Strongarm 402A Operating Instructions Manual

10,000 psi 54 oz air/hydraulic foot pump – heavy duty

Advertisement

10,000 PSI 54 oz Air/Hydraulic
Foot Pump – Heavy Duty
Operating Instructions
WARNING:
!
! !
!
!
Important: read these instructions and all warnings prior to
using this equipment. Understand all operating procedures,
safety warnings and maintenance requirements. Failure to
do so could cause an accident resulting in serious or fatal
injury and/or personal property damage.
www.strongarminc.com
PROD NO. 030215
MOD NO. 402A
M13-SA030215

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 402A and is the answer not in the manual?

Questions and answers

Summary of Contents for Strongarm 402A

  • Page 1 PROD NO. 030215 MOD NO. 402A 10,000 PSI 54 oz Air/Hydraulic Foot Pump – Heavy Duty Operating Instructions WARNING: Important: read these instructions and all warnings prior to using this equipment. Understand all operating procedures, safety warnings and maintenance requirements. Failure to do so could cause an accident resulting in serious or fatal injury and/or personal property damage.
  • Page 2 It is recommended that this equipment be inspected annually by a qualified repair facility. Defective parts, decals, safety labels or signs should be replaced with STRONGARM specified parts. WARNING! •...
  • Page 3 CONTENTS Description Air Pump Oil Dipstick Adaptor 3/8" to 1/4" NPT Operating Instructions ASSEMBLY Remove shipping screw located on the top side of the cover. Replace shipping screw with the supplied oil dipstick. Do not use a wrench or over tighten when installing the dipstick. Please keep the shipping screw if needed for shipping or transport.
  • Page 4: Operation

    OPERATION Hydraulic Connection • Remove the plastic cap FIG 1. Please keep this cap for shipping or storage. • Connect NPT 3/8" hydraulic line to the output port. • If needed the unit comes with an adaptor to attach a 1/4" NPT hydraulic line FIG 2. FIG 1 FIG 2 Air Connection...
  • Page 5 OPERATION Depress the PUMP end of the treadle as shown in FIG. 5, the air motor will be activated to pump hydraulic oil to the system. FIG. 5 FIG. 6 Note: If the pump doesn't work properly at first, it may have air in the hydraulic system. If this happens you will need to prime the hydraulic system.
  • Page 6: Maintenance And Storage

    MAINTENANCE AND STORAGE Add several drops of lubrication to the air-inlet port periodically to lubricate the air motor. When the unit will be stored for a long time without using, please follow the instructions below: • Wipe the entire unit clean. •...
  • Page 7 10,000 PSI 54 oz Air/Hydraulic Foot Pump PROD NO. 030215 MOD NO. 402A Heavy Duty NO. DESCRIPTION QTY. NO. DESCRIPTION QTY. NO. DESCRIPTION QTY. NO. DESCRIPTION QTY. 23 Shock Block 45 Steel Ball 67 O-Ring C-Ring 24 Spring Cap 46 Valve Core...
