- Page 1 Phantom Key Push Button Ignition System Instruction Part #90577 For Installing: Part #’s 55000, 55001, 55002,...
- Page 2 If you have any questions concerning the installation of this harness, feel free to call Painless Performance Products' Tech Line at 1-800-423- 9696. The Tech Line can be reached from 8 A.M. to 5 P.M. central time, Monday through Thursday, and 8 A.M. to 4:30 P.M. on Fridays.
- Page 3 Factory schematics of the starting system and ignition switch will be greatly useful in connection of this Painless product. They will make understanding each wire function easier and will save you a lot of time that would otherwise be used trying to identify wires at the ignition switch with a volt meter.
-
Page 4: Table Of Contents
TABLE OF CONTENTS PAGE # SECTION INTRODUCTION CONTENTS OF THE PAINLESS KIT TOOLS NEEDED PRE-INSTALLATION GUIDELINES INSTALLATION Push button Mounting Module & Relay Mounting Harness Connections KEY FOB MODES, INFORMATION, & OPERATION TESTING THE INSTALLATION PROGRAMMABLE MODES Key Fob Learn... -
Page 5: Introduction
This install manual is broken down into sections: Introduction - provide simple clarification of the Phantom Key Product Contents of the Painless Kit – lists parts your Phantom Key Kit supplies Tools Needed - lists all things required to properly install the Phantom Key ... -
Page 6: Contents Of The Painless Kit
Refer to the Contents Figure (below) to take inventory. See that you have everything you are intended to have in this kit. If you find that anything is missing or damaged, please contact the dealer where you obtained the kit or Painless Performance at (800) 423-9696. - Page 7 SMALL PARTS Included with the Painless harness is a parts kit containing insulated ring terminals. These terminals have a semi-transparent insulation that is heat shrinkable to provide a weatherproof connection. The un-insulated splices are to be used in conjunction with the supplied heat shrink.
-
Page 8: Tools Needed
TOOLS NEEDED In addition to your regular hand tools, you will need, at least, the following tools: Wire Crimping and Stripping Tools: This style of hand crimper can be purchased from just about any local auto parts store, home improvement store or can also be purchased online. -
Page 9: Pre-Installation Guidelines
PRE-INSTALLATION GUIDELINES At this time identify the wires of the chassis harness you will be connecting to. A factory schematic and/or a voltmeter will help accomplish this. You may find that there are extra wires going to your ignition switch that the Phantom key does not support. In most causes these are ground wires to key buzzers and indicator lights in the dash. -
Page 10: Installation
The Phantom key will not replace these factory installed modules; they must be used in conjunction with this Painless product. If your ignition switch key has one of these ID chips it must remain in or close to the ignition for everything to work properly. - Page 11 Before any installation takes place, decide on a good location for the module. This mounting point must be inside the vehicle. The Phantom Key module is not designed to hold up to the environment found inside an engine compartment or in any other place outside the vehicle.
-
Page 12: Module & Relay Mounting
The programming switch, the small red momentary switch seen in the photo, does not have to be permanently mounted. However, if it is not permanently installed, the Module will need to be mounted in such a way you will be able to plug the small 2 pin connector into the module and still be able to route the button to the driver seat area. -
Page 13: Harness Connections
SPST stands for single pole single throw. These relays do not have a functional 87a pin, although some do have two 87 pins. The relays provided in the kit that are printed with the “PAINLESS” logo are SPST relays. The Accessory and the Park Light relays use this type of relay. - Page 14 routing takes place, that way you can group wires together instead of routing each wire individually. At this time you will also need to determine how you are going to make connections at the ignition switch. You can completely remove the ignition switch (if you do not need to bypass any kind of column lock or factory installed security) or you can use either variation of the “Quick Connect Method”...
- Page 16 10 gauge red wire from the Phantom Key to the battery power wire. If you are doing this install on a vehicle equipped with a Painless chassis harness this battery power wire may be printed with circuit number #934.
- Page 17 If you are doing this install on a vehicle equipped with a Painless chassis harness this wire going to the “Coil” fuse on the fuse block will be printed with circuit number #931.
- Page 18 12 gauge brown wire from the Phantom Key to the accessory power wire. If you are doing this install on a vehicle equipped with a Painless chassis harness this wire going to the accessory circuits of fuse block will be printed with circuit number #932.
- Page 19 Quick Connect Method The “Quick Connect Method” can be used in connecting the wires of the Phantom Key to the wires of the ignition switch ONLY IF a key is being used in the ignition The “Quick Connect Method” of connecting the Phantom Key requires less wire routing and less cutting of your existing chassis harness.
- Page 21 (if you have integrated brake/turn lights), or towards a brake light. If you are installing this into a vehicle equipped with a Painless chassis harness the brake switch output may have circuit #918 printed on it.
- Page 22 If you are installing this into a vehicle equipped with a Painless chassis harness the wire of the park light circuit may have #927 printed on it. Do not get this Brown wire confused with the...
- Page 23 Ensure your routing is correct and cut the 16 gauge brown wire coming from the Park Light relay to length and strip ¼” of insulation from the wire. Using a blue Posi-Tap from the parts kit, and the procedure for installing the Posi-tap on p.
-
Page 24: Key Fob Modes, Information, & Operation
CAUTION: AT THIS TIME THE BATTERY MAY BE RECONNECTED. THE BATTERY SHOULD NOT TO BE RECONNECTED UNTIL ALL CONNECTIONS HAVE BEEN DOUBLE CHECKED AND ANY UNUSED WIRES OF THE IGNITION SWITCH AND PHANTOM KEY MODULE HAVE THE ENDS TAPED TO AVOID SHORTING TO GROUND. KEY FOB MODES, INFORMATION, &... -
Page 25: Testing The Installation
Any spare key fobs should be kept in AUTOMATIC mode to preserve battery life. The battery that powers the key fob is a CR2030 that typically carry a 1 year+ life expectancy. Painless does not stock replacement batteries, however, most drug stores and large retailers carry them. -
Page 26: Programmable Modes
Ensure the vehicle is in park or neutral, apply the brake, and push and hold the stainless push button, this should engage the starter solenoid and crank for as long as the button is held. If your engine fails to start during the first crank, you will need to press the button twice and re-try. - Page 27 STARTER DELAY- This is the amount of time between when the module activates the Ignition circuit before it will engage the starter solenoid. You have the option of selecting 0, 3, or 7 seconds. This is useful for vehicles that need to prime the fuel system and build fuel pressure before startup or even for diesel applications that need glow plugs heated before start up.
-
Page 28: Key Fob Learn
#PP-495. (this part is sold by Painless direct and not through our dealers, contact Painless to order) The 2 key fobs provided with the Phantom Key have already been programmed to your module. Put the system in Accessory mode. This is done by pressing the stainless push button one time without applying the brake. -
Page 29: Emergency Bypass
Within 5 seconds of the LED turning solid, push and hold down the Lock button of the key fob you wish to program to the module. The LED will flash 3 times indicating the new key fob has been learned. ... - Page 30 Chassis harnesses, fuel injection harnesses, and Trail Rocker units are covered under a lifetime warranty. All other products manufactured and/or sold by Painless Performance are warranted to the original purchaser to be free from defects in material and workmanship under normal use. Painless Performance will repair or replace defective products without charge during the first 12 months from the purchase date.
