Q-Light SHDN30 Operating Manual

SHDN30
OPERATING MANUAL
2 Faces Heavy Duty Signal Phone
Thank you for purchasing Q.Light product.
Please read this manual carefully before installing this system
for safe and long use of the product.
▪ Heavy-duty product of with both sided,high volume phones
which is suitable for heavy cranes and transportation
machinery.
▪ Possible to control volume level by using the built-in volume
controller..
▪ Standard Body Color : MUNSELL NO. : 7.5BG 7/2
▪ Standard Horn Housing Color : Red
▪ Material : Body- DIECAST AL., Horn Housing-SUS316L
▪ Volume : 113~118dB/1m x 2
▪ Operating Temperature : -20℃~50℃

▪ Product Specification

Model
Built-in Sound
5 Warning
WS
Sounds
5 Special
WP
Warning
Sounds
SHDN30
WM
5 Melodies
WA 5 Alarms
3 Voice
WV
Signals

▪ External View Drawing

▪ Protection Class : IP56
Rated Voltage/
Weight
dB Voltage Current
118dB
·DC12V
x2
/2.140A
118dB
·DC12V
·DC24V DC
x2
/1.860A -3.49Kg
·DC24V
118dB
x2
·AC110V AC
·AC110V
/0.252A -4.21Kg
116dB
·AC220V
x2
·AC220V
113dB
/0.166A
x2
Built-in
Model CH
Sound
ch1 Fire : A-ANG(Wail) Sound
5 ch2 Emergency : WA-U Sound
WS Warning ch3 Ambulance : PI-PO Sound
Sounds ch4 Machinery Fault : PI-PI Short Interval
ch5 Foam Release Alarm : PI~ Continuous
ch1 Fire : A-ANG(Wail) Sound
5 Special ch2 Abandon Alarm~
WP Warning ch3 Machinery Fault : PI-PI Short Interval
Sounds ch4 Foam Release Alarm : PI~ Continuous
ch5 General Alarm : Long PI after 7 Short PI
ch1 Sweet Home
ch2 For Elise
5
WM ch3 Cuckoos Waltz
Melodies
ch4 Piano Sonata
ch5 Turkish March
ch1 Beep(Intermittent)
ch2 Door Chime
WA 5 Alarms ch3 Phone Ring Sound
ch4 PI-PI-PI- (Short Interval)
ch5 Tripping Bead Sound
ch1
3 Voice
WV ch2 Voice Recording & Replay 3 Channels
Signals
ch3
Refer to above structure drawing together with below drawing and
explanation for right operating.
▪ Make sure terminal plate inside the body of the product.
Remove cover② by loosening cover bolt(M5-4EA)①.
▪ Treat the end of power cable by using "O" or "U" type terminal
for safe wiring.
▪ Connect power cable to terminal plate③.
▪ In case of product using AC voltage, connect the line without
polarity(wire color).
▪ In case of product using DC voltage, black line is negative(-).
▪ Keep the tightness of power entry⑧ by using water-proof
connector(flexible connector #16 is supplied as a standard
specification) or cable grand.
▪ Product can be damaged by water or dust if the cable entry is
exposed outdoor without airtightening.
▪ Keep the tightness of power entry④ by using water-proof
dB
Sound Tone
118
dB
x 2
118
dB
x 2
118
dB
x 2
116
dB
x 2
113
dB
x 2
