- Page 1 OV1020 | Part No. 107885 OV1020 HEIGHT ADJUSTABLE TABLE USER GUIDE...
- Page 2 PRODUCT OVERVIEW User Guide: OV1020 OV1020 HEIGHT ADJUSTABLE TABLE FEATURES • Full table base (add your own work surface) • Meets BIFMA X5.5 standards • UL 962 approved • Easy-order with one part number • Lift capacity up to 250 lb.
-
Page 3: Table Of Contents
TABLE OF CONTENTS User Guide: OV1020 TABLE OF CONTENTS Parts Diagram Independent Table Table with Anti-Sag Bar Safety Information Assembly Instructions 8-11 Operation Initialization and Reset Handswitch Operation Troubleshooting Unit Errors Technical Data Warranty Standards & Certifications This manual explains how this sit-stand desk is assembled, used, and maintained. -
Page 4: Parts Diagram
PARTS DIAGRAM User Guide: OV1020 OV1020 PARTS DIAGRAM INDEPENDENT TABLE For tables up to 60" PARTS Qty/Package 1. Column 2. Handswitch 3. Control Box 4. Power Cord 5. #10 x ¾" Screw 4 | OV1020... - Page 5 PARTS DIAGRAM User Guide: OV1020 TABLE WITH ANTI-SAG BAR For tables over 60" PARTS Qty/Package 1. Column 2. Handswitch 3. Control Box 4. Power Cord 5. Anti-Sag Bar 6. #10 x ¾" Screw OV1020 | 5...
- Page 6 PARTS DIAGRAM User Guide: OV1020 SAFETY INFORMATION IMPORTANT SAFETY INSTRUCTIONS Save these instructions. DANGER To reduce the risk of electric shock: Always unplug this furnishing from the electrical outlet before cleaning. WARNING: To reduce the risk of death, serious injury, or property damage, read and follow this safety information and the provided instructions when assembling this product.
-
Page 7: Safety Information
SAFETY INFORMATION User Guide: OV1020 DO NOT OVERLOAD DESK To prevent table from tipping or collapsing, make sure the desk frame is not overloaded by the weight of tabletop and objects on table. Evenly distribute load; excess loads near edges can reduce stability and lead to tip over. - Page 8 The assembly of the table frame to be made in accordance with this manual. Changes to the table frame or improper use may affect the safety, function, and life of your product. This manual is for all sit-stand tables from the OV1020 series. ASSEMBLY OVERVIEW 1.
-
Page 9: Assembly Instructions
ASSEMBLY INSTRUCTIONS User Guide: OV1020 ASSEMBLE THE COLUMNS TO THE WORK SURFACE Center the columns front to back on the work surface. Use the #10 x ¾" screws to fasten the top support onto the table top. Be sure motor boxes are mounted 1.5" from edge of work surface. - Page 10 ASSEMBLY INSTRUCTIONS User Guide: OV1020 FASTEN THE CONTROL BOX AND HANDSWITCH TO THE TABLE TOP Make sure the control box and handswitch are fastened in a location where all the cables will connect without being in tension. Be sure to use approved screws per the table top supplier.
- Page 11 ASSEMBLY INSTRUCTIONS User Guide: OV1020 CONNECT THE HANDSWITCH (HS) CABLE TO THE CONTROL BOX CONNECT THE SUPPLIED POWER CORD (AC) TO THE CONTROL BOX ATTACH ALL CABLES TO THE TABLE FRAME OR ON THE UNDERSIDE OF THE TABLE TOP Attach cables in order to avoid any damage during operation.
-
Page 12: Operation
OPERATION INFORMATION User Guide: OV1020 OPERATION INFORMATION INITIALIZATION/RESET The desk must be initialized/reset after any of the following: - After assembly - After disconnection from the power supply - After any impact on the table top. To initialize/reset, move the table to the lowest position by pressing the DOWN button on the handswitch until the columns reach the lowest position. -
Page 13: Troubleshooting
TROUBLESHOOTI User Guide: OV1020 TROUBLESHOOTING UNIT ERROR CODE SOURCE SOLUTION No power supply Plug in the power cord or check the connection Table does not on the control box move No connection or a loose Verify the plug connections of the motor cable... -
Page 14: Technical Data
TROUBLESHOOTING User Guide: OV1020 TECHNICAL DATA GENERAL CONTROL BOX Power supply 120 VAC ±10% / 60 Hz Standby power consumption, primarily <0.3 W Operating temperature 0-35°C Protection class IP 20 Maximum power output 240VA/24V TWO-COLUMN FRAME WITH CONTROL BOX Maximum lift capacity 250 lb (≈... -
Page 15: Warranty
TROUBLESHOOTING User Guide: OV1020 STANDARDS & CERTIFICATIONS The drive system is tested according to the following standards: UL 962 Issued: 2019/05/21 Ed: 4 Household and Commercial Furnishings CSA C22.2#68 Issued: 2019/05/21 Ed: 8 (R2018) Motor-Operated Appliances (Household and Commercial) Meets BIFMA x5.5 2014. - Page 16 OV1020 USER GUIDE Part No. 107885 RevA | 062119...
