Summary of Contents for Kleenmaid BSC4530
- Page 1 Instructions for use and warranty details Beverage Serving Cabinet Model No.: BSC4530...
- Page 2 Once installation is complete, please read this instruction manual carefully and get to know the controls and the features of your new Kleenmaid appliance. These simple instructions will enable you to achieve excellent results from the very first time you use it.
-
Page 3: Table Of Contents
Kleenmaid Warranty ........ -
Page 4: Wine / Beverage Preservation Technology Warnings
Wine / Beverage Preservation Technology Before using this beverage serving cabinet, please read and follow all safety rules and operating instructions. WARNING Warranty applies to the Beverage Serving Cabinet only and not to the content of the Beverage Serving Cabinet. The appliance is not covered by the warranty if it is being used for any purpose other than that for which it was specifically designed. - Page 5 R600a Refrigerant WARNINGS: For your safety observe the following recommendations. This appliance contains a small quantity of R600a refrigerant which is environmentally friendly, but flammable. It does not damage the ozone layer, nor does it increase the greenhouse effect. ...
- Page 6 Allow 24 hours before switching on the beverage serving cabinet. During this time we recommend that you leave the door open to clear any residual odours. Important: BSC4530 is for integrated or built in use only. Recommendations: The location you have selected for your Beverage Serving Cabinet should: - be unencumbered and well ventilated;...
-
Page 7: Installation Of Beverage Serving Cabinet
Leveling your Beverage Serving Cabinet: The base of the cabinet in which the Beverage Serving Cabinet is installed must be level so the BSC4530 is level BEFORE loading wine. GENERAL INSTRUCTIONS 1.Built in Beverage Serving Cabinets are front venting but are not designed to be fully integrated behind a joinery door. -
Page 8: Installation Drawings
Note: The appliance must be positioned so that the plug is accessible after installation. DIMENSIONAL DRAWINGS: As BSC4530 is a built-in model inside a cabinet, the cabinet should have good ventilation space and no back panel, otherwise it will affect the functioning of the cabinet. (Installation... - Page 9 INSTALLATION DRAWINGS...
- Page 10 OPENING ANGLE...
-
Page 11: Installation Instructions
Installation Instructions: Fig. 3 Fig. 1 Fig. 2 1. Place the Beverage Serving Cabinet into the cabinet, then adjust the beverage serving cabinet to make it steady. Open the door, take out the fixing plate (1 pcs), inner Hexagon Screws ((2 pcs), inner Hexagon Screwdriver (1 pcs), and self-tapping screws (3 pcs) from the accessory bag. -
Page 12: I Nstructions For Left Hinged Door Installation
INSTRUCTION FOR LEFT HINGED DOOR INSTALLATION BSC4530 uses a replacement door kit for changing from the default right hand hinge to a left hand hinge. The Hinge Reversing Kit contains a complete new door WITHOUT a handle, which will be obtained from the original door. The original door should be stored safely in case the hinge side is to be reversed again in the future. - Page 13 2. Align and install the upper and lower hinges to the hinge holes (picture FIG.C, FIG.D, FIG.E, and FIG.F) FIG.C FIG.D FIG.E FIG.F 3. Install door to the hinges (picture FIG.G , FIG.H, FIG.I) FIG.G FIG.H FIG.I...
-
Page 14: Adjustable Timber Shelving
4. Cover the right hinge holes with decorative nails (picture FIG.J , FIG.K), complete the installation. FIG.K FIG.J ADJUSTABLE WOODEN SHELVES Adjusting & removing the shelves For easy access to the storage content, you must pull the shelf approximately 1/3 of its depth out of the rail compartment. -
Page 15: Switching On Your Beverage Serving Cabinet
SWITCHING ON YOUR BEVERAGE SERVING CABINET Plug in and switch on the Beverage Serving Cabinet by pressing the power button for 3 seconds. When you use the Beverage Serving Cabinet for the first time (or restart the Beverage Serving Cabinet after having it switched off for an extended period), there will be a few degrees variance between the temperature you have selected and the one indicated on the LED readout. - Page 16 - To facilitate air circulation DO NOT over load your Beverage Serving Cabinet or stack more than 1.5 rows of standard 0.75L bottles per shelf. - Avoid obstructing the internal fans (located inside on the back panel of the Beverage Serving Cabinet).
