HUATEC Radiometer dosimeter FJ-6600
**Notes to Users**:
Please take care of the sensor of the
instrument, which is fragile. Any person
tending to use, maintain or repair the product
shall carefully read this Operation Manual. The
instrument
may
achieve
the
designed
performance only when it is operated in strict
with
the
manufacturer's
compliance
instructions. Please observe the following
suggestions during maintenance and use of the
instrument, so as to extend its service life.
1. Do not drop, knock or violently shake the
instrument;otherwise the detector may be
damaged.
2. In case the instrument is left idle for a long
time, please take out the battery.
3. Please keep the instrument dry during
storage or use, for humidity may cause damage
to it.
www.huatecgroup.com
export@huatecgroup.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FJ-6600 and is the answer not in the manual?

Questions and answers

Related Manuals for HUATEC FJ-6600

Summary of Contents for HUATEC FJ-6600

  • Page 1 HUATEC Radiometer dosimeter FJ-6600 **Notes to Users**: Please take care of the sensor of the instrument, which is fragile. Any person tending to use, maintain or repair the product shall carefully read this Operation Manual. The instrument achieve designed performance only when it is operated in strict with manufacturer’s...
  • Page 2 HUATEC Radiometer dosimeter FJ-6600 4. If the instrument fails to work normally, please sent to designated authorized service. The final power of interpretation owe to our company. The Company reserves the right to upgrade the product or modify this Manual without notification to the user.
  • Page 3 HUATEC Radiometer dosimeter FJ-6600 The instrument adopts non-plug sensor. In case of any malfunction, please contact our specialists. To replace any original part of the instrument with part provided by other manufacturers other than the Company may weaken the safety of the product. Any unauthorized modification or maintenance may result in damage to the instrument.
  • Page 4 HUATEC Radiometer dosimeter FJ-6600 Notes and suggestions to use and operation The instrument provides three single alarming modes, i.e. sound, flash and vibration, and three combined alarming modes, i.e. sound + flash, sound + vibration, and flash + vibration. When the battery is low, please turn off the...

  • Page 5: Table Of Contents

    HUATEC Radiometer dosimeter FJ-6600 Contents 1. Operation panel .......... 6 1.1. LCD display (Figure 1) ......8 1.2. User interface Icons ........ 8 2. Technical parameters ......... 9 3. Functions..........11 4. Operation description of the functional keys ..............11 4.1.
  • Page 6 HUATEC Radiometer dosimeter FJ-6600 parameter setup ..........13 5.1.1. Equivalent dose rate(Figure 2) ... 13 5.1.2. View and set up the EDR alarming mode and alarming value ........14 5.2. Equivalent dose(ED) interface parameter setup ..........18 5.2.1. Equivalent dose(ED) interface ... 18 5.2.2.

  • Page 7: Operation Panel

    HUATEC Radiometer dosimeter FJ-6600 Operation panel Front View www.huatecgroup.com export@huatecgroup.com...
  • Page 8 HUATEC Radiometer dosimeter FJ-6600 Back View The operation panel of the instrument consists of LCD display, Alarm indicating lamp, www.huatecgroup.com export@huatecgroup.com...

  • Page 9: Lcd Display (Figure 1)

    HUATEC Radiometer dosimeter FJ-6600 Pulse indicating lamp,Function "MODE/POWER" Function key"SET/VIEW". The LCD display may show the current time, mode, dose rate, accumulated dose value and battery power. 1.1. LCD display (Figure 1) Figure 1 1.2. User interface Icons Icon Indication...

  • Page 10: Technical Parameters

    HUATEC Radiometer dosimeter FJ-6600 Impulse (acousto-optic indicating signal for different frequencies is given according to radiance) Alarm clock Battery power Dose rate Accumulated dose Dose rate unit (Sievert): µSv/h, mSv/h Accumulated dose unit: µSv, mSv Technical parameters Types of measured Ray: X, γ and β rays...
  • Page 11 HUATEC Radiometer dosimeter FJ-6600 0.01 µSv - 9999Sv Energy ranges of measurement: 40KeV - 3.0MeV Relative errors energy dependence(137Cs): ≤±25% Basic relative errors:: ≤±10% (when 20uSv/h) Adjustable range of alarm threshold level relative to radiation dose rate: adjustable within the range...

  • Page 12: Functions

    HUATEC Radiometer dosimeter FJ-6600 Dimension: 125*55*26 (mm) Weight: 100g (excluding battery) Functions - Alarm of exceeded programmed threshold levels - Retention of maximum EDR - Clock and alarm clock - Light indication for pulse: to give light indications of different frequencies based on the strength of radiation –...

  • Page 13: Introduction To The Keys

    HUATEC Radiometer dosimeter FJ-6600 keys 4.1. Introduction to the keys instrument keys, i.e. "MODE/POWER" "SET/VIEW", shown in (Figure Front View) . 4.1.1. Function of key" MODE/POWER": - Turn on/turn off - Switch measuring modes - Setting selection 4.1.2. Function of key "SET/VIEW":...

