  • Page 1 F4PGK305S1 F6PGK305S1 F4PGK365S1 F6PGK365S1 PROFESSIONAL GAS INSTALLATION INSTRUCTIONS COOKTOP PLAQUE DE CUISSON GAZ INSTRUCTIONS D’INSTALLATION PROFESSIONNELLE PLACA DE COCCIÓN INSTRUCCIONES DE INSTALLACIÓN PROFESIONAL DE GAS...
  • Page 3 Our goal is to deliver products that are worthy of your family recipes and that will breathe life into your kitchen, the heart of your home. We invite you to enjoy your new Fulgor Milano product with same amount of care and attention that we have put into creating it.
  • Page 5: Table Of Contents

    Pay attention to these symbols present in this manual: TABLE OF CONTENTS PAGE DANGER 1 - Special Warnings Before Starting Installation You can be killed or seriously injured if you don’t Cooktop Installed over Oven Installation IMMEDIATELY follow instructions. 2 - Product Dimensions and Cutout Requirements Important Preparation Suggestions WARNING Mobile Home Installation...
  • Page 6: Special Warnings

    1 - Special Warnings IMPORTANT Please read all instructions before using this appliance. Proper installation is your responsibility. Have a qualified technician install this cooktop. IMPORTANT WARNING BEFORE CONNECTING THE APPLIANCE ON THE • Observe all governing codes and ordinances. GAS LINE SUPPLY, ENSURE THAT ITS GAS SETTING IS APPROPRIATE.
  • Page 7: Product Dimensions And Cutout Requirements

    2 - Product Dimensions and Cutout Requirements Important Preparation Suggestions 1. Chamfer all exposed edges of decorative laminate to prevent damage from chipping. 2. Radius corners of cutout and file to Insure smooth edges and prevent corner cracking. Recommend 1/4”or 3/8” diameter drill In each corner.
  • Page 8 COUTOUT DIMENSIONS CUT OUT WIDTH MIN 28-1/2 [72.4 cm] MIN 19-9/16” [49.7 cm] MIN 2” (5.0 cm) MIN 3 1/2” (9.0 cm) 30” MAX 28-11/16” [72.9 cm] MAX 19-3/4” [50.2 cm] MIN 34-1/2” [87.6 cm] MIN 19-9/16” [49.7 cm] MIN 2” (5.0 cm) MIN 3 1/2” (9.0 cm) 36”...
  • Page 9 CUTOUT REQUIREMENTS 13” (33 cm) Depth of unprotected overhead cabinets. 30” (76.2 cm) MIN. (Model 30“). 36” (91.4 cm) MIN. (Model 36”). 18” (47.7 cm) MIN. Height from countertop to nearest cabinet on either side of unit. 36” (91 cm ) MIN. (see Note* Clearance from countertop to unprotected overhead surface. ) 5”...
  • Page 10: Mobile Home Installation

    We recommend to that you consider the minimum dimension SOLID SURFACE COUNTERTOP INSTALLATION of cut-out size in the case of new installation. WARNING The appliance should not be installed with a ventilation system that blows air downward toward the range. This type of ventilation system may cause ignition and combustion problems with the gas cooking appliance resulting in personal injury or unintended operation.
  • Page 11: Cooktop Installation

    3 - Cooktop Installation PARTS WARNING • Excessive Weight Hazard MANUAL Use two or more people to move and install cooktop. Failure to do so can result in back or other injury. GASKET • Cut Hazard GAS CONVERSION KIT GAS CONNECTION KIT Beware of sharp edges.
  • Page 12 Step 3 Step 4 Insert the cooktop centered into the cutout opening. Four clamp brackets are provided with your unit. Make sure the front edge of the counter top is parallel to After cooktop has been installed into the countertop, install the cooktop.
  • Page 13: Gas Requirement

    4 - Gas Requirement A QUALIFIED SERVICE MAN OR GAS APPLIANCE INSTALLER All supply piping, except as noted, should use common MUST MAKE THE GAS SUPPLY CONNECTION. National Pipe Thread (N.P.T.). For all pipe connections use an approved pipe joint compound resistant to the action of Leak testing of the appliance shall be conducted by the LP gas.
  • Page 14: Gas Connection

