Summary of Contents for One Arcade YY-K253
-
Page 2: Table Of Contents
CONTENT Product Profile………………………………………… 2 Spare Parts List…………………………………………3 User Instructions………………………………………3 All Devices Details…………………………………4-5 Game Setting………………………………………6-11 Usual Maintenance and Solutions……………………12 Wire Diagram…………………………………………13... -
Page 3: Product Profile
Product Profile Size：1070*2325*1972mm Weight：300kg Input Voltage：AC 220V Power Capacity：300W light decoration loud speaker loud speaker outer decoration LED light displayer seat LED light start button coin acceptor blue LED light Seat decoration Summary： This game is in beautiful appearance and good design, 42 inch high clear displayer and high technology. -
Page 4: Spare Parts List
Spare Parts List Parts Name Remarks User Manual Power cable keys User Instructions 1. Insert enough right coin； 2. Press start button to start the game； 3. In the game, move the gun to shoot zombies. 4. This game has 6 stages, after you pass the first 5 stages, then you can start 6 stage. -
Page 5: All Devices Details
All Devices Details 1. Upper light decoration： 2.gun decoration： Gun trigger Protection net 2. Control panel： start button LED light coin ticket dispenser acceptor... - Page 6 5. Under control panel, you open the door, then you can see these below devices： upper motor ball tunnel under motor ticket box coin box power IO board supply 6. Cabinet backside devices： host box speaker amplifier...
-
Page 7: Game Setting
Game Settings 1. Power on this game machine, after its auto testing，the game starts. The progress line shows loading progress: 2. After auto loading finish, it will go to LOGO page, please insert coin to play； 3. Press Test button to enter game setting menu, then you can see setting options as below: a )“game volume”：... - Page 8 h )“Present Coins: present coins, can be cleared. I )“1P gun adjust”：can adjust 1P gun’s shoot cursor. j )“2P gun adjust”：can adjust 2P gun’s shoot cursor K )“IO test”：go to hardware test page. l )“return to factory default”：when game setting in wrong, choose this option to initial factory default.
- Page 9 Press the service button to exit Please move the 1P gun at the center of the circle, press the start button to determine Too large to offset, please re shoot b )Adjust finishes test: After finish adjust testing, it will enter curser micro adjust automatically. This adjust option can test the gun is adjusted accurately or not.
- Page 10 6. Choose stage：When game enter the stage map, choose any unlocked stage by shooting it. 7. All 6 stages scenes are as below： garden stage street stage...
- Page 11 pyramid stage factory stage stage cemetery 8.Game Props: speeder prop: increase shooting speed in limited time. pea shooter: shoot zombies in queue； freeze pea shooter ：continuously shoot zombies in queue. Though it is lower aggressively, but can freeze zombies. cherry bomb：put cherry in front of player for protection, when zombies come,it will bomb and kill a quantity of zombies.
- Page 12 water melon shooter: shoot zombies in queue. It is shooting in low speed, but can shoot a quantity of zombie, and very aggressive. 10.Alarm page：if attacked by zombie, the displayer is twinkling in red frame, as below: 11.Continue to play or not：when the blood line is almost finished, it will show you tips “YES or NO”...
-
Page 13: Usual Maintenance And Solutions
12.Scores page(You win or You lose), as below: 13.Game over page: Maintenance and Solutions Normal Problems Cause Solutions 1.reconnect it according to Power on the game, but the 1.VGA port in misconnection wire diagram displayer is off. 2.the power switch is closed 2. -
Page 14: Wire Diagram
1.switch off the game, confirm 1.maybe machine no body attack the game or The game stop suddenly attached by something or other other reasons, then restart the reasons. game. 1.mother board in problem 1.turn to engineer for help Coin acceptor don’t work 2 ．... - Page 15 Wire Diagram...
