SECURECOM SC-F3G User Manual

Remote monitoring communicator
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
S
C
-
F
3
G
S
C
-
F
3
G
User Manual 1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SC-F3G and is the answer not in the manual?

Questions and answers

Summary of Contents for SECURECOM SC-F3G

  • Page 1 User Manual 1.0...

  • Page 2: Table Of Contents

    Before You Start ..........................5 7.1 Monitoring Receiver ........................5 7.2 GPRS/3G SIM Card and APN ......................5 Setting SC-F3G ..........................6 8.1 Installing the 3G DATA Setup application..................6 Configuring SC-F3G .......................... 6 9.1 Information and administration area .................... 6 9.2 Module Status ..........................

  • Page 3: Introduction

    Introduction The SC-F3G device is a modern remote monitoring communicator which operates on the 3G/2G mobile network, converts the Contact ID signals of alarm control panels into SIA DC-09 digital format and forwards to the predefined remote monitoring station’s receivers. The signals are embedded in TCP or UDP packages and sent over WCDMA and GPRS network.

  • Page 4: Device Configuration

    Device Configuration Part Description ANTENNA UMTS / GSM network antenna Connector: SMA, Impedance: 50 ohm, Frequency: 900/1800/2100 MHz SIM CARD HOLDER For mobile network connection Type: M2M data card, Dimension: 2FF mini SIM Backup power supply Li-Ion BATTERY (optional) In case of power supply outage or sabotage. Type: SANYO UR18650F Main power supply DC POWER (DC+/DC-) Rated voltage: DC 9-30V, Rated current: max.

  • Page 5: Status Led Signals

    Test period 7.2 GPRS/3G SIM Card and APN For using the SC-F3G device a GPRS/3G SIM card is needed. During the configuration you need to add the APN (Access Point Name) of the GPRS/3G SIM card and the following possible configuration parameters.

  • Page 6: Setting Sc-F3G

    The installation file of 3G DATA Setup application can be found on the flash drive of the device. Installation steps: 1. Connect the SC-F3G communicator to the computer with the USB cable which can be found in the package 2. After the computer recognized the device as a normal flash drive, select and copy the 3G_DATA_setup.exe to the PC...

  • Page 7: Module Status

    APN (Private APN) User Add the user name for the APN if necessary Password Add the password for the APN if necessary 9.4 Latest Events In this window the communication events of the SC-F3G device can be tracked.

  • Page 8: Monitoring Station Settings

    6 characters long Object identifier The self identifier of the SC-F3G device (4 characters long). Replace If it is enabled than the SC-F3G exchange the alarm control panel’s identifier, to given self object identifier. obtained identifier YES: exchange, NO: not change...

  • Page 9: Communication Event Codes

    9.7 Status Event Codes Setting the Contact IDs for the communicator’s own events. The event codes are standard 3 characters long ( 1 and 3, for “event” and „restore” are added automatically). If the event code field is blank, the event is not sent to the monitoring station. Supply failure Power supply is damaged or failed.

  • Page 10: Signal Transmission Logic

    10.2 Signal Transmission Logic If both monitoring stations are entered, the direction if signal sending can be: • Automatic: MS1 receiver is the primary, MS2 is the secondary, and every signal is forwarded to the MS1 until it is available. If MS1 is unavailable, every signal is forwarded to MS2. As the MS1 receiver will be available, so the test report is sent by MS1, it becomes primary again.

  • Page 11: Mounting

    Mounting 1. step: Fixing the back plastic back plate 2. step: Panel fixing and wiring...
  • Page 12 3. step: Releasing the wall fixing screw, flipping for the front plastic case fixing and screwing 4. step: Wall fixing with plastic cover...

  • Page 13: Technical Details

    Freq. Bands 3G: 900/2100MHz (4G LTE optional) Antenna: 3G SMA male PSTN landline backup Alarm transmission Interface application to monitoring software SECURECOM interface (SIA to Sur-Gard) Two wire interface via terminal block Dial capture interface to alarm panel Line voltage: Loop current:...
