Summary of Contents for MrCool SMART CONTROLLER
- Page 1 SMART CONTROLLER Control Your Minisplit From Anywhere...
- Page 2 UNPACKING & PLUGGING IN - INSTALLATION OF SMART CONTROLLER Step 1: Power off your AC from the mains and open the front panel of your air conditioner. Step 2: Inside the front panel, you will find a docking station as...
- Page 3 UNPACKING & PLUGGING IN - INSTALLATION OF SMART CONTROLLER (CONT’D) Step 3: Open the MRCOOL Smart Controller box and take out the MRCOOL Smart Controller. Step 4: The Smart Controller has two sides, Side A & Side B.
- Page 4 UNPACKING & PLUGGING IN - INSTALLATION OF SMART CONTROLLER (CONT’D) Step 5: Insert the MRCOOL Smart Controller with side A front facing into the docking station. Step 6: Close the front panel of your MRCOOL air conditioner. You’re done with the installation. Please power on your...
- Page 5 STEP 1A: PRIOR TO APP INSTALLATION Your MRCOOL AC • Make sure your MRCOOL Smart Controller is installed inside the front panel of your AC as described in the previous section. • Make sure that your MRCOOL air conditioner is powered ON.
- Page 6 STEP 2A: APP INSTALLATION SmartHVAC App • Go to the App Store / Play Store. • In ‘search’ section type ‘SmartHVAC’. • Once ‘SmartHVAC’ App is displayed, tap the ‘GET’ button. • Open the App after installation is complete. STEP 2B: LOGIN / REGISTER Login Screen •...
- Page 7 STEP 3A: REGISTRATION - iOS USERS Note: Registration process is meant to connect the MRCOOL Smart Controller to your home Wi-Fi network through the ‘SmartHVAC’ App. Step 1: After successful login, you are at the Home screen. Step 2: Tap the ‘+‘ button as shown in the red circle.
- Page 8 STEP 3A: REGISTRATION - iOS USERS(CONT’D) Step 3: Go to your phone’s Wi-Fi settings. Step 4: Connect your phone to MRCOOL Smart Controller Wi-Fi (SmartHVAC_BI03_xxxxxx). Note: If you can not find a Wi-Fi that starts with SmartHVAC_BI03_xxxxxx, Power off the AC...
- Page 9 STEP 3A: REGISTRATION - iOS USERS(CONT’D) Step 6: Your phone will show the list of available Wi-Fi networks. Step 7: Select your Wi-Fi network from the list (there should be No captive portal or port blocking on your selected network). Step 8: Enter the password of your Wi-Fi network and tap the ‘Connect’...
- Page 10 STEP 3A: REGISTRATION - iOS USERS(CONT’D) Step 9: Customize your device with a name of your choice (for example, Bedroom, Lounge, Office, etc.) and tap on ‘Done’. Step 10: If the circle around AC icon is not green please refresh the home screen by swiping downwards (Pull-to-refresh).
- Page 11 STEP 3B: REGISTRATION - ANDROID USERS Note: Registration process is meant to connect the MRCOOL Smart Controller to your home Wi-Fi network through the ‘SmartHVAC’ App. Step 1: After successful login, you are at the Home screen. Step 2: Tap the ‘+’ button as shown in the red circle.
- Page 12 STEP 3B: REGISTRATION - ANDROID USERS (CONT’D) Step 3: Tap the ‘Wi-Fi Settings’ button as shown in the red border. Step 4: Connect your phone to MRCOOL Smart Controller Wi-Fi (SmartHVAC_BI03_xxxxxx). Note: If you can not find a Wi-Fi that starts...
- Page 13 STEP 3B: REGISTRATION - ANDROID USERS (CONT’D) Step 6: Select your Wi-Fi from the drop down list (there should be No captive portal or port blocking Enter the Password of your on your selected network). Wi-Fi Network Step 7: Enter the password of your Wi-Fi network and tap the ‘Connect’...
- Page 14 STEP 3B: REGISTRATION - ANDROID USERS (CONT’D) Step 8: Customize your device with a name of your choice (for example, Bedroom, Lounge, Office, etc.) and tap on ‘Done’. Step 9: If the circle around AC icon is not green please refresh the home screen by swiping downwards (Pull-to-refresh).
-
Page 15: Your Home Screen
YOUR HOME SCREEN Your home screen shows the real time status of all your MRCOOL Devices. A registered MRCOOL Device can show either of the 3 status, outlined in circles: 1 - Green - Device is online. You’re good to go! 2 - Red - Device is offline (try following options). - Page 16 CONTROL SCREEN - ENJOY THE UNLIMITED FUNCTIONALITIES Modes Temperature Control Set Point Temperature Room Temperature Power Button Swing Position Fan Speed Timeline Control eSaver History...
- Page 17 CONTROL SCREEN - ENJOY THE UNLIMITED FUNCTIONALITIES Tap on wrench for more op�ons MRCOOL Smart Controller works with Amazon Alexa & the Google Assistant Note: User manual may be subject to change with �me. For latest version, please visit: www.mrcool.com...
- Page 18 TROUBLESHOOTING: CHANGING WI-FI NETWORK OF SMART CONTROLLER Case 1: MRCOOL Smart Controller & mobile are on same Wi-Fi network - Tap on wrench symbol to enter device settings. Tap on ‘Change Wi-Fi’ button. List of available networks will appear. Enter password of selected network. New settings are done.
- Page 19 6. WARRANTY CONDITIONS; HOW TO GET SERVICE IF YOU WANT TO CLAIM UNDER THIS LIMITED WARRANTY Before being able to claim under this Limited Warranty, the owner of the Product must (a) notify MRCOOL. of the intention to claim by visiting our website during the Warranty Period and providing a description of the alleged failure, and (b) comply with MRCOOL.’s return shipping instructions.
- Page 20 COMPUTER, MOBILE DEVICE, AND ALL OTHER ITEMS AND PETS IN YOUR HOME, RESULTING FROM YOUR USE OF THE PRODUCT INFORMATION, SERVICES, OR PRODUCT. PRODUCT INFORMATION PROVIDED IS NOT INTENDED AS A SUBSTITUTE FOR DIRECT MEANS OF OBTAINING THE INFORMATION. IN ADDITION TO THE ABOVE, IN NO EVENT WILL MRCOOL BE LIABLE FOR ANY CONSEQUENTIAL, INCIDENTAL, EXEMPLARY, ACCIDENTAL, OR SPECIAL DAMAGES, INCLUDING ANY DAMAGES ARISING DUE TO THE USAGE OF PRODUCT OR PRODUCT PERIPHERALS.
Need help?
Do you have a question about the SMART CONTROLLER and is the answer not in the manual?
Questions and answers
Where do I install smart controller on 5th gen Mr cool mini split
The Smart Controller on a 5th Gen MRCOOL mini split should be installed inside the front panel of the air conditioner. Open the front panel, locate the docking station, and insert the Smart Controller with Side A facing front into the docking station. Then close the front panel and power on the unit from the mains.
This answer is automatically generated
My two ezpros have no docking station - i cant find any place to plug the USB sticks in?
To connect USB sticks to the MrCool controller without a docking station, slide the USB dongle directly into the open port on the unit. The port is visible and accessible for direct connection, even if your setup differs slightly from examples shown.
