uniview technologies NSW081P Quick Installation Manual

8-port poe ethernet switch
Hide thumbs
1
2
3
4

Advertisement

Quick Links

Download this manual
The Switch you purchased contains following items
Item Name
Switch
1
Power Adapter
2
3
Power cable
Plastic-foot
4
5
Quick Installation Guide
You can toggle switch to decide whether to use Extend or not (Note: After toggling the
switch, you need to reboot the device to enable or disable this function):
ON: Extend mode is enabled. All downlink ports are separated, and the network
transmission distance is extended to 250 meters.
OFF: Extend mode is disabled (switch to standard switching mode). All ports can
communicate with each other.
Quantity
Unit
Set
1
Piece
1
1
Piece
Piece
4
Piece
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the NSW081P and is the answer not in the manual?

Questions and answers

Summary of Contents for uniview technologies NSW081P

  • Page 1 The Switch you purchased contains following items Item Name Quantity Unit Switch Power Adapter Piece Power cable Piece Plastic-foot Piece Piece Quick Installation Guide You can toggle switch to decide whether to use Extend or not (Note: After toggling the switch, you need to reboot the device to enable or disable this function): ON: Extend mode is enabled.
  • Page 2 Panel Status Meaning Green Power connected Power LED Power disconnected or power failure Green Link established Sending/receiving data Flashing Status LED Link No link Orange Supplying power POE LED POE Status Not supplying power ● Unplug power before cleaning. Do not wipe the switch with wet cloth. Do not clean with liquid.
  • Page 3 1. Verify that the power supply complies with the specifications marked on the switch. 2. Connect the power adapter to the DC interface of the switch first, and then connect the power adapter to the mains. 3. Check that the PWR indicator on the switch is lit, which means power is connected correctly.
  • Page 4 ● This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and ( 2) this device must accept any interference received, including interference that may cause undesired operation.
