hEDEL DUAL POWER BREAK Manual

M A N U A L F O R T H E
DUAL POWER BREAK
C U S T O M S T U F F
H A N D M A D E
in Germany
• The Power Break can be used for
impedances of 4, 8 and 16 ohms.
• Four speaker boxes can be connected
for the perfect sound.
• Two independently adjustable volume
levels are easily operated via a
footswitch.
• It can also be used without connecting
it to a box.
• • The Power Break has a controllable
DI Out signal, which can be picked up
3,5 mm stereo-jack and balanced XLR.
Perfect for recordings, live
performances and headphones.
• Power Break and foot pedal are
characterised by a low weight.
• Thanks to the built-in fan, the device
does not get hot. The sound remains
the same with the use of the
instrument.
•
• Did You Know? The Dual Power Break is
100 % handmade.
C O N T E N T S PA G E
Page 1
S 1 Cover
S 2 Technical specifications
Page 2
S 1 Description Front-/ Back
S 2 Safety instructions
Page 3
S 1-2 Connection scheme
Page 4
S 1 Fuse (exchange)
S 2 Imprint
