XV
User Guide
V1.10 25-02-2017
Diode Ladder Wave Filter
Thank you for purchasing the AJH Synth Sonic XV Eurorack synthesiser module, which like all AJH
Synth products, has been designed and handbuilt in the UK from the very highest quality compo-
nents. We hope that it will help and inspire you towards creating some great music and sound-
scapes!
The Sonic XV Eurorack module is a four pole Diode ladder lter, featuring the circuitry and sound
of the Musonics Sonic V synthesiser from the early 1970's. In addition to the regular 24dB Low
Pass output we have added a 6dB Low Pass output and a Bandpass output, along with full volt-
age control and level correction of the resonance on the 24dB output.
Two waveshapers/wavefolders have been added to hugely increase the sonic versatility of this
module, rstly there is a six stage diode breakpoint based wavefolder, the output of which can be
added to the input signal in any amount from 0 to 100% using a wet/dry mixer control. The drive
level of the wavefolder can be manually adjusted with the IN Wave control, or by patching a
control or modulation voltage into the IW-CV jack, it can be voltage controlled. There is also a
three position bias control switch that allows additional variation to the input waveshaping.
The second waveshaper is connected to the resonance loop of the lter and it adds distortion and
waveshaping to the resonance loop signal, again the drive can be adjusted manually or under full
voltage control from the RW-CV input. There is a wet/dry mix control so that resonance wave-
shaping can be added at any rate between 0 to 100%.
These additions take the diode ladder lter core way beyond it's original function, by using the
waveshaping options it becomes a " lter" module that can actually add harmonics to waveforms
rather than simply ltering them. With four independant CV inputs very complex ltering and
waveshaping sounds are possible that take it far beyond regular diode or transistor ladder lters.
Module width is 14 HP of EuroRack space and it is compatible with standard Euro Rack cases. The
height of the panel is 128.5mm, and depth is 24mm, or 34mm with the power cable attached.
There are four mounting holes at the corners of the module and we provide 4 of M3 rack xing
screws, along with a Eurorack compatible power cable. Current consumption is 70mA from the
+12V supply rail and 55mA from the -12V supply rail.
All AJHSynth modules are covered by a one year guarantee against manufacturing defects.
Notes:
It is important that the power supply ribbon cable is connected correctly, see the "Power Cable Orienta-
tion" section for more details. Also, we recommend that a high quality, low noise Eurorack power
supply is used with this modules, some switched mode PSU's generate high levels of line ripple which
may cause undesirable audio noise on the output.
www.ajhsynth.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the SONIC XV and is the answer not in the manual?

Questions and answers

Summary of Contents for AJH Synth SONIC XV

  • Page 1 We hope that it will help and inspire you towards creating some great music and sound- scapes! The Sonic XV Eurorack module is a four pole Diode ladder lter, featuring the circuitry and sound of the Musonics Sonic V synthesiser from the early 1970’s. In addition to the regular 24dB Low Pass output we have added a 6dB Low Pass output and a Bandpass output, along with full volt- age control and level correction of the resonance on the 24dB output.
  • Page 2: Controls, Inputs And Outputs

    Controls, Inputs and Outputs Resonance Level 2 1 Cuto Frequency Resonance Mix 4 3 Freq. CV Level Res Wave Drive 5 Input Wave Mix 6 Input Level Input Wave Drive 8 10 Resonance CV R Wave Drive CV 11 9 Freq. CV In I Wave Drive CV 12 14 Audio Input I Wave Bias 13...
  • Page 3 This control sets the drive amount to the Resonance wavefolder, turning the control clock- 5 Res Wave Drive: wise increases the drive level. If a control voltage is applied to the R Wave Drive CV Input (11) by plugging in a patch cable, then this control changes function and attenuates the signal passed from the R Wave Drive CV Input to the Resonance waveshaper.
  • Page 4 Diode Ladder BP Output Audio Input Filter core 6dB Output Cuto Freq. Freq CV Input Freq. CV Level 24dB Output SONIC XV FILTER BLOCK DIAGRAM AUDIO SIGNAL PATH: RESONANCE SIGNAL PATH: 1 V/Oct Input CONTROL SIGNAL PATH: INTERNAL VOLTAGE CONNECTIONS:...
  • Page 5 Getting Started: The Sonic XV lter can be easily used without any waveshaping by simply rotating the IN MIX and RES MIX controls to zero (fully anticlockwise) In this con guration the Sonic XV lter performs as a regular resonant VCF, with 24dB Low pass, 6dB Low pass and Band Pass outputs.
  • Page 6 Patch example: Below is a visual example of a patch combining several AJH Synth modules. This is to give an idea of how to connect everything together, in this case we are applying external CV’s from thwo separate Envelope Generators to modulate both the Cutto frequency and the Drive if the Input waveshaper.
  • Page 7: Power Cable

    Adjustment, Calibration and Power Cable connection Note: This information is given for completeness, the Sonic XV Module is calibrated after manufac- ture and under normal circumstances should not require any user adjustment. Frequency Trimmer Scale track Trimmer Power Cable Red Stripe aligns with -12V as shown FOR MANUFACTURER ADJUSTMENT ONLY.
