One-Tool Portable Video Borescope
Model:OTE6100Q
OTE6100Q portable video borescope is for
the global automotive service market the
latest launch of an important product,
specifically for the detection of automobile
evaporation box, combustion chamber,
three catalytic sensors and other difficult to
enter the narrow bending space. The
product has a unique temperature
protection. It is equipped with an portable
host, make it easy for users to accurately
make probe depth into the narrow space,
and it will display the clear video and
pictures on monitor .With advanced scalable
accessories and real-time temperature
display to meet your diverse testing needs.
Advertisement
Summary of Contents for One-Tool OTE6100Q
- Page 1 One-Tool Portable Video Borescope Model:OTE6100Q OTE6100Q portable video borescope is for the global automotive service market the latest launch of an important product, specifically for the detection of automobile evaporation box, combustion chamber, three catalytic sensors and other difficult to enter the narrow bending space.
-
Page 2: Product Appearance
Product Appearance 1、3.5 inch LCD Monitor Item Power on/off TF Card USB interface TV output Up/Zoom Setting Taking Picture Video/OK Down/Rotation Preview/Playback LED adjuster... - Page 3 Product Appearance 2、Handle Item Flexible tube female interface Rotatable connector photo shortcut button Monitor slot 3、Snake Tube Item Probe snake tube Fixed nut Flexible tube male interface...
- Page 4 Operation Guide • 1、Install monitor： • Install the monitor on the handle as shown, and make sure the installation not loose. • 2、Install snake tube： • Install the snake tube male interface into the monitor famale interface,screwing clockwise,and make sure the installation not loost.
- Page 5 Operation Guide 3、Monitor • 3.1 Insert TF card Before using the device, please insert TF card. Note: In order to ensure device on normally working, please try to use the nameplate C4 and above to operate. After insert the card, it is best to format it. 3.2.
-
Page 6: Specification
Specification Monitor Camera Screen Size： 3.5’’ TFT LCD Monitor Video resolution: AVI (640x480) 5.5mm /8.5mm Probe Photo resolution: JPEG (640x480) Diameter of camera Frame Rotation: 180° Rotation & Mirror image 5.5mm /8.5mm Lens freeze frame: Resolution 720*576 Zoom: 4x Variable Digital Zoom Menu language: Traditional Chinese, Simplified 60°... -
Page 7: Application Environment
Application Environment For professional service personnel, this products can be used in the case of non-disassemble or damage the instrument, used to detect the human eye can not see the place. Can be precision instrument testing, engine maintenance, vehicle repair, pipeline maintenance, building maintenance and air conditioning evaportaor maintenance and so on. - Page 8 Warning! Important safety matters: Please do not use our camera with other manufacturers monitor,even same interface. Do not use the product in certain areas where it may be exposed to a wire or charged area. The exposed metal parts can be electrically conductive and may cause unexpected accident.
-
Page 9: Guarantee Terms
Guarantee terms • Thank you for choosing this product, this product is a well-designed, durable video industrtial endoscope. Under normal use and maintenance should be able to play its superior performance. Within six months from the date of purchase, if there is any damage caused by the manufacturing process or components, we will provide free maintenance service for the licensee and replace the parts as appropriate.
