CONTINENTAL CONTROL SYSTEMS WattNode BACnet Series Installation Manual

W
N BaC
att ode ®
and
W
N
att ode ®
R
Electric Power Meter
Installation Manual
Series - Service - Interface
______ - _______ - ________
3Y-208
3Y-400
3Y-480
3Y-600
BN = BACnet
3D-240
3D-400
3D-480
WNC = Third generation
RWNC = Revenue, third generation
1 Precautions
1.1 Only qualified personnel or licensed electri-
cians should install the WattNode meter. The
mains voltages of 120 to 600 Vac can be lethal!
1.2 Follow all applicable local and national electri-
cal and safety codes.
1.3 The terminal block screws are not insulated.
Do not contact metal tools to the screw termi-
nals if the circuit is live!
1.4 Verify that circuit voltages and currents are
within the proper range for the meter model.
1.5 Use only UL listed or UL recognized current
transformers (CTs) with built-in burden resis-
tors, that generate 0.333 Vac (333 millivolts AC)
at rated current. Do not use current output
(ratio) CTs such as 1 amp or 5 amp output
CTs: they will destroy the meter and may
create a shock hazard.
1.6 Protect the line voltage inputs to the meter with
fuses or circuit breakers (not needed for the
neutral or ground wires). See 3.3.1 below.
1.7 Equipment must be disconnected from the
HAZARDOUS LIVE voltages before access.
1.8 If the meter is not installed correctly, the safety
protections may be impaired.
1.9 Symbols
Read, understand, and follow all instructions including warnings
and precautions before installing and using the product.
Potential Shock Hazard from Dangerous High Voltage.
Functional ground; should be connected to earth ground if possible,
but is not required for safety grounding.
UL Listing mark. This shows the UL and cUL (Canadian) listing
mark.
FCC Mark. This logo indicates compliance with part 15 of the FCC
rules.
Complies with the regulations of the European Union for Product
Safety and Electro-Magnetic Compatibility.
• Low Voltage Directive – EN 61010-1: 2001
• EMC Directive – EN 61327: 1997 + A1/1998 + A2/2001
V~ This indicates an AC voltage.
Net
PC or BACnet Host
A−, D0, RxD−/TxD−
B+, D1, RxD+/TxD+
eveNue
Options
See website
for options
®
Transformers
1 Phase 2 Wire 120V with neutral
1 Phase 2 Wire 230V with neutral (non-U.S.)
1 Phase 2 Wire 277V with neutral
1 Phase 2 Wire 208V no neutral
1 Phase 2 Wire 240V no neutral
1 Phase 3 Wire 120V/240V with neutral
3 Phase 3 Wire Delta 208V no neutral
3 Phase 3 Wire Delta 400V no neutral (non-U.S.)
3 Phase 3 Wire Delta 480V no neutral
3 Phase 4 Wire Wye 120V/208V with neutral
3 Phase 4 Wire Delta 120/208/240V with neutral
3 Phase 4 Wire Wye 230V/400V with neutral
(non-U.S.)
3 Phase 4 Wire Wye 277V/480V with neutral
3 Phase 4 Wire Delta 240/415/480V with neutral
3 Phase 4 Wire Wye 347V/600V with neutral
W
A -
B+
Com
Common C
X
ØA CT
WHITE
ØB CT
BLACK
ØC CT
Source
Faces
Current
Figure 1: WattNode Wiring Diagram
Electrical
Service (or Load) Types
Table 1: WattNode Models
2 Overview
Congratulations on your purchase of the WattNode
transducer (meter). The WattNode meter enables you to make power and en-
ergy measurements within electric service panels avoiding the costly installa-
tion of subpanels and associated wiring. It is designed for use in demand side
management (DSM), submetering, and energy monitoring applications. The
WattNode meter communicates on an EIA RS-485 two-wire bus using the
BACnet protocol.
2.1 Additional Literature
See the Continental Control Systems, LLC website (www.ccontrolsys.com)
for product pages, datasheets, and support pages for all WattNode meter mod-
els and current transformers. Each WattNode model has an
Reference Guide
and interface.
2.2 Electrical Service Types
Table 1 above lists the WattNode models and common circuit types. In the
"Electrical Service Types" column, when two voltages are listed with a slash
between them, they indicate the line-to-neutral / line-to-line voltages. The
"Line-to-Neutral" and "Line-to-Line" columns show the operating ranges for
the WattNode meters.
Continental Control Systems LLC
N BAC
ATT ODE NET
®
WNC- 3Y-xxx
-BN
WNC- 3D-xxx
-BN
N
Status
ØA
Status ØB
Status ØC
Line-to- Line-to-
Neutral Line
(Vac) (Vac)
96 – 138 n.a.
184 – 264 n.a.
222 – 318 n.a.
n.a. 166 – 276
n.a. 166 – 276
96 – 138 166 – 276
n.a. 166 – 276
n.a. 320 – 460
n.a. 384 – 552
96 – 138 166 – 276
96 – 138 166 – 276
184 – 264 320 – 460
222 – 318 384 – 552
222 – 318 384 – 552
278 – 399 480 – 690
with detailed information on the available measurements
