USER MANUAL FOR YOUR
HUL136.1 136 litre
Built-under larder
fridge
NOTE
: This User Instruction Manual contains important
information, including safety & installation points, which will
enable you to get the most out of your appliance. Please keep it
in a safe place so that it is easily available for future reference, for
you or any person not familiar with the operation of the appliance.
DD 26/08/14

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HUL136.1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Iberna HUL136.1

  • Page 1 USER MANUAL FOR YOUR HUL136.1 136 litre Built-under larder fridge NOTE : This User Instruction Manual contains important information, including safety & installation points, which will enable you to get the most out of your appliance. Please keep it in a safe place so that it is easily available for future reference, for you or any person not familiar with the operation of the appliance.

  • Page 2: Table Of Contents

    Contents Environmental note Important safety information 4–5 Specifications of your refrigerator Dimensions Description of the appliance Description of the product features Using your refrigerator 9-10 Before switching on During first use Turning on the appliance and setting the thermostat Arranging and storing food in the fridge section 11-12 Cleaning and maintenance 12-14...

  • Page 3: Environmental Note

    Environmental note Note : Before discarding an old appliance, switch off and disconnect it from the power supply. Cut off and render any plug useless. Cut the cable off directly behind the appliance to prevent misuse. This should be undertaken by a competent person. Disable the door lock to make sure that children cannot get stuck inside the appliance.

  • Page 4: Important Safety Information

    Important safety information Your safety is of the utmost importance to us. Please make sure that you read this instruction booklet before attempting to install or use the appliance. If you are unsure of any of the information contained in this booklet, please contact the Advice Line.
  • Page 5 Child safety o Packaging material should be kept away from children. o Children should not be allowed to touch the controls or play with the appliance. General safety o Do not pull on the power supply cable to remove the plug from your mains supply socket.

  • Page 6: Specifications Of Your Refrigerator

    Specifications of your refrigerator o Total gross capacity: 136 litres o Total net capacity: 133 litres o Automatic defrost o Adjustable thermostat o Internal light o 3 Safety glass shelves o Salad crisper o Bottle rack o General door rack o Reversible door o Door-on-door fittings Dimensions of appliance...

  • Page 7: Description Of The Appliance

    Description of the appliance 1) Refrigerator shelf 2) Safety glass salad crisper shelf 3) Salad crisper 4) Thermostat dial 5) Bottle rack 6) Butter and cheese rack...

  • Page 8: Description Of The Product Features

    Description of the product features 1) Shelves o The shelves may be placed in any of the guide slots within the interior of the appliance. They are protected from sliding out. o To remove a shelf: Take off all of the items that are stored on the shelf that you want to remove.

  • Page 9: Using Your Refrigerator

    Using your refrigerator Before switching on o Make sure that it has been installed by a suitably qualified person, as per the information contained in the installation instructions. o After delivery, wait for eight hours before connecting the appliance to your mains supply. This will allow any refrigerant gasses that may have been disturbed during the transportation process to settle.

  • Page 10: Turning On The Appliance And Setting The Thermostat

    Turning on the appliance and setting the thermostat You switch on your appliance by connecting it to your mains supply and setting the thermostat. The thermostat dial is located at the base of the refrigerator. o The thermostat automatically regulates the temperature inside the refrigerator, depending on what number you have turned the thermostat control knob to.

  • Page 11: Arranging And Storing Food In The Fridge Section

    Arranging and storing food in the fridge section o Warm food or evaporating liquids should not be stored in your refrigerator, as this will increase the humidity inside of the appliance. o All foods should be wrapped or covered, this is particularly important if the food has a strong flavour.

  • Page 12: Cleaning And Maintenance

    o Milk bottles should have a cap on them and be stored on the bottle shelf that sits in the door. o Garlic, potatoes, onions and bananas should only be stored in a refrigerator IF they are stored in airtight containers.

  • Page 13: Defrosting The Refrigerator Compartment

    Defrosting the refrigerator compartment o Defrosting occurs automatically in the refrigerator section during operation. The defrost water is collected by the evaporating tray and evaporates automatically. o The evaporating tray and defrost water drain hole should be cleaned periodically with the defrost drain plug. This will prevent water from collecting in the bottom of the refrigerator, instead of flowing down the defrost drainage channel and drain hole.

