The SPYDAQ-1x00-HPR is a powered RF Signal Repeater. The repeater is used for
extending the range for standard spYdaq Transmitter, especially when objects
that restrict signal are involved.
The SPYDAQ-1x00-HPR is available in 3 model variants:
SPYDAQ-1000-HPR
SPYDAQ-1100-HPR
SPYDAQ-1200-HPR
The repeater contains an RF receiver and RF transmitter. The receiver (like the
standard SPYDAQ Base-Station) employs Antenna Diversity; using 2 antennas's
to listen for SPYDAQ transmitter messages and locking on to the highest signal
path.
The entire configuration for the repeater is done using simple DIP switches at the
rear of the product. These DIP switches will allow the user to receive and transmit
on any of the 4 available radio channels.
The repeater listens and repeats messages from any spYdaq device on the
selected RF channel. If you wish to ignore certain spYdaq transmitter device
addresses, the user can program the unit (via DIP switches) to ignore that
transmitter. This may be appropriate if one transmitter is very close to the base-
station already and it is not necessary for the repeater to duplicate the
transmission.
The repeater contains an internal Lithium-Ion rechargeable battery, this battery
will continue to power the repeater and continue normal operation in the event of
failure of the external power source. The life of the battery is dependant on the
number of transmitters on the system and the transmit power setting. Typically
the battery will provide normal operation of 1~2 days.
Note:
The repeater's internal Lithium-Ion battery will be disconnected via an internal
jumper link prior to leaving the factory. Before commissioning the repeater the
battery jumper link should be fitted. See section 5 in this manual.
SPYDAQ-1000-HPR
Reference: Provisional
Change Note: Provisional
Introduction
Model Variants
433MHz Version
868MHz Version
916MHz Version
