NORDYNE
ENGINEERING SPECIFICATION
(SYSA Friendly Rev. 2)
DESCRIPTION:
LABEL, WIRING DIAGRAM, ECM MOTOR, 208-240 VOLTS, R7TQ-090/120
EXTENDED DESCRIPTION:
MATERIAL: Pressue sensitive adhesive, per Nortek Spec #800166-
COLOR:
Black ink on White paper
SIZE:
11.0" X 17.0" including 0.125" perimeter border
PAGES:
2
NOTE:
When printed in house, print on 11.0" x 17.0" sheet following all specifications noted
REV.
ECM
Richard Blasko / 10/27/2016
-
402468
ANY CONSTRUCTION CHANGE IN THIS PART FROM THE APPROVED SAMPLE PROVIDED NORDYNE ENGINEERING
(ON WHICH THIS SPECIFICATION IS BASED) MUST RECEIVE WRITTEN ENGINEERING APPROVAL PRIOR TO
SUPPLYING SUCH REVISED PARTS
1011728
SPEC. NO.
10/27/2016
DATE
S'SEDE'S
DATED
ENG. APPROVAL / DATE
File Name: 10117280.xlsx, Page 1, Page 1 of 1, Printed: 12/12/2016 7:27 AM
0
REV.
1
SHEET
OF
See literature with same #
See vendor print w/ same #
TOLERANCES
(UNLESS OTHERWISE SPECIFIED)
1/32
Fractions(±)
0.031
Decimals(±)
REASON FOR REV.
1
X
NEW PART
X
ADDED PART
CHANGE
Hole spacing(±)
Hole Location(±)
