Summary of Contents for dentalfarm W.A.FI.S.
- Page 1 DUST FILTERING SYSTEM W.A.FI.S. Electric Version MAINTENANCE AND INSTRUCTION MANUAL...
- Page 2 DESCRIPTION W.A.FI.S. is a dust suction, filtering and elimination system (DENTALFARM exclusive patent) expressly studied to work in conjunction with the Dentalfarm sandblaster models which can be easily connected to any blasting chamber. The system fully complies with international existing rules referred to environmental hygiene.
- Page 3 INSTALLATION INSTRUCTIONS The WAFIS must be positioned on the floor, under or near the bench where the sandblaster has been placed. The connection ATTENTION: pipe must fall perpendicularly avoiding any pockets and/or siphons which may collect sediment inevitably causing am loss in the intake power (eventually cut the pipe).
- Page 4 INSTRUCTIONS FOR USE To operate the WAFIS system connected to a pre-arranged DENTALFARM sandblaster, it is sufficient to leave the switch (pos. 1) on and turn the light on. On the other hand, in case the WAFIS is connected to the power outlet, you must turn on acting on its own switch.
- Page 5 FEEDING CABLE (7-8) TECHNICAL REFERENCE REGULATIONS AND TEST PROCEDURES Every unit is mass-manufactured by DENTALFARM in compliance with technical and safety rules in force, as provided for by the 2006/42 EEC Community Directive on Machinery. Careful inspection and full routine testing are carried out singularly on each filtration system.
- Page 6 EXPLODED DRAWING AND SPARE-PART LIST CODE DESCRIPTION RCS044 DEPRESSOR CLEANING SWAB NEA111 PLASTIC FERRULE D.=16 RCB030 DEPRESSOR INSPECTION CAP NEC016 MAIN SWITCH 1201021 STAINLESS STEEL HOUSING NES029 WAFIS SOLENOID VALVE + CONNECTOR NEV014 ELECTRIC CABLE 3X1 WITH IEC320 PLUG NEV013 FEEDING CABLE NPR119 8x6 1/8”...
- Page 8 Percentage of eliminated dust 99,8% Power tension 230v - 50Hz DENTALFARM s.r.l. Via Susa, 9/a - 10138 TORINO - ITALY COMMERCIAL SERVICE - (+39) 011/4346588 AFTER SALE SERVICE – (+39) 011/4346632 FAX – (+39) 011/ 4346366 E-MAIL - info@dentalfarm.it WEBSITE: www.dentalfarm.it...