  • Page 14: Interface Switch

    HUATEC Radiometer dosimeter FJ-6600 mode will be enabled automatically; or hold down the key "MODE/POWER"when the instrument is off to turn on the instrument. Turn off: hold down the key "MODE/POWER" when the instrument is on to turn it off.

  • Page 15: View And Set Up The Edr Alarming Mode

    HUATEC Radiometer dosimeter FJ-6600 rate is refreshed every second, and the measurement unit will automatically switch to uSv/h or mSv/h according to the value of the equivalent dose rate. Figure 2 5.1.2. View and set up the EDR alarming mode and alarming value In the equivalent dose rate interface, press key "SET/VIEW", and the alarm value of the...
  • Page 16 HUATEC Radiometer dosimeter FJ-6600 Figure 3 Hold down key "SET/VIEW" for 3 seconds, it will enter into the setting interface of alarming mode and alarm value. In this interface, first need to set the alarm mode; if the icon flashing ,it indicates the corresponding function can be set.
  • Page 17 HUATEC Radiometer dosimeter FJ-6600 Figure 5 If it is unnecessary to change the current option, press key "MODE/POWER "to switch to the next function. The mode of the sound, vibration, light and pulse can be set in sequence. When the pulse work indicating icon is flashing, press the key "MODE/POWER"again,...
  • Page 18 HUATEC Radiometer dosimeter FJ-6600 rightmost digit of the alarm value will flash; press key "SET/VIEW", a proper digit from 0 to 9 can be selected;then press key "MODE/POWER"again to set the next bit digit; when all bits of the alarm value have been set,then press key "MODE/POWER"...

  • Page 19: Equivalent Dose(Ed) Interface And

    HUATEC Radiometer dosimeter FJ-6600 Figure 6 5.2. Equivalent dose(ED) interface and parameter setup 5.2.1. Equivalent dose(ED) interface In the equivalent dose(ED) interface, the display shows "DOSE" icon, the current equivalent dose value and unit (Figure 7). The measurement unit will automatically switch among uSv, mSv and Sv according to the equivalent dose value.

  • Page 20: View And Set Up The Alarm Value Of

    HUATEC Radiometer dosimeter FJ-6600 5.2.2. View and set up the alarm value of equivalent dose(ED) In the equivalent dose(ED) interface, press key "SET/VIEW" to show the equivalent dose alarm value and unit, as well as the "DOSE ALARM VALUE" icon (Figure 8).
  • Page 21 HUATEC Radiometer dosimeter FJ-6600 alarm value. After setting of the four digits of the alarm value completed, press "MODE/POWER" again, and the equivalent dose value will flash; at the same time, the "DOSE VALUE" icon will be displayed (Figure 9).
  • Page 22 HUATEC Radiometer dosimeter FJ-6600 current interface. If no operation is done morethan 6 seconds, the instrument will confirm the current setting and return to the equivalent dose interface. Figure 10 Note: the equivalent dose value cannot be restored once deleted. Therefore, please record it before operation.

  • Page 23: Clock Setup

    HUATEC Radiometer dosimeter FJ-6600 Figure 11 In the maximum equivalent dose rate mode, hold down key "SET/VIEW" to enter the reset interface; press key "SET/VIEW" again to select whether to reset; when all digits are zero, it means to reset; when the dose rate is displayed, it means not to reset;...
  • Page 24 HUATEC Radiometer dosimeter FJ-6600 Figure 12 In the clock interface, hold down key "SET/VIEW" to enter the clock setting interface, at this time, the clock can be set. Similar to the setting of alarm value, key "SET/VIEW" can be used to change the digits, and key "MODE/POWER"...

  • Page 25: Alarm Clock Setup

    HUATEC Radiometer dosimeter FJ-6600 Figure 13 After the leftmost digit of month is set, press key "MODE/POWER" to set year (Figure 14). Press key "SET/VIEW", the currently flashing digit can be modified. Figure 14 If no operation is done morethan 6 seconds, the instrument will confirm the current setting and return to the clock interface.
  • Page 26 HUATEC Radiometer dosimeter FJ-6600 "ALARM TIME" icon and preset alarm clock time will be displayed (Figure 15). Figure 15 In the alarm clock interface, hold down key "SET/VIEW" to enter the alarm clock setting interface. First, select whether to turn on the function of alarm clock.

  • Page 27: Explanation Of Other Prompts

    HUATEC Radiometer dosimeter FJ-6600 key "SET/VIEW", and the digital value can be modified; press key "MODE/POWER", it will switch to the next digit. After setting of the four digits is complete, press key "MODE/POWER", and the four digits will flash simultaneously. If...

  • Page 28: Prompt For Err1 And Solution

    HUATEC Radiometer dosimeter FJ-6600 Figure 16 6.2. Prompt for Err1 and solution If the "Err1" icon is displayed (Figure 17), it means the sensor has not detected any signal within 120s. Figure 17 Solutions: 1)Low battery may results in abnormal work of the instrument.

  • Page 29: Maintenance Bond

    HUATEC Radiometer dosimeter FJ-6600 2)The sensor has been damaged or the corresponding circuit fails. If the problem has not been solved by replacing the battery, the instrument shall be returned to the factory for repairs. Maintenance bond The warranty period of the instrument is one year (From the day when you have it).