-
Page 17: Temperature Settings
TEMPERATURE SETTINGS Important: The LED displays by default the actual internal air temperature. In the event of a power failure the settings are stored so when power is restored operation will resume with the previous settings. It is important to understand that there is a difference between the air temperature inside the Beverage Serving Cabinet and the actual temperature of the wine. -
Page 18: Auto Lighting Function
③ Cycle Button： Each time the button is pressed the temperature inside will drop 1 ℃, until reduced to a minimum, and then return to the highest temperature. AUTO LIGHTNING FUNCTION This product is designed with auto lightning function (as default feature) , i.e.: Auto lighting on when door opened. -
Page 19: Replacing The Led Light Strip
REPLACING THE LED LIGHT STRIP 1. Take out the LED light strip together with the light cover by unscrewing the screw in the middle. screw Light cover 2. Unplug the LED light wire from the connector Connector 3. Take out the LED light strip from the light cover by unscrewing 2 screws on the strip Screw Screw 4. -
Page 20: Wine Serving Temperature Chart
WINE SERVING TEMPERATURE CHART All wines mature at the same temperature, which is a constant temperature set between 12ºC to 14ºC. The chart below is an indicative temperature chart to suggest the best temperature for drinking purposes. Champagne NV, Sparkling, Spumante 6ºC Dry White Semillon, Sauvignon Blanc 8ºC... -
Page 21: Defrosting/Condensation/Hygrometry/Ventilation
DEFROSTING/CONDENSATION/HYGROMETRY/VENTILATION Your Beverage Serving Cabinet is designed with “Auto-cycle” defrost system. During “Off-cycle” the refrigerated surfaces of the Beverage Serving Cabinet defrost automatically. Defrost water from the Beverage Serving Cabinet storage compartment drains automatically and part of it goes into a drainage container, which is located at the back of the Beverage Serving Cabinet next to the compressor. -
Page 22: Care And Cleaning
CARE AND CLEANING Always disconnect the appliance from the mains electrical supply before cleaning or performing maintenance. • To remove/replace the timber shelves follow the instructions on page 13. • Do not use abrasive products or detergents. After washing, rinse and dry thoroughly. •... -
Page 23: Trouble Shooting
TROUBLE SHOOTING Ensure that there is power to the electrical supply plug by connecting another electrical appliance to it. Check fuse, if any. Make sure that the door is closed properly. If your Beverage Serving Cabinet appears to be malfunctioning, unplug it and contact your after sales service. - Page 24 TROUBLE SHOOTING GUIDE Common problems may easily be solved, saving you the possible cost of a service call. Please read the instruction manual carefully and consult this trouble shooting guide chart. PROBLEM POSSIBLE CAUSE Beverage Not plugged in. Serving Cabinet The appliance is turned off.
-
Page 25: Specifications
Specifications: - Compressor operated: R600a - Rated voltage/frequency : 230V+10%/-6% 50/60Hz - Automatic defrost - Humidity : 65% RH +/-10% RH - Black outer and inner finish - Internal light - Triple layers glass door - Ambient operating temperature range SN ~ T (10-43 C） - Refrigerant quantity contained 18gm - UV filter door glass - Glass door panes space filled with Argon to improve insulation and prevent condensation... -
Page 26: Kleenmaid Warranty
The benefits given to you under this Kleenmaid Warranty are in addition to other rights and remedies to which you may be entitled under the Australian Consumer Law in relation to the Product to which this Kleenmaid Warranty relates. Subject to the conditions below, the Product is warranted by Kleenmaid and/or its agents to be free from defects in materials and workmanship for the Warranty Period for normal Domestic Use. - Page 27 13. Kleenmaid accepts no liability for items that are lost, damaged, or stolen as a result of freight, transport or storage. If you are required to transport the Product to an authorised service centre, you must ensure that it is securely packed and insured.
- Page 28 Other products available in the Kleenmaid range of appliances Washing machines Clothes dryers Dishwashers Ovens Cooktops Steam ovens Microwave ovens Built in espresso coffee machines Rangehoods Freestanding ovens Refrigerators & Freezers Beverage Serving Cabinets Water Dispensers Vacuum Cleaners Compass Capital Services Pty Limited...
