Summary of Contents for TECHMOR AC-1-4
- Page 1 AC-1-4 ANALOG TO CAN BUS MODULE USER MANUAL Rev. C 10/ 2 / 201 4...
- Page 2 Resolution 16-Bit Accuracy 0.1% F.S. Electrical The AC-1-4 can be supplied with 6-24V DC via the red and black wires on the 4- conductor cable on the Power/CAN side of the enclosure. Supply Voltage 6 - 24 V DC Current (No Load)
- Page 3 Channel Output (Voltage) = Counts * 0.0001 Changing the CAN ID The CAN ID of the AC-1-4 can be set by the user by sending a special programing message to the unit. The message format is as follows: Change CAN ID...
- Page 4 For support on Techmor products, contact: support@techmor.com +1-704-769-0001 Copyright 2014. The information contained in this document is proprietary and confidential, and property of Techmor, Inc. Any use of this information, without written consent of Techmor, Inc. is prohibited by law.
