Home APP. You can use QR code scanner software directly or simply search the “AirLive SmartLife Plus”. AirLive SmartLife Plus... - Page 4 Setup the IoT Package Start to use IoT Gateway Install the Gateway Execute the APP Connect the gateway to the Router Click the “AirLive by Ethernet cable SmartLife Plus” icon on your smart Note: When the internet connection is For Home...
- Page 5 Setup the IoT Package Start to use IoT Gateway Select QR code to Add Scan the QR code Gateway Remove the back holder of the Please select "QR Code" to add Gateway by sliding it down and gateway. then, Please scan the QR code to add the gateway.
- Page 6 Key in gateway ID and password to gateway if QR code not work. field. The default ID is "admin" and the password is "airlive". Press the Note: Make sure your phone and Eye to see your password gateway are on the same...
-
Page 7: Start To Use Iot Device
Setup the IoT Package Start to use IoT Device Devices Screen Siren After Login into the Gateway, the When the Siren is not displayed in APP will display the Scenes page by the Devices tab, then go to "Setting" default to see your devices. Click >>... - Page 8 1. Click the Icon to see the Device By default the Wifi in the Gateway is information. turned on. The default SSID is Airlive-XXXXX were XXXX is the 2. Click the Text to Activate the wireless MAC address of your Actuator (Sensor cannot be Gateway.
- Page 9 Setup the IoT Package Start to use IoT Device Wifi Notice-2 Wifi Notice-3 To change the Wifi settings Go to In the Wifi menu you can select OFF "Setting" and "Gateway to turn the Wifi of the Gateway Off. Information" Click on the Wireless Or for AP Mode/ STA mode.
- Page 10 Setup the IoT Package Start to use IoT Gateway / Start to use IoT Device Download APP User's Guide You can click "Question mark" to Smart Life download the user's guide for APP For Home operation. Start to use IoT Device Page 08...
- Page 11 Setup the IoT Package Start to use IoT Device Start to use 3 in 1 sensor Install the 3 in 1 sensor Remove the black mylar, the red Use the double-sided adhesive light will flash about 10 seconds. And attached to back of the device, and then you can paste the device on the paste the device on the door or door or window.
- Page 12 Setup the IoT Package Start to use IoT Device Start to use Motion(PIR) Sensor Install the Motion sensor Turn the cover counter-clockwise Fix the bracket on the wall. There's a and open it. Remove the black magnet on the backside of this mylar, the red light will flash 3 times.
- Page 13 Setup the IoT Package Start to use IoT Device Start to use Smart Plug Install the Plug (Option) Plug the device into the outlet. And Plug the appliance's power into the then you can plug the appliance's plug. power into the plug. Ex: table lamp, electric fan Page 11...
- Page 14 Setup the IoT Package Start to use IoT Device Install the SC300W by WIFI 1 Install the SC300W by WIFI 2 We recommend to connect the Then immediately, please click on the camera via LAN cable, it is more Reset/WPS button on the camera. stable.
- Page 15 Setup the IoT Package Start to use IoT Device / Start to use AirLive SmartLife Plus Install the SC300W by Ethernet If you have connected the camera Smart Life through WiFi, please skip this step. For Home Do not connect by WiFi and Ethernet cable at the same time.
-
Page 16: Start To Use Airlive Smartlife Plus
Setup the IoT Package Start to use AirLive SmartLife Plus Execute the SmartLife Plus Smart Rule Click the “AirLive SmartLife Plus” AirLive SmartLife Plus APP features “Smart icon on your smart phone, For more Rules” which allows you to group sensors information about the use of the APP from different rooms, as well as to cary out... - Page 17 Setup the IoT Package Start to use AirLive SmartLife Plus Quickly Launch Intruder Setting Intruder Alarm Alarm After login the gateway to click Click "Home Security Alarm" on "Macros" tab screen Trigger: Set the duration for Click the padlock to close/open, then...
-
Page 18: Appendix
Smart Life settings. For Home Press Include/Exclude icon and press Exclusion. When using the Airlive Kit the Devices have already been included to the gateway by default, but if you want to include a device again you must exclude the device first. - Page 19 Appendix Exclude Devices Exclude Device -2 Exclude 3 in 1 sensor -3 APP will show "Exclude device", Press tamper key on the back of and start count down. sensor 3 times in rapid succession then the red light LED will flash. Note: when device excluded, it will automatically be in the inclusion mode, red light slowly flashing...
- Page 20 Appendix Exclude Devices Exclude Motion sensor -4 Exclude Smart Plug -5 Press tamper key on the back of Press LED key on the plug 3 sensor 3 times in rapid succession times in rapid succesion then then the red light LED will flash. the red light LED will flash.
-
Page 21: Include Sensors And Smartplug (Option)
Appendix Exclude Devices / Include Sensors and Smart Plug (Option) Exclude Device -6 Success to exclude device, APP will Smart Life show message. For Home Include Sensors and SmartPlug (Option) Page 19... - Page 22 Appendix Include Sensors and SmartPlug (Option) Include 3 in 1 multi sensor -1 Include Motion Sensor -2 3 in 1 sensor will automatically be in PIR sensor will automatically be in the inclusion mode if you excluded the inclusion mode if you excluded the device, red light slowly flashing the device, red light slowly flashing for 30 seconds.
- Page 23 Appendix Include Sensors and SmartPlug (Option) Include Smart Plug -3 Include Device -1 Plug the device into the outlet. Go to Devices page and click "+" icon. Note: Plug will automatically be in Press Include Device including mode if you excluded device, red light slowly flashing for 30 seconds.
- Page 24 Appendix Include Sensors and SmartPlug (Option) Include Device -2 Include Device -3 Press "START INCLUSION" When the device is being included, APP will configure the setting into Start to include a device. gateway. Page 22...
-
Page 25: Include Smartcube 300W (Option)
APP will display the message "Device For Home Included" it is now ready for use. Include SmartCube 300W (Option) If you want to use SD-card for video recording, please see the guide in the FAQ section of the SmartCube 300W on www.airlive.com Page 23... - Page 26 Appendix Include SmartCube 300W (Option) Add Camera Select scan QR code or LAN search Go to Devices page and Please select "QR Code" or "LAN click "+" icon. Search" to add camera. Press Add camera Page 24...
- Page 27 Appendix Include SmartCube 300W (Option) Scan the QR code LAN Search Please scan the QR code to add the Or click "LAN search" to add the camera. You can find the camera's camera if QR code not work. QR code on the back of the camera. Note: Make sure your phone and camera are on the same network segment...
- Page 28 Include SmartCube 300W (Option) Key in the password Success Add Camera Key in camera's password and Camera icon will show on Device display name to field. The default screen. password is "airlive" Note: display name can input you desired name. Page 26...
- Page 29 Appendix Include SmartCube 300W (Option) Live View Camera Settings Click camera icon to live view You can refresh the video image or streaming snapshot or recording or change password or delete the camera. Refresh Streaming Recording Video Key in password Change Video Quality or Change Password Delete camera...
- Page 30 FCC Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
- Page 31 Smart Home Kit QIG OvisLink Corp. 5F, No.6, Lane 130, Min-Chuan Rd., Hsin-Tien Dist., New Taipei City 231, Taiwan TEL: +886 2218 6888 FAX: +886 2218 6988...
