AOG 11-31-SSD Install Specifications

Door & drawer
Hide thumbs
1
2
3
4
5
6

Advertisement

Table of Contents

INSTALLER:
Leave these instructions with consumer.
CONSUMER: Retain for future reference.
Important:
READ THESE INSTRUCTIONS CAREFULLY BEFORE STARTING INSTALLATION
• When installing this unit directly below another unit, only install with AOG built-in products.
• For proper installation, be sure to use the correct cutout dimensions as specifi ed for your specifi c
model number.
• It is recommended that silicon caulking (not supplied) is applied around the back of the door/
drawer cabinet trim before sliding the cabinet assembly into the opening.
• Some models may include an additional owner's manual.
• When used for propane cylinder storage, a louvered door model is required.
CAUTION: Make sure the enclosure is properly vented. See your grill owner's manual for venting
requirements, or consult your local codes.
WHEN USING A PROPANE TANK CYLINDER:
• Never locate a cylinder under or near a grill unless suffi cient ventilation and shielding is
provided to prevent any heating of the cylinder regulator and hose. Refer to any additional
instructions included with your door (and/or your grill owner's manual) for the required installation
method of propane tank cylinders.
• FOLLOW ALL THE SAFETY WARNING AND INFORMATION FOUND IN THESE
INSTRUCTIONS, ON YOUR PROPANE CYLINDER, AND IN YOUR GRILL OWNER'S MANUAL
ABOUT SAFE STORAGE AND USE OF PROPANE GAS.
REV 3 - 1812041115
Model # 13-31-SSD Shown
GENERAL INFORMATION
American Outdoor Grill • PO Box 4053 • La Puente, CA 91747
DOOR & DRAWER
INSTALL SPECIFICATIONS
This unit is to be installed by a qualifi ed,
professional service technician.
1
Model # 17-24-SSDR Shown
WARNING
L-C2-360
