EDDYTHERM operating manual
EDDYTHERM operating manual
Dear customer,
Thank you for choosing a PRÜFTECHNIK product. We are convinced you will be happy
with your decision. If you have any suggestions for improvement – regarding this
product or manual – please drop us a line.
1
PRÜFTECHNIK Alignment Systems GmbH
Freisinger Str. 34
85737 Ismaning
Germany
Tel
+49 89 99616-0
Fax: +49 89 99616-100
info@pruftechnik.com
www.pruftechnik.com
Edition January 2011
Order number ALI 9.392.G
Advertisement
Table of Contents
Summary of Contents for PRÜFTECHNIK EDDYTHERM
- Page 1 EDDYTHERM operating manual EDDYTHERM operating manual Dear customer, Thank you for choosing a PRÜFTECHNIK product. We are convinced you will be happy with your decision. If you have any suggestions for improvement – regarding this product or manual – please drop us a line.
- Page 2 EDDYTHERM operating manual This page intentionally left blank...
-
Page 3: Table Of Contents
EDDYTHERM 1x / EDDYTHERM 1-6 ........ - Page 4 EDDYTHERM operating manual This page intentionally left blank...
-
Page 5: Preface
EDDYTHERM operating manual Preface Congratulations on your decision to purchase the EDDYTHERM induction heater. PRÜFTECHNIK has been developing and distributing induction heaters for more than 25 years. On the basis of this extensive experience, PRÜFTECHNIK offers induction heating technology for a broad spectrum of components: roller bearings, bushings, couplings, rolls, gear wheels, etc. - Page 6 EDDYTHERM operating manual This page intentionally left blank...
-
Page 7: Safety Precautions And Operating Notes
Intended use EDDYTHERM is only intended for use as a heating device in industrial applications. It is designed for the inductive heating of components, such as ball bearings, for shrink fitting. The device and its accessories should only be operated by personnel trained in their use. -
Page 8: Safety Precautions
EDDYTHERM 1x and EDDYTHERM 1-6 have the protection class IP22 (protected against penetration by objects with a diameter greater than 12.5 mm, protection against dripping water). EDDYTHERM 4x has the protection class IP20 (protected against penetration by objects with a diameter greater than 12.5 mm, no protection against water). - Page 9 The equipment may only be operated and serviced by trained personnel. The operating instructions are an integral part of EDDYTHERM and must be always be legible, complete The operating instructions are an integral part of EDDYTHERM and must be always be legible, complete and available to anyone working with the device.
-
Page 10: Operating Notes
Storage and transport can take place at a relative humidity of up to 90% and at any altitude. Always use the original packaging when transporting the equipment. Type label The type label is located on the lower left side of the EDDYTHERM 4X unit (see illustration on page 12) or on the underside of the EDDYTHERM Ix and I-6 units. Type Ser.Nr. -
Page 11: Eddytherm 1X / Eddytherm 1-6
EDDYTHERM operating manual EDDYTHERM 1x / EDDYTHERM 1-6 Features at a glance User-oriented operating modes and displays › Temperature selection › Time selection › Automatic demagnetization after every heating cycle › Reduced-power heating option in 20% steps (100%, 80%, 60%, 40%, 20%) ›... -
Page 12: Eddytherm 4X
EDDYTHERM operating manual EDDYTHERM 4x Features at a glance User-oriented operating modes and displays › Temperature selection › Time selection › Automatic demagnetization after every heating cycle › Reduced-power heating option in 20% steps (100%, 80%, 60%, 40%, 20%) › Digital display of preset and measured values ›... -
Page 13: Eddytherm Control Panel
EDDYTHERM operating manual EDDYTHERM control panel Digital display Reduced-power Manual heating option demagnetization Operating modes Indicator LED Temperature/time adjustment key Indicator LED Brief description of operating modes and functions Temperature hold The workpiece is heated to the set temperature and held at that temperature until it is needed. It is automatically demagnetized before it is removed. -
Page 14: Starting Eddytherm
EDDYTHERM operating manual Starting EDDYTHERM EDDYTHERM 4x cable holder EDDYTHERM 4x is provided with a bracket upon which excess power cable may be hung to avoid damage or the danger of tripping. Setup Simply plug the heater into the power socket. The indicator LED for the “temperature shutoff” operating mode lights up. -
Page 15: Mounting The Workpiece
EDDYTHERM operating manual Mounting the workpiece To achieve the best possible efficiency, always choose the largest possible crossbar. This is the only way to guarantee that the workpiece will be heated rapidly. Slide the workpiece onto the crossbar and then place the crossbar onto the columns with the unpainted side facing down. - Page 16 EDDYTHERM operating manual Multiple identical workpieces Multiple workpieces can be heated together if they are identical, i.e., have the same weight and the same dimensions. Demagnetization of tools Mount the demagnetization bar (optional) as shown in the figure below. Press the demagnetization key and hold the tool in the gap of the demagnetization bar.
