Installation and user guide
(Supreme (ION) shown, please note vessels may vary in design and colour)
For all Aquatiere No Scale Models
Aquatiere,8a Stag Business Park, Ringwood. BH24 3AS
01425 471221
sales@aquatiere.co.uk
Model No
STANDARD
PLUS
NS
SUPREME
ION
ISSUE4 03/02/17
Advertisement
Summary of Contents for AQUATIERE NS Series
- Page 1 Model No STANDARD PLUS SUPREME Installation and user guide (Supreme (ION) shown, please note vessels may vary in design and colour) For all Aquatiere No Scale Models Aquatiere,8a Stag Business Park, Ringwood. BH24 3AS 01425 471221 sales@aquatiere.co.uk ISSUE4 03/02/17...
-
Page 2: Non-Return Valve
AQUATIERE NO SCALE INSTALLATION Before installing the No scale unit, please ensure you have the correct model with regard to the water demand and the water hardness/hardness type. Aquatiere can advise if required. 1. INITIAL INSTALLATION CONSIDERATIONS Observe water byelaws ... - Page 3 GENERAL FITTING INSTRUCTIONS Fit the Aquatiere main No Scale unit in a standing, vertical position onto the incoming water main, taking note of the flow direction of the system. For ease of use the unit is supplied with John Guest BSP 22 male Push fit fittings, however for installations where space is an issue, compression fittings can be used with care (ensure threads are wound with PTFE tape and take care not to cross thread).
- Page 4 NO SCALE SUPREME (ION EXCHANGE VARIANT) CONTENTS A 2 X PUSH FIT 22MM PIPE CONNECTOR B 2 X THREADED ¾ - ¾ BSP MALE NIPPLE C 2 X ¾ BSP COLLAR PIPE IN PIPE CARBON PRE- POST FILTER FILTER MAIN VESSEL FLOW PLEASE NOTE...
- Page 5 NO SCALE TYPICAL LAYOUTS (Please use this along with basic no scale diagram on previous page. NOTE- The supreme model is fitted in same configuration as below but is not shown in drawings) COMBI BOILER FLOW POST NO SCALE FILTER WATER TANK FLOW...
- Page 6 COLD WATER TANK WATER TANK FLOW COLD POST NO SCALE FILTER HOT WATER CIRCUIT INCLUDING FEED FROM COLD Isolation valve COLD WATER FEED BYPASS LOOP PRESSURE LIMITING POST VALVE IF REQUIRED FILTER FILTER FLOW...
- Page 7 DUPLEX FITTING GUIDE DIAGRAM (please note the diagram should be used as a guide Note this also applies to supreme models with the 3 canister layout) COLD Post Filter NS40/60 Post Filter NS40/60 HOT WATER CIRCUIT INCLUDING FEED FROM COLD ISOLATION VALVE COLD WATER FEED BYPASS LOOP...
- Page 8 TROUBLE SHOOTING GUIDE NO SCALE SALTLESS WATER SOFTENER If you experience problems with your no scale unit please carry out the following procedure 1. If a copper by-pass is fitted ensure the pipe work has been cross bonded to ensure conductive continuity is maintained across the pipe work 2.
-
Page 9: Maintenance Notes
3. Fitting onto non-mains supplied water 4. Damage caused by dirty mains water 5. The effect of aggressive water, the degradation and /or blinding of resin and/or chlorine attack on resin 6. Incorrect specification other than Aquatiere 7. Compensation for plumbing costs... - Page 10 No scale service record Original installation date resin change date resin change date resin change date resin change date Pre - filter or dosing pot service record (if fitted) Original installation date cartridge change date cartridge change date cartridge change date cartridge change date cartridge change date cartridge change date...
