SOLIDDRIVE SD1 Desktop Kit-250 Install Instructions

SD1 DESKTOP KIT-250

GETTING STARTED WITH SOLIDDRIVE

Included with the SolidDrive SD1 Desktop Kit-250 for installation
on any horizontal surface:
One (1) SolidDrive SD1 Desktop, SD-250 mini ampli er with
built-in EQ curves, 15V DC power supply, all necessary cabling,
instructions and durable, padded case.
The SolidDrive SD1 Desktop is connected to the SD-250 amp
from the supplied "push-on"connector to the right speaker output
on SD-250. The special silicone rubber pad "grips" any non-po-
rous surface.
The portable SolidDrive SD1 Desktop Kit-250 is to be used with
a laptop computer, portable CD player, or other sound source.
The SolidDrive SD1 Desktop utilizes patented technology to
convey an audio signal into a table or countertop, evenly deliver-
ing sound from the entire surface.
Warning
SolidDrive products must be installed by a professional audio installer/contractor. For safety
and for optimum audio performance, installer must follow all directions issued by SolidDrive.
Install Instructions For:
SD1 Desktop Kit-250.

SETUP

1. Connect the power supply to the SD-250 ampli er.
2. Plug the power lead from the 15V DC power supply into the DC
IN of the ampli er. Connect the SolidDrive with "push-on" connec-
tor to the speaker output of the SD-250. If one drive is used move
jumper setting to MONO.
3. Connect audio source (MP3 player, computer, etc.) to stereo
mini input. Make sure INPUT SELECTOR is set to STEREO MINI.
4. If outside the USA, use appropriate outlet adapter and plug
into wall outlet.
5. Adjust volume on computer or other audio source to desired
level. The audio output signal level will vary from computer to
computer. You can use the volume control on the SD-250.
6. Adjust the proper electronic EQ on the SD-250 [WOOD,
DRYWALL (gypsum), GLASS, or FLAT] for the surface type the
SolidDrive will be used on.
© 2014 MSE Audio. All rights reserved. PN INS-SD-250 Rev01.27.12
Avis
Les produits SolidDrive doit être installé par un installateur professionnel audio/contractuer.
Pour plus de sûreté et pour des performances audio optimales, l'installateur doit suivre toutes
les instructions émises par SolidDrive.