  • Page 14: Installation

    o Replace the light cover and wait 5 minutes before reconnecting the plug to the power supply. Installation IMPORTANT: Before installation usage, read all the instructions and make sure that the voltage (V) and the frequency (Hz) indicated on the rating plate are exactly the same as the voltage and frequency in your home.

  • Page 15: Positioning

    o When the connection is completed, no stray strands or cut wire should be present. The cord clamp must be secured over the outer sheath. Positioning o It is advisable that your appliance is only installed in a location where the ambient temperature of the room, corresponds with the climate classification that is stated on the rating plate of your appliance.

  • Page 16: Aperture And Appliance Dimensions

    Aperture and appliance dimensions o The diagram above shows the aperture size that you will need to be able to install your appliance. Supplied installation components o The diagrams below show the contents of the supplied installation kit and the tools you will require to carry out the installation process.

  • Page 17: Installing Your Fridge

    Tools required 7) Water gauge 8) Wrench 9) Setsquare 10) Screwdriver Installing your refrigerator If you need the appliance door to open from the other side, then please reverse the door before commencing the installation process. (See “Reversing the door” section). o Remove the screw (5) at the top of the appliance and place the top bracket (6) in its place.
  • Page 18 o Fix the bracket with the screw (5). o Take out the gasket (11) located on the side panel and remove the protective tape. o Stick the gasket on the reverse side of the door hinges of the appliance. o You should use a water gauge (7) to ensure the appliance is level.
  • Page 19 o Slide the appliance into the kitchen unit and align the hinge surface with the front surface of the kitchen unit using a setsquare (9). o Screw the hinges and metal bracket to the kitchen unit using screws (1). o Unscrew and remove the nuts and washers from the appliance door.
  • Page 20 o Dimension B: Measure from the underside surface of the kitchen unit to the bottom of the door hang. o Dimension C: Measure from the underside surface of the kitchen unit to the top of the next unit door. o Subtract measurement C from measurement B. Place the door hang (2) using this dimension for the vertical position and place it in the centre for the horizontal position.
  • Page 21 o Close the door and check the alignment with the other cabinet doors. Make the adjustment of the unit door by screwing or unscrewing the adjustment bolts using a screwdriver (10) for vertical adjustment and by the help of the slots on the door hang for other directions.

  • Page 22: Ventilation Requirements

    o Slide the hang cover (4) onto the door hang. o Position the plinth providing a minimum 25 mm gap between the cabinet door and fix it. NOTE: There are ventilation slots in the front of this appliance. If the height of the plinth covers any of the ventilation slots, then a cut-out must be made in the plinth to ensure that all of the ventilation slots are exposed.

  • Page 23: Reversing The Door Of Your Appliance

    Reversing the door of your appliance Caution! After unscrewing any of the fixing hinges, hold the door to prevent it from falling and causing damage. Any parts that you remove from the appliance whilst reversing the door, should be retained for later use. o Unscrew the screws on the front surface of the appliance door.

  • Page 24: Troubleshooting

    o Move the hole plugs to the opposite side. o Assemble the door upper hinge and door lower hinge to the opposite corners of their original position. o Assemble the appliance door. Troubleshooting IMPORTANT: If your fridge appears not to be operating properly, before contacting the Advice Line, please refer to the checklist below.
  • Page 25 Ice has formed on the inner back wall of my fridge o Check that food has not been pushed too far back inside the appliance, so that it is in contact with the inner back wall. There is water in the base of the fridge or leaking out of my fridge.

  • Page 26: Technical Data

    Technical Data Manufacturer IBERNA Model Number HUL136.1 Product Category 1 – Refrigeration Energy Efficiency Class (1) Annual Energy Consumption (2) 115 kWh Storage Volume of Fridge 133 litres Compartment Storage Volume of Freezer Compartment Star Rating Frost Free Compartments Fridge...

  • Page 28: Contact Details

    United Kingdom 6 Bennet Road, Reading, Berkshire RG2 0QX United Kingdom Customer Care 0844 692 3605...
