- Page 1 INSTRUCTION AND MAINTENANCE MANUAL MODELS OCEAN INDUSTRIAL ALBORAN OCEAN INDUSTRIAL ALBORAN info@arionapools.com arionapools.com...
-
Page 2: General Contents
INSTRUCTION AND MAINTENANCE MANUAL MODELS OCEAN INDUSTRIAL ALBORAN GENERAL CONTENTS Page 3- Specifications Page 4- Technical data for the Ocean Industrial Page 5- Technical data for the Alboran Page 6- 1. Handling (packaging, storage, how to move them) Page 6- 2. Installation (Engine room) Page 7- 2. -
Page 3: Specifications
OCEAN INDUSTRIAL SPECIFICATIONS Filter for a public pool, manufactured to industrial standards, reinforced fiberglass tank. UV ray resistant. Fitted as standard with a pressure relief valve. • Filter bed: 1 metre. • Upper cap diameter of 400mm in reinforced fiberglass. •... - Page 4 OCEAN INDUSTRIAL Ø DIMENSIONS GRAVEL SAND MODEL CONNECTION FILTERING SURFACE SPEED FLOW (1-2mm) (0,4-0,8mm) (mm) m² m³/h/m² m³/h (Kg) (Kg) OC1050.20 1050 0,87 1755 1050 1100 OC1050.34 1050 0,87 30-40 26-34 1755 1050 1100 OC1050.50 1050 0,87 1755 1050 1100 OC1200.23 1200 1,13...
- Page 5 ALBORAN Ø MODEL CONNECTION FILTERING SURFACE FLOW DIMENSIONS (mm) SAND LOAD WEIGHT m² V=50m³/h (Kg) (Kg) ALBORAN 950 0,70 ALBORAN 1100 1100 0,96 47,5 1100 1325 ALBORAN 1200 1200 1,13 1200 1575 ALBORAN 1400 1400 1,54 1301 1400 1750 TECHNICAL DATA 0,6 -1,6 kg/cm²...
- Page 6 1. HANDLING 1.1. PACKAGING The filters are delivered on wooden pallets suited to the size of the filter, and in a vertical position as standard. They are wrapped in a protective film. 1.2. STORAGE If a filter is not going to be installed immediately, it must be kept in its original packaging and stored under cover, protected from the sun and inclement weather.
- Page 7 INSTRUCTION AND MAINTENANCE MANUAL 2.2. INSTALLATION OF VALVE MANIFOLDS Install the valve manifold before loading the filter with the filter aid. The valve manifold brackets will support the weight of the valves, the pipes and the water inside them, and will reduce the force that the filter connections will need to withstand.
-
Page 8: Operation
3. OPERATION Before opening or closing the valve manifolds, it is essential to always turn off the pump and ensure that there is no water flowing inside the pipes. 3.1. FILTRATION The valve manifolds must be placed in the following position: FILTRATION VALVE POSITION... - Page 9 INSTRUCTION AND MAINTENANCE MANUAL air is used to loosen and fluff up the sand bed, to achieve more efficient cleaning. This saves on the amount of water used during cleaning. 3.3. RINSE The valve manifolds must be placed in the following position: RINSE FROM PUMP VALVE...
- Page 10 3.5. REMOVING THE SAND FROM THE FILTER Empty the filter by opening the drain situated on the bottom of the filters. • Remove the upper cap to remove the sand. • One person should help to remove the sand from the filter from the inside. •...
-
Page 11: Important Considerations
INSTRUCTION AND MAINTENANCE MANUAL IMPORTANT CONSIDERATIONS Pressure filters must only be operated by qualified personnel. Operators must have received training in the tasks involved in operating the filter, and be informed of the dangers and harm that it can entail. Use a pressure gauge panel to control the filter pressure. - Page 12 info@arionapools.com Polígono Industrial Egiburuberri 13-1B 20100 Errenteria, Gipuzkoa, Spain arionapools.com...
