- Page 1 SC80 Installation & User guide...
- Page 2 Index Page 3: Product information and specs Page 4: Trouble shooting Page 5: Filter replacement Page 6: CO2 bottle replacement Page 7: CO2 adjustment Page 8: Water temp adjustment Page 9: Component checklist Page 10: Install layout Page 11: Ventilation requirements Page 13: Instillation guide Page 23: Unit setup Page 29: Warranty...
-
Page 3: Specifications
• Water supply must be microbiologically safe. WARNING PROPERTY DAMAGE • In situations where any water leakage could result in damage to property, the complete Schwan Installation should be installed over a Drained Safe Tray, plumbed to an appropriate drain. -
Page 4: Troubleshooting
Trouble shooting Unit shutdown page 30 Fault Cause Action Check power and water supply is on, if so then shut down unit Chiller system will not start No power / water or faulty chiller unit Call MERQUIP Increase cabinet ventilation make Unit chilling full time and producing Ventilation below min requirements. -
Page 5: Filter Change
Filter Change To ensure your Schwan drinking water system continues to provide you with fresh filtered chilled and sparkling drinking water, your Schwan filter cartridge needs to be replaced at least every 12 months. In some situations where there is a lot of sedimentation or chemicals in the water supply, it may be advisable for the filters to be replaced more frequently to avoid annoying slow water flow or chemical taste issues. - Page 6 CO2 bottle replacement screw new CO2 bottle onto regulator Turn chiller off at switch Some gas will escape Shut gas off at regulator using control knob, turn off Open regulator by turning gas by tuning knob knob clockwise anticlockwise until it is at full Adjust CO2 pressure using off position.
- Page 7 CO2 adjustment By adjusting the knob on the regulator you can adjust the carbonation of the water. The more pressure applied the more sparkle you get. Watch gauge on regulator and make sure the pressure doesn't ex- ceed 5 Bar. We recommend not having the unit under 3 Bar as the unit will not produce enough sparkle.
- Page 8 Water temp adjustment NOTE: turning chiller on MAX chill could cause it to ice up, use MAX setting at own risk. Water temp effects the carbonation of the sparkling water — the warmer the water the less fizz the water will hold.
-
Page 9: Component Checklist
Component checklist 11. CO2 regulator 1. Dispenser with tubes packed in separate box 13. JG reducer 8-6mm 14. JG flow bend support 4. Dispenser base with O-ring 15. stop tap connector 1/4 inch tube 5. Dispenser rubber washer 6. Dispenser metal washer 16. -
Page 10: Typical Installation Layout
Power cord SC80 chiller unit Drained safe tray of cabinet In situations where any water leakage could result in damage to property, the WARNING complete Schwan installation should be installed over a Drained Safe Tray, plumbed to an appropriate drainage connection. -
Page 11: Venting Requirements
Venting requirements Cabinet must have an air inlet vent at the bottom and outlet vent no more than 200mm from the top The amount of air space around the unit apply for both passive and fan forced ventilation There must be a 100mm air space on The front of the unit must have both sides of the under bench chiller at least 100mm of air space... - Page 12 Venting requirements Top vent must be a minimum size of 220mm x 90mm and no more than 200mm from top of door Vent must have a minimum of 60mm of air space behind Vent door for air flow out of cabinet Bottom cut out of the cabinet must be at least 200mm x 40mm...
-
Page 13: Installation
Installation... - Page 14 Tap install NOTE: The tap can not mount to a surface of more than 30mm thick. MAX 30 mm There must be a 50mm diameter flat and solid clamping surface under the bench for the tap mounting system Min 50 mm The centre of the hole must be no further than 80 mm from sink Dill 25mm hole in bench top...
- Page 15 Screw mounting rod into bottom of dispenser Slide dispenser with tubes and mounting rod into hole and sit on tap base Thread washers onto rod rubber first then metal followed by nut Using 13 mm tap spanner tighten nut so tap is firmly mounted on bench...
-
Page 16: Water Supply Install
Water supply install Fit 15mm to 1/4 inch adapter to stop tap. Tighten until hand tight then give it a light nip up with spanner. NOTE: Do not over tighten Fit 1/4 inch blue water supply tube to adapter on stop tap Press fully into connector. - Page 17 Using remaining 4 screws fit filter to wall. Fit supply tube from PRV to inlet of filter head. NOTE: make sure that the tube is going into the IN side of the filter head Fit rest of blue 1/4 inch tube to filter outlet Do not trim tube to length All tubing must be cut square and clean to fit into fittings...
- Page 18 Chiller install Unit air space clearance requirements Remove ice bank plug from back of unit Use supply tube from filter to fill ice bank Fit tube with 8mm adapter into fill ice bank inlet...
- Page 19 Open stop tap partially to provide a slow flow — do not turn on fully Fill ice bank to point shown between min and max level When ice bank is full turn off water supply Unplug fitting from ice bank NOTE: some water will spill out...
- Page 20 Put Red ice bank plug back in to ice bank inlet Fit water supply fitting into WATER IN Attach flow bend clip to tube as shown Plug in power cord to back of unit...
- Page 21 The back of the unit should look like this. Check all fittings are in correctly and position chiller in cabinet. NOTE: top of internal ice bank is not sealed take care when moving unit and dry up any spilled water. The tubes coming from the tap attach to the soda out (white) and water out (blue) trim to length.
- Page 22 Position gas bottle and trim tube to length. Fit other end of tube to CO2 IN on the Chiller. Plug in 3 pin plug to power supply. Do not turn on yet! Tube length check NOTE: make sure tubes are cut to the right length to provide continuous fall but aren’t under strain Right length...
-
Page 23: Initial Setup
Initial setup... - Page 24 Setting up water supply Open cold lever on dispenser Open cold water supply slowly until fully open Run cold water for 5 min to clear any air bubbles and check for leaks at points shown on next page.
- Page 25 Check for water leaks...
- Page 26 Close off cold water and run sparkling side of tap to fill tank and get rid of any air bubbles run for 5 min then shut it off NOTE: the water on this side will come out slow until gas is applied. Turn power on at the wall Socket Turn power on at the unit.
-
Page 27: Check For Gas Leaks
4 Bar open gas regulator and set to 4 bar NOTE: CO2 must not exceed 5 bar Open soda leaver on tap 1/2 way water will gush out open for 10 seconds. Shut off and the CO2 pump should start up Check for gas leaks... - Page 28 Installed unit should look like this.
-
Page 29: Warranty
Alternatively, Schwan may require you to return your unit to Schwan so that Schwan can provide you with a replace- ment unit free of charge. In this case, Schwan will pay the necessary freight charges, and you will need to take re- sponsibility for the removal of the faulty unit, and installation of the replacement unit. -
Page 30: Unit Shutdown
Unit shutdown than 24 hours shut down unit by following these steps Shut gas off at regulator using control knob, turn off gas by tuning knob anticlockwise until it is at full off position. Open cold tap until water stops flowing Turn power off at the wall... - Page 31 This unit is backed by MERQUIP NOTES For service call 0800 636 0 636 Or visit www.merquip.co.nz And book a service...
