Summary of Contents for BEACH WAGON Lite
- Page 1 BEACH WAGON COMPANY BEACH WAGON Lite RAM4-1 USER GUIDE www.beachwagon.company © copyright 2017...
-
Page 2: Table Of Contents
BEACH WAGON COMPANY RAM4-1 CONTENTS Contents Warnings Maintenance and repair Moun2ng wheels Wheel locking Unfolding Folding Storage www.beachwagon.company © copyright 2017... -
Page 3: Warnings
BEACH WAGON COMPANY RAM4-1 WARNINGS WARNING! A CHILD'S SAFETY IS YOUR RESPONSIBILITY. WARNING! Never leave a child unattended. It may be dangerous to leave your child unattented. WARNING! This verhicle is not a toy. Children are NOT allowed to play with it. WARNING! Read the instructions BEFORE use. Keep these instructions for future reference. WARNING! This verhicle is intended for childeren from age 3 years and maximum up to 80 KG WARNING! This product is not suitable for running or skating. WARNING! Do not attach the product to any other vehicle, car, bicycle, motor or animal. Do not use on highway. Only use for walking. Maximum speed 10 KM per hour. WARNING! Avoid serious injury from falling or sliding out. WARNING! Maximum load is 80 KG. Never overload. Never load more children then the product is suitable for. WARNING! Always divide the load evenly over the wagon. Overloading on one side might cause tilting of the wagon. WARNING! When the product is used in the sun, there is a hazard of sun burn. Use sun protection for children. WARNING! Keep flames and heat away from the product. WARNING! This vehicle requires regular maintenance by the user. See the maintenance instruction in this manual. WARNING! Ensure that all accessories are engaged / constructed according the adviced instructions in the manual of these accessories before use. WARNING! To avoid injury ensure that your child is kept away from the product when unfolding and folding this product. WARNING! Keep plastic covers and bags away from children to avoid suffocation and hazard. WARNING! Children should be kept on a distance of moving parts while making adjustments. WARNING! Children may never stand in the wagon when moving. www.beachwagon.company © copyright 2017... -
Page 4: Maintenance And Repair
BEACH WAGON COMPANY RAM4-1 MAINTENANCE and REPAIR Regular maintenance extends life span of the Beach Wagon and reduces the chance of problems. Please have all minor repairs and maintenance done by a good bicycle shop or experienced bicycle repairer, and contact your dealer with any other problems or for parts needing to be repaired. Or contact us at www.beachwagon.company. The high-quality materials used to make the Beach Wagon guarantee its long life span. When assembling the frame in the factory, no extra protecBon is applied to the parts. Premature damage to metal parts is prevented by cleaning the Beach Wagon regularly and treaBng all parts with acid-free vaseline or other protecBve substances. Extra maintenance is necessary when the Beach Wagon comes into contact with sand or salt. Salt should be rinsed off with clean water, and the parts coated with a protecBve layer in order to prevent damage to the steel parts. Take the wheels off and clean the axles with water. AFer cleaning make all parts dry. Please remember that if the Beach Wagon comes into contact with salt, this could penetrate into the metal tubes. To prevent excessive corrosion, tubes must be checked for damage and treated with a protecBve layer. The covers are made of polyester and can be washed in the washing machine at a low temperature of 30 degrees Celsius. The polyester covers can be removed by opening the zippers and velcro for inspecBon and maintenance. Check before every use of the wagon. 1. Check if all nuts and bolts are fastened securely. If necessary Bghten or loosen them. 2. Treat all moving parts with vaseline or Teflon spray. 3. Check the cover and all other texBle parts for damaged seams and/or zips. 4. Check the frame for damage and/or breaks. 5. Check all parts for damage/corrosion. If necessary clean the parts, and coat them with a protecBve layer. 6. Check the wheel bearings for corrosion. If necessary, remove the bearings from the wheel rim, clean them and apply a layer of vaseline. -
Page 5: Moun2Ng Wheels
BEACH WAGON COMPANY RAM4-1 MOUNTING WHEELS See page “Wheel locking" for fixing wheels to axle. www.beachwagon.company © copyright 2017... -
Page 6: Wheel Locking
BEACH WAGON COMPANY RAM4-1 WHEEL LOCKING Rear wheel How to acach. Slide wheel axle (A) into frame axle (B) unBll buYon (C). Push buYon (C) and slide wheel axle (A) into frame axle (B) unBll buYon (C) is fixed into locking hole (D). How to remove Push buYon (C) and pull out wheel in outside direcBon of axle. Front wheel. How to acach. Slide wheel axle (A) into frame axle (B) unBll buYon (C). Push buYon (C) and slide wheel axle (A) unBll buYon (C) is fixed (D). How to remove Push buYon (C) and pull out wheel in outside direcBon of axle. www.beachwagon.company © copyright 2017... -
Page 7: Unfolding
BEACH WAGON COMPANY RAM4-1 UNFOLDING Acach wheels: see page “Moun2ng wheels”. Open the lef and right side Pull bar strap panel. 4 clamps in open posi2on Open buckle Open front and rear panel. Do NOT open by lifing pull bar. Open by lifing the front and rear panels. Beware the pull bar does not hit your HEAD! You can move pull bar strap to inside of the wagon. Fix the side panels by closing the 4 clamps. Put the 4 clamps in open posi2on. See also website for clamp closing anima3on. © copyright 2017 www.beachwagon.company... -
Page 8: Folding
BEACH WAGON COMPANY RAM4-1 FOLDING Fold front and rear panels. Open the 4 clamps. Do NOT fold by pull bar. Beware the pull bar does not hit your HEAD! Fold wagon by holding the front and rear panels. Fold the right and lef side panels. Close pull bar strap with the buckle to hold Bring the clamps in pull bar and wagon “close” posi2on for flat frame together. folding. Open buck Pull bar strap Remove wheels: see page “Wheel locking”. © copyright 2017 www.beachwagon.company... -
Page 9: Storage
BEACH WAGON COMPANY RAM4-1 STORAGE Park the wagon frame on the floor or hang on the available wall hooks. www.beachwagon.company © copyright 2017... - Page 10 BEACH WAGON Lite BEACH WAGON COMPANY Stationsstraat 81 9679 EC Scheemda The Netherlands contact@beachwagon.company www.beachwagon.company Beach Wagon Company own the intellectual property rights in our brands and designs of the Beach Wagons and accessories. We acBvely pursue people who infringe our intellectual property.
