Hedstrom SATURN M08602 Quick Start Manual

SATURN - M08602
FOR CHILDREN AGED 3 TO 10 YEARS
SAFETY GUIDELINES
Not suitable for children under three years, contains small parts.
This equipment must be assembled and checked by an adult. Two adults may be required to assemble this product.
For family domestic use only. This product has not been designed for commercial use in play centers, nurseries etc.
Adult supervision is required at all times.
Only one child per seat at any one time.
The item is not designed for adults or for children weighing more than 45kg.
The total weight on the product at any one time must not exceed 145kg.
For outdoor use.
Check all nuts, bolts and fittings for tightness and tighten if required.
Check all coverings for bolts and sharp edges and replace when required.
Check swing seats, chain, ropes and other means of attachments if relevant to your product for evidence of deteriora-
tion. Replace when required in accordance with the manufacturers instructions if necessary.
Place the product on level surface at least 2 metres from any structure or obstruction such as a fence, garage, house,
wall, overhanging branches, laundry line or electrical wires.
The items MUST be anchored firmly into the ground.
DO NOT install the product over concrete, asphalt or any hard surface.
DO NOT orientate the product directly towards the sun.
Leave all fittings finger tight until assembly is complete, for ease of construction. Then tighten firmly.
Children should not wear cycle helmets whilst on this equipment.
Do not allow children to stand on any swing seats, glider seats or slide chutes relevant to your product.
Do not allow the children to jump or climb off any moving equipment.
Do not twist swing ropes or wrap them over the top bar.
Do not allow loose, hooded or baggy clothes to be worn as children can get trapped and may be unable to free
themselves.
Do not allow children to climb on parts of this equipment intended for this purpose.
Do not allow children to wander into the play area whilst the equipment is in use.
Do not allow children to slide head first down the chute, walk up the chute or jump or climb off the chute.
Gliders and swings must not exceed an angle of 60 degrees from the ground.
Regularly check the item for wear and damage, removing the item from use when necessary until replacement parts
are fitted.
Failure to assemble and maintain this item as per instruction may cause injury to the user.
Please keep the instructions in a safe place for future reference.
Made in China to European Standards.
Conforms to EN71
03.07 ISSUE 1
SWING PARTS LIST
1
top bar (x1)
3
"right-hand" type top leg (x2)
5
side stay bar (x2)
8 9
glider legs (x2) glider seat tubes (x2)
11 12
glider seat (x2) glider footrest (x2)
SLIDE PARTS LIST
17
18
19
20
21
22
chute side stay bar x1
23
24
25
2
"left-hand" type top leg (x2)
4
plain bottom leg (x3)
6
7
glider handle tubes (x2)
glider bracket (x1)
10
bottom leg (x1)
13 14
allen key (x1)
swing seat (x1) 16
28
33
chute support top bar x1
29
26
30
31
32
27
15
spanner (x1)
ground peg (x5)
