Summary of Contents for XS Scuba PN RG100
- Page 1 SERVICE AND REPAIR MANUAL SPIRIT REGULATOR PN RG100 Service & Repair Manual Revised - 02/11...
-
Page 2: Table Of Contents
Spirit Regulator Contents Section 1 - Introduction Warnings, Cautions, & Notes ........................ 3 Scheduled Service..........................3 EAN/ Nitrox Service ..........................3 Facility Requirements ..........................4 Specialty Tools ............................5 Section 2 - Preliminary Inspection External Inspection ..........................6 Immersion / Leak Test ........................... 6 Intermediate Pressure Test ........................ -
Page 3: Section 1 - Introduction
Refer to the instructions provided in the XS Scuba Authorized Service Document, titled - Regulator Parts Cleaning Procedures. -
Page 4: Facility Requirements
Spirit Regulator Facility Requirements As an Authorized XS Scuba Dealer, your customers expect you to provide top-notch overhaul service, both before and after the sale. Next to airfills and gas blending, it is the single most important com- modity your store can provide. -
Page 5: Specialty Tools
1/4" Nut Driver PN #11-168-500 Small (.02) Blade Screwdriver PN #11-133-500 Cristo Lube PN #MS150 Galion, OH 44833 Hakko Side Cuts, 5" PN #16-020-500 Phone: 419-468-2212 Snap Ring Pliers www.scubatools.com 11/16" Open End Wrench 3/4" Open End Wrench Copyright ©2011 XS Scuba... -
Page 6: Section 2 - Preliminary Inspection
Spirit Regulator Preliminary Inspection External Inspection 1. Closely examine the conical filter to check for any signs that contaminants have entered the system, including sea water, rust, or aluminum oxide. NOTE: A green discoloration of the filter indicates that moisture has entered the regulator, and internal corrosion has possibly occurred. -
Page 7: Intermediate Pressure Test
2,500 - 3,000 psi. Close the supply valve and depress the second stage purge button to depressurize the system before at- tempting to perform any disassembly. ▼ After completing the Preliminary Inspection, proceed to Section 3 – Disassembly Copyright ©2011 XS Scuba... -
Page 8: Section 3 - Disassembly Procedures
Spirit Regulator Disassembly Procedures General Guidelines ▼ Prior to performing any disassembly, check to ensure that the service facility is well equipped with all the tools and parts needed to perform a complete service from start to finish. DO NOT attempt to perform the service unless all of the required tools and parts are available. -
Page 9: First Stage Disassembly
To ensure the best available protection against damage, XS Scuba specifically recommends the Gripmaster Vise, available from Peter Built Co. - Page 10 Spirit Regulator 6. Disassembly of the Yoke Connector a. Loosen the yoke screw several turns counter-clock- wise. Place a 1" Yoke Retainer Socket (Peter Built PN 20-156-500) inside the yoke and over the hex fea- tures of the yoke retainer(8). Pass a Breaker Bar (PN 20-157-500) through the yoke, and tighten the yoke screw lightly snug over the dimpled feature (see Fig.
- Page 11 Do not attempt to polish the sealing surface of the orifice cone. ▼ After completing the disassembly of the first stage, proceed to the following procedure - Second Stage Fig. 6 – HP Cone Inspection Disassembly. Copyright ©2011 XS Scuba...
-
Page 12: Second Stage Disassembly
Spirit Regulator Second Stage Disassembly CAUTION: Whenever possible, use only plastic or brass O-ring tools for removing O-rings in order to prevent damage to the sealing surface. Steel instru- ments, such as dental picks, can easily damage the sealing surface of a softer brass part, causing irrepa- rable leakage and requiring the part to be replaced with new. - Page 13 NOTE: The orifice is O-ring sealed, and it will remain inside the air barrel after it has been unthreaded. The following step must be performed to remove the orifice without damaging its polished sealing surface. Copyright ©2011 XS Scuba...
- Page 14 ▼ After completing the disassembly of the first and second stages, refer to the instructions provided in the XS Scuba Authorized Service Document, titled - Regulator Parts Cleaning Procedures. Spirit Regulator Service and Repair Manual...