    Gas Connection ILLUSTRATIVE GAS SUPPLY PIPING • Thread the appliances pressure regulator with 1/2” male (NO OTHER APPLIANCE BELOW end connection both supplied with this appliance. COOKTOP) • Make the gas connection to the inlet of the pressure BURNER BOX regulator with 1/2”...
  • Page 15 FOR ALTERNATIVE PIPING METHODS TO CONNECT THE CAUTION APPLIANCE TO THE GAS SUPPLY, A TRAINED SERVICE MAN OR GAS APPLIANCE INSTALLER MUST MAKE THE GAS SUPPLY Do not attempt to attach the flexible connector directly to an CONNECTION. external pipe thread. Leak testing of the appliance shall be conducted by the Installer Connection requires flare union adapters.
  • Page 16: Pressure Testing

    Pressure Testing The appliance must be isolated from the gas supply piping system by closing its individual manual shut-off valve during any pressure testing of the gas supply piping system at test pressures equal to or less than 1/2 PSIG (3.5 kPa). This appliance, as well as its individual shut-off valve, must be disconnected from the gas supply piping system during any pressure testing of the system at test pressures in excess...
  • Page 17: Electrical Requirements

    5 - Electrical Requirements General Information Electrical Connection This appliance must be supplied with the proper voltage An adequate electrical supply and outlet must be used to and frequency and connected to an individual, properly operate the electrical parts of your cooktop. grounded branch circuit, protected by a circuit breaker or fuse having amperage as noted on the rating plate.
  • Page 18 WIRING DIAGRAM (5 ZONES) TERMINAL BLOCK 5 SINGLE RE-IGNITER SYSTEMS (ALTERNATIVE) WIRING DIAGRAM (5 ZONES + KNOB LIGHT) TERMINAL BLOCK J 13 J 12 J 14 5 SINGLE RE-IGNITER LED KNOB SYSTEM SYSTEMS (ALTERNATIVE)
  • Page 19: Conversion For Lp Or Ng Gas

    6 - Conversion for LP or NG Gas Converting Appliance for Use with LP Gas WARNING Conversion is to be performed by a AUTHORIZED SERVICER (or other qualified agency) in accordance with the manufacturer’s instructions and all codes and requirements of the authority having jurisdiction. Failure to follow instructions could result in serious injury or property damage.
  • Page 20: Converting Appliances For Use With Ng Gas

    Pressure regulator conversion The appliances is designed for use with NG gas or LP gas. The gas pressure regulator is supplied. It must be installed in the gas way ahead of manifold entrance. It is pre-set for use with the gas supplied with the appliances. For use with different gas must be converted.
  • Page 21: Injectors Position

    Injectors position Inj-pos-30” (4 Single + Minidual) 192 Main Flame 72 Simmer LP conversion Inj-pos-30” (4 Single + Minidual) 105 Main Flame 50 Simmer...
  • Page 22 LP conversion Inj-pos-36” (4 Stacked + Minidual) 170 Main Flame 170 Main Flame 105 Main Flame 105 Main Flame 53 Simmer 192 Main Flame 53 Simmer 36 Simmer 105 Main Flame 36 Simmer 72 Main Flame 50 Main Flame 170 Main Flame 170 Main Flame 105 Main Flame 105 Main Flame...
  • Page 23: Low Flame Adjustment

    Low Flame Adjustment Adjustment for Burners with two rings flame: DANGER 1. Light burner and set control knob for low flame. Lighting gas burners with a match is dangerous. 2. Remove the control knob from valve stem. And also You should match light the cooktop burners only In an remove the control panel, and valve gaskets.
  • Page 24: Electric Gas Ignition

    The Burner Flames Proper adjustment will produce a stable, steady blue flame of minimum size. The final adjustment should be checked by turning knob from Turn each burner on. Flames should be blue in color with no high to low several times without extinguishing the flame. trace of yellow.
