Goliath User Manual
v.0.8.0
Thanks for choosing the Goliath as your new MIDI controller. The Goliath will bring you
new functionalities and give you more control over your MIDI devices.
What follows is a description of how to connect the Goliath to your machines, set it up
and use it.
Overview:
The Goliath is a small battery powered MIDI device that gives you the ability to control
more than one MIDI CC at a time, randomize the parameters, generate random notes
sequences and last but not least: have fun!
Power and connections:
The Goliath requires a 9V DC battery to operate. This is placed inside the controller by
removing the bottom part of the enclosure, unscrewing the four screws at the corners.
To connect the Goliath, simply plug a MIDI cable from the MIDI OUT of a device of your
choice (this can also be a DAW) to the MIDI IN of the Goliath. Connect a MIDI cable
from the MIDI OUT of the Goliath to the device you want to control.
Incoming MIDI messages can be merged with the MIDI data generated by the Goliath,
this option can be enabled or disabled in the early startup of the controller.
Advertisement
Table of Contents
Summary of Contents for Gibbon Goliath
- Page 1 To connect the Goliath, simply plug a MIDI cable from the MIDI OUT of a device of your choice (this can also be a DAW) to the MIDI IN of the Goliath. Connect a MIDI cable from the MIDI OUT of the Goliath to the device you want to control.
- Page 2 Bunches: A bunch is a set of MIDI CCs stored in the internal memory of the Goliath. There are 3 bunches in total, each bunch can contain up to 16 MIDI CCs. Independent settings for the Random Notes Generator are also available for each bunch.
- Page 3 Each randomization will also change the reference value of the encoder. CTRAL Mode: This is the mode in which the Goliath starts when switched on. In this mode, turning the rotary encoder will send MIDI CC values for the parameters stored in the selected bunch according to the reference value of the encoder.
- Page 4 Once the firmware has been fully loaded, the controller will reset. To erase the current firmware from the Goliath, press [F], the red LED will turn on and off briefly meaning the entire firmware of the Goliath has been erased, the data stored in the internal memory won't be affected.
- Page 5 There is no need to backup the firmware of the Goliath when used for the first time as an initial backup has been already performed. Never switch off the Goliath whilst one of the above actions is taking place as this...
- Page 6 Multi MIDI Learn (MML): - hold [F] and press [A] to exit MML - hold [F] and send MIDI CC to Goliath to remove a MIDI CC from the current bunch in Random Note Generator (RNG): - press [A] to change clock division. there are 6 different clock divisions available - press [B] to change scale.
- Page 7 www.gibbondigital.com 2017...
