Pasport PS-2121 Quick Start

Colorimeter
PS-2121
cuvette
Equipment equipment needed:
• PASPORT interface with USB-compatible computer or Xplorer (PS-2000)
®
• DataStudio , DataStudio Lite, or EZscreen software
®
800-772-8700 • 916-786-3800 • techsupp@pasco.com • www.pasco.com
Colorimeter Specifications
Specifications:
Range:
Wavelengths:
Accuracy:
Resolution:
Default sample rate
*
Maximum sample rate:
**
Temp. Range:
lid
cuvette holder
Calibration
button
0 to 100% transmittance
Red (660 nm), orange (610 nm),
green (565 nm), blue (468 nm)
± 0.5% transmittance
0.1% transmittance
1 sample/sec
5 samples/sec
5–40°C (recommended)
C ol o r i m e t er Qu i c k S t a r t
The PS-2121 Colorimeter measures the transmittance (%) of different colors of
light through a solution, and can be used to determine a solution's concentration.

Equipment Setup

1. Connect a PASPORT TM interface to a USB port on your computer or to a USB hub.
(If using an Xplorer, connect the Xplorer cable to a USB port on your computer.)
2. Connect the sensor to the PASPORT interface (USB Link, PowerLink, Xplorer, etc.).
3. The software launches when it detects a PASPORT sensor. Select a choice from
the PASPORTAL window.
1
Colorimeter Usage Tips
*
The recommended sample rate is 1 Hz for color and Beer's law studies.
If you plan to do reaction order studies, use a faster sample rate.
**
The temperature range applies to both the temperature of the solution in
the cuvette and the ambient temperature. Using the Colorimeter above
or below the recommended range or with condensation may give false
readings.
2
3
CARD 1A
012-08158C
CARD 1B
