- Page 1 USER MANUAL MeshTek® BLE-Ethernet-WiFi-USB Gateway User Manual Revision 1.2 TABLE OF CONTENTS...
-
Page 2: Table Of Contents
...........................5 ATEWAY CHAPTER 2 FEATURES ............................6 ..............................6 ENERAL ..............................6 BLE .................................6 CHAPTER 3 ELECTRONIC PARAMETERS ......................7 CHAPTER 4 MESHTEK GATEWAY ARCHITECTURE ....................9 ............................9 LOCK IAGRAM CHAPTER 5 GETTING STARTED ........................10 ..........................10 YSTEM EQUIREMENT ..............................10 ETUP ..........................10... - Page 3 It is our intention to provide our valued customers with the best documentation possible to ensure successful use of your iLumi Solutions, Inc. products. To this end, we will continue to improve our publications to better suit your needs. Our publications will be refined and enhanced as new volumes and updates are introduced.
-
Page 4: Chapter 1 Overview
USER MANUAL Chapter 1 Overview The MeshTek Gateway is a Bluetooth Low Energy (“BLE”) to Wi-Fi IoT gateway. It allows users to control and monitor various MeshTek devices from a mobile app or cloud. The MeshTek Gateway supports both Ethernet and Wi-Fi for connectivity to the local network and the internet. -
Page 5: Meshtek Gateway
USER MANUAL 1.2 MeshTek Gateway • Representation of end user interface and connectors available on MeshTek Gateway is shown Blue Tactile Tactile RJ-45 Switch 2 Switch 1 (Reset) Connectors / Buttons Description Micro-USB, power input (5.0VDC, 1.2A) RJ-45 10/100Mbps Ethernet... -
Page 6: Chapter 2 Features
• 1 x USB 2.0 host (Same port at micro USB) • 1 x Ethernet 2.3 BLE • MeshTek-H52 Bluetooth 5.0 ready module based on Nordic’s nRF52832 (ARM® Cortex™-M4 CPU 64MHz 32- bit processor) • Max output power: +18.9 dBm •... -
Page 7: Chapter 3 Electronic Parameters
IEEE 802.11g/802.11n: Orthogonal Frequency Division Modulation Technology Multiplexing(OFDM) +20dBm Transmit Power Ceramic Antenna Antenna 3dBi Antenna Gain Up to 100 meters (open space) Range WPA / WPA2 Security 802.11b/g/n all support 2×2 MIMO Note © ilumi Solutions, Inc. www.ilumisolutions.com Page 7 | 19... - Page 8 General Information Color White 90mm x 90mm x 28mm Size Weight • 1 x 5VDC USB Adapter • 1 x Micro USB Cable (1m) Accessory • 1 x Ethernet Cable (1m) © ilumi Solutions, Inc. www.ilumisolutions.com Page 8 | 19...
-
Page 9: Chapter 4 Meshtek Gateway Architecture
USER MANUAL Chapter 4 MeshTek Gateway Architecture 4.1 Block Diagram The below block diagram gives an overview of a MeshTek Gateway architecture: © ilumi Solutions, Inc. www.ilumisolutions.com Page 9 | 19... -
Page 10: Chapter 5 Getting Started
• MeshTek Gateway with accessory kit • iOS device (iOS 10.0 and above) Note: Internet connection should be available in case user wants to remotely control the MeshTek devices. 5.2 Setup • Connect one end of the Ethernet cable to the Gateway and other end to the WiFi Router •... - Page 11 • After the Gateway is detected, follow the instructions available on screen. Click on “Next” and provide name to the Gateway. Click on “Add” button present at the bottom of the screen to move onto the next setup. © ilumi Solutions, Inc. www.ilumisolutions.com...
- Page 12 User credentials and End node details needs to be synced between the two. (Note: Local connection would be successful when both the Gateway and iOS device are present on the same local network.) © ilumi Solutions, Inc. www.ilumisolutions.com Page 12 | 19...
- Page 13 Gateway is ready for User. Go to the Dashboard screen to see the added Gateway. Click on “Gateway” to check the added Gateway parameters and status of the connection. Green dot indicates that the Gateway is online and local connections is successful. © ilumi Solutions, Inc. www.ilumisolutions.com Page 13 | 19...
- Page 14 Gateway pairing process. In case both the Gateway and iOS device are not on same local network then the APP would prompt User to “Please plug Ethernet cable and try again”. User can decide to click on “Skip” button to finish the paring process. © ilumi Solutions, Inc. www.ilumisolutions.com Page 14 | 19...
- Page 15 “Networks” page and the click on the Network in which Gateway was added. Once done, the configuration would be synced as shown below and now the User would be able to control End nodes via Gateway © ilumi Solutions, Inc. www.ilumisolutions.com...
-
Page 16: Deleting A Gateway
Click on the “Gateway” present on the Dashboard and click on the “Delete Group” button present on the bottom of the screen. • Once deleted, the Gateway is removed from User’s Account and it becomes available for pairing again. © ilumi Solutions, Inc. www.ilumisolutions.com Page 16 | 19... -
Page 17: Adding And Editing A Network
Network for each Gateway. • Click on “Add Network” button present on the bottom right of the Networks page. Give the logical name and description to the Network and click on “Save”. © ilumi Solutions, Inc. www.ilumisolutions.com Page 17 | 19... - Page 18 Click on “Edit” button present on the bottom left of the Networks page. Edit icon would appear against each of the Network, by clicking on the icon you can Rename, Change Photo or Delete the Network as shown in below images. © ilumi Solutions, Inc. www.ilumisolutions.com Page 18 | 19...
-
Page 19: Chapter 6 Revision History
USER MANUAL Chapter 6 Revision History Revision Date Status / Comments Jan 2019 Initial Release March 2019 Updated Getting Started section © ilumi Solutions, Inc. www.ilumisolutions.com Page 19 | 19...