-
Page 15: Section 4 - Reassembly Procedures
CAUTION: The use of aerosol spray or petroleum based lubricants must be strictly avoided. The propellant gas or petroleum base may attack or weaken plastic or rub- ber parts. Use all replacement parts provided in the XS Scuba Authorized ▼ Dealer parts kit. Copyright ©2011 XS Scuba... -
Page 16: First Stage Reassembly
First Stage Reassembly WARNING: DO NOT attempt to use any other manu- facturer's part as a substitute for any XS Scuba part, regardless of any similarity in shape, size, or appear- ance. Doing so may render the product unsafe, and could result in serious injury or death. - Page 17 Mate the filter housing into the inlet port of the first stage body, and turn clockwise by hand until snug. Apply a torque wrench with a m" deep socket to tight- en the filter housing to a torque measurement of 17 foot-lbs (±1). (See Fig. 15.) Copyright ©2011 XS Scuba...
- Page 18 Spirit Regulator c. Fit the handwheel(3f) over the filter housing with the male threaded side facing up. d. Install both O-rings(3c&3a) onto the filter retainer(3b). Mate the filter retainer into the filter housing, and turn clockwise by hand until snug. Apply a torque wrench with 4"...
-
Page 19: Second Stage Reassembly
Second Stage Reassembly WARNING: DO NOT attempt to use any other manu- facturer's part as a substitute for any XS Scuba part, regardless of any similarity in shape, size, or appear- ance. Doing so may render the product unsafe, and could result in serious injury or death. - Page 20 Fig. 26 – Lever Installation NOTE: To better control the orientation of the poppet inside the air barrel while the lever is being installed, XS Scuba recommends using the Poppet Align/ Orifice Preset Tool (P/N 20-785-400), available from Peter Built Co. (See Fig. 28.) 8.
- Page 21 LP seat. (See Fig. 32.) NOTE: To pre-set the orifice at exactly the correct depth inside the air barrel, XS Scuba recommends using the Poppet Align/ Orifice Preset Tool (P/N 20- 785-400), available from Peter Built Co. Complete Fig.
-
Page 22: First Stage Intermediate Pressure Test
Spirit Regulator Final Testing Procedures CAUTION: If the regulator will be used with EAN/ Nitrox, it is important to pressurize and flow test the regulator using only hydrocarbon-free gas. The regulator will otherwise become contaminated with hydrocarbons if normal compressed air is used. Industrial grade compressed Nitrogen is strongly recommended as a lower cost alternative to EAN/ Nitrox for the purposes of flow testing. -
Page 23: Second Stage Adjustment And Flow Test
If airflow cannot be heard, it will be necessary to initiate a slight leak between the orifice and poppet. Press the knurled knob inward to engage the slotted drive of the Inline Adjustment Tool with the head of Copyright ©2011 XS Scuba... -
Page 24: Subjective Breathing Test
Spirit Regulator the orifice inside the inlet fitting. Then, turn the orifice slightly counter-clockwise while lightly depressing the purge cover to prevent wear on the seat. Do not adjust any further than is needed to establish a slight leak. 5. Hold the drive of the Inline Adjustment Tool engaged with the orifice. -
Page 25: Flowbench Testing (Optional)
Disinfect the mouthpiece, and dry the regulator completely with a clean towel. This completes the overhaul service procedures for the Spirit regulator. Copyright ©2011 XS Scuba... -
Page 26: Troubleshooting Guide
Do not attempt to perform partial service if the regulator shows any signs of use. For additional troubleshooting assistance, contact your XS Scuba distributor. Spirit Regulator Service and Repair Manual... -
Page 27: Second Stage
1. Replace with new. Water entering second stage 2. Mouthpiece worn or damaged. 2. Replace with new. 3. Adjustment knob or O-ring damaged, 3. Disassemble and inspect, replace or reassemble as required. incorrectly installed, or worn. Copyright ©2011 XS Scuba...
