HP-00007-01, Appendix 3
Appendix 3 Product End-of-Life Disassembly instructions
Product Identification:
Marketing Name / Model
HP Business Desktop dx5150 Series
Purpose: The document is intended for use by end-of-life recyclers or treatment facilities. It provides the
basic instructions for the disassembly of HP products to remove components and materials requiring
selective treatment.
1.0
Items Requiring Selective Treatment
1.1
Items listed below are classified as requiring selective treatment.
1.2
Enter the quantity of items contained within the product which require selective treatment in
the right column, as applicable.
Item Description
Printed Circuit Boards (PCB) or Printed
Circuit Assemblies (PCA)
Batteries
Mercury containing components
Liquid Crystal Displays (LCD) with a
surface greater than 100 square cm
Cathode Ray Tubes (CRT)
Capacitors / condensers (Containing
PCB / PCT)
Electrolytic Capacitors / Condensers
measuring greater than 2.5 cm in
diameter or height
External electrical cables and cords
Gas Discharge Lamps
Plastics containing Brominated Flame
Retardants
Components and parts containing toner
and ink, including liquids, semi-liquids
(gel/paste) and toner
Components and waste containing
asbestos
Components, parts and materials
containing refractory ceramic fibers
Components, parts and materials
containing radioactive substances
Description
Small Form Factor, ATX board
Notes
With a surface greater than 10
square cm
All types including standard
alkaline and lithium coin or button
style batteries
For example, mercury in lamps,
display backlights, scanner lamps,
switches, batteries
Includes background illuminated
displays with gas discharge lamps
Include the cartridges, print
heads, tubes, vent chambers, and
service stations.
HP Restricted
02-Jun-2005
Qty items in
product.
2 (sys board &
P/S board)
1
0
0
0
0
3 (3 in P/S)
0
0
0
0
0
0
0
Page 1
