Follett REFP Installation Instructions

Description

Batteries operate the keypad lock during a loss of
power.
Installation
1. Provide power to the unit and turn the
power switch to the ON position.
2. Open the door using the keypad lock
and prop the door open so it doesn't
close during the battery installation.
Keypad instructions can be found in
the Installation, Operation and Service
manual on page 11.
3. Turn power switch to the OFF position or
unplug the unit from the power supply.
4. Remove the four screws (Fig. 1.1) on the
kick panel at the bottom of the unit.
5. Remove the kick panel and slide the
panel to the right of the refrigerator.
Note: Take care when removing, some wires
are connected to the kick panel (Fig. 1.2).
6. Find the control module on the left-hand
side of the unit, just to the left of the
condenser.
7. Open the Velcro strap (Fig. 1.3) that
holds the battery pack and the battery
connector.
8. Connect the battery connector with the
black and red wires to the top of the
battery pack.
9. Place the battery pack back in place on
the control module and tighten the Velcro
strap around the battery pack.
10. Re-install the kick plate.
11. Close the door and check to make sure
that the wire on the hinge side of the
door is not kinked or pinched.
12. Test operation of the keypad lock while
the power to the unit is OFF to confirm
back-up battery connection.
13. Turn the power switch ON or plug the
unit back into the power supply.
801 Church Lane • Easton, PA 18040, USA
Toll free (877) 612-5086 • +1 (610) 252-7301
www.follettice.com
REFP/FZRP Keypad Units
Fig. 1
3
1
Battery Backup

Installation Instructions

2
2
Order parts online:
www.follettice.com
01065234R00
