Summary of Contents for Alberen iTAKSI M12
- Page 1 M12 TAXIMETER USER GUIDE This document provides information to assist in the users. Alberen Electronics Limited reserve the right to change the specification of its products without notice. If any further information is required, please contact your local dealer!
-
Page 2: Table Of Contents
8. DISPLAY LAST FARE, METER MEASUREMENT AND SPEED ……………………… 9. OPENING AND SELECTING THE TARIFF…………………………………………………… 9.1. TARIFF STRUCTURE…………………………………………………………………… 9.2. ENTERING EXTRA FEE………………………………………………………………… 10. CLOSING THE TARIFF…………………………………………………………………………….. 11. ENTERING MENU………………………………………………………………………………….. 11.1. MENU TABLE…………………………………………………………………………….. 12. CLOSING THE TAXIMETER……………………………………………………………………… 13. PRINTER CONNECTION………………………………………………………………………….. 14. ROOF LAMP CONNECTION…………………………………………………………………….. Alberen Electronics... -
Page 3: View
M12 Taximeter User Guide. © 2016 1. VIEW 1.1. FRONT VIEW 1.2. REAR VIEW Alberen Electronics... -
Page 4: Cables
M12 Taximeter User Guide. © 2016 2. CABLES 2.1. POWER CABLE 2.2. POWER CABLE WITH SECOND LAMP DRIVE 2.3. PRINTER CABLE Alberen Electronics... -
Page 5: Key Functions
Space (Ö) (Ü) Alberen Electronics... -
Page 6: Opening The Taximeter
It can be seen all revenue records of the 3 different drivers by admin. This records can be printed by admin. Also they can be erased by admin. Drivers and admin passwords can be changed by admin. Alberen Electronics... -
Page 7: Display Time And Date
“FOR HIRE position, time is shown in the upper screen as at the below. When button is pressed a second time. Lastly, when button is pressed a third time. If the taximeter doesn’t receive speed signal, the time-date information remains in the screen for 60 seconds. Alberen Electronics... -
Page 8: Display Last Fare, Meter Measurement And Speed
10. OPENING AND SELECTING THE TARIFF When it is pressed to button first time in the “FOR HIRE” position, the Tariff 1 is opened from the initial charge of Tariff 1 and the taximeter starts to calculate time and distance. Alberen Electronics... -
Page 9: Tariff Structure
Daily (D) ALL YEAR All Year, Specific time interval HH:MM-HH:MM Weekly (W) ALL YEAR All Year, Specific time of the week days HH:MM-HH:MM HH:MM-HH:MM HH:MM-HH:MM ……………………………………... Holiday Normal START DD/MM HH:MM Specific Date Interval for every year, start Alberen Electronics... - Page 10 Unit distance or unit distance fare (yard/100 or p/10) Unit time or unit time fare (second/64 or p/10) Tariffs which changed automatically as depends duration of the journey Tariff 1 Tariff 2 Tariff 3 ………………….. Tariff 8 Alberen Electronics...
-
Page 11: Entering Extra Fee
Unit distance or unit distance fare(yard/100 or p/10) Unit time or unit time fare (second/64 or p/10) 10.2. ENTERING EXTRA FEE While the tariff is open, the extra fee is entered to upper screen by pressing extra button repeatedly. Alberen Electronics... -
Page 12: Closing The Tariff
It can be reached to the menu by pressing button in the “FOR HIRE” position. All information (as counters, setting parameters, etc) are shown in menu. Structure of the menu is shown in menu table at the below. Alberen Electronics... -
Page 13: Menu Table
Sample limit meter distance or unit distance fare values are value for auto distance tariffs shown at the lower display. Print Information All tariff information (tariff 1,2,3, ) can be Alberen Electronics... -
Page 14: Closing The Taximeter
While the taximeter is closed, when pressed any button, it passes to driver selection menu 14. PRINTER CONNECTION The Printer Cable is connected to Printer and printer connector of the taximeter. The printer gets power from the taximeter via printer cable. Printer Cable Alberen Electronics... -
Page 15: Roof Lamp Connection
If a second roof lamb will be connected to taximeter; then “Power Cable with Second Lamp Drive” cable should be used as power cable. Second lamb can be used for “STOPPED” or a different position. The white cable of the power cable is connected to the positive pole of the second roof lamp. Alberen Electronics...