-
Page 17: Eddytherm 4X Swivel Crossbar
Bearing size The powerful EDDYTHERM 4x can heat workpieces or roller bearings weighing in excess of 200 kg in a short period of time (example: bearing 23088, 180 kg/396 lb, heated from 20°C/68°F to 100°C/212°C in approx. 8 minutes). - Page 18 EDDYTHERM operating manual Bearings with brass or bronze cages When bearings with brass or bronze cages are to be heated, care must be taken to ensure that the cage does not heat faster than the inner bearing ring. This could cause the lubrication contained in the bearing pockets to become overheated, which in turn could, in extreme cases, lead to overheating of the rolling elements themselves.
-
Page 19: Temperature Probe
EDDYTHERM operating manual Temperature probe The EDDYTHERM can be operated with automatic temperature detection using two different types of temperature probes. Magnetic probe This temperature probe [ETH 7305] is equipped with a powerful permanent magnet that attaches itself to any ferromagnetic material. - Page 20 The connector of the temperature probe is plugged into the connector next to the keypad (or to the right beneath the control panel in the 4x), and is locked with the threaded bushing. The EDDYTHERM recognizes the connected probe type and automatically limits the temperature programming to the highest allowable value in each case.
-
Page 21: Description Of Operating Modes And Functions
EDDYTHERM operating manual Description of operating modes and functions The EDDYTHERM offers three different operating modes to accommodate a wide range of user requirements, making it suitable for nearly any inductive heating task. Three operating modes 1. Temperature selection with automatic shutoff Set the desired temperature using the arrow keys. -
Page 22: Temperature Shutoff
A buzzer sounds to signal completion of the heating cycle. Step-by-step instructions: 1. Mount the workpiece on the EDDYTHERM. 2. Attach the temperature probe to the upper side of the workpiece. 3. Press the “temperature shutoff“ key. The associated indicator LED lights up. -
Page 23: Temperature Hold
It is automatically demagnetized before it is removed. Step-by-step instructions: 1. Mount the workpiece on the EDDYTHERM. 2. Attach the temperature probe to the upper side of the workpiece. 3. Press the “temperature hold“ key. The associated indicator LED lights up. -
Page 24: Timed Shutoff
Step-by-step instructions: 1. Mount the workpiece on the EDDYTHERM. 2. If the workpiece temperature is to be checked during heating, mount the temperature probe on the upper side of the workpiece. -
Page 25: Demagnetization
EDDYTHERM operating manual Demagnetization EDDYTHERM is equipped with a demagnetization circuit that allows demagnetization of ring-shaped workpieces independent of the heating process. Step-by-step instructions: 1. The ring-shaped workpiece is mounted on the swivel crossbar or regular crossbar (optional). 2. By pressing the “demagnetization” key, you can start the demagnetization process without first heating the workpiece. -
Page 26: Reduced-Power Heating Option
EDDYTHERM operating manual Reduced-power heating option In some special instances it may be necessary to heat a bearing slowly (for example, in bearings with a brass cage, where the brass cage heats up faster than the bearing). The reduced-power heating option slows down the heating process to allow all bearing components to heat evenly. -
Page 27: Faults And Error Messages
EDDYTHERM operating manual Faults and error messages EDDYTHERM is equipped with an overload protection (automatic fault detection unit) to prevent damage to the device or to the roller bearings being heated. Error messages Appears if a temperature probe is not connected in the “temperature hold” or “temperature shutoff”... -
Page 28: Troubleshooting
EDDYTHERM operating manual Troubleshooting Indicator LED does not light up and there is no display The connector is not plugged in Remedy: Plug the power cord into the power socket or check whether the power socket is energized. The micro fuse is blown Remedy: Contact your PRÜFTECHNIK representative. -
Page 29: Crossbars
EDDYTHERM is delivered with crossbars in a variety of sizes. The crossbars consist of thin, laminated sheets. Do not use them as a hammer or lever. Always mount the crossbars on EDDYTHERM so that their laminates are oriented vertically (with the unpainted side facing down); see the figure below. -
Page 30: Technical Data
EDDYTHERM operating manual Technical data Version EDDYTHERM EDDYTHERM EDDYTHERM EDDYTHERM EDDYTHERM EDDYTHERM EDDYTHERM 1-x Table-top 1-x Table-top 1-6 Table-top 1-6 Table-top 1-6 Table-top 1-6 Table-top 1-6 Table-top unit unit unit unit unit unit unit Type (package) ETH 17.110 ETH 17.100 ETH 17.500... -
Page 31: Index
EDDYTHERM operating manual Index Accessories 29 Safety precautions 8 Faults 27 Altitude 10 Scope of delivery 29 Features at a glance Automatic shutoff 21 Setup 14 EDDYTHERM 1-6 11 Starting EDDYTHERM 14 disabling 27 EDDYTHERM 1x 11 Storage 10 EDDYTHERM 4x 12... - Page 32 EDDYTHERM operating manual Visit our Internet homepage for information on new products, accessories and technical applications. www.pruftechnik.com EDDYTHERM ® is a registered trademark of PRÜFTECHNIK Dieter Busch AG. No copying or reproduction of this information, in any form whatsoever, may be undertaken without express written permission of PRÜFTECHNIK Alignment Systems GmbH. The information contained in this leaflet is subject to change without further notice due to the PRÜFTECHNIK policy of continuous product development.
