Summary of Contents for FTH Power X2-F Abyss

Page 1 User Manual Company：FTH Power Address：20801 Currier Road, City Of Industry, CA 91789 Phone: 844-978-2632 Email: support@fthpower.com...
Page 2: Safety Tips
User Manual Items included in your e-bike packaging: In order to ensure your safety and maximize your enjoyment from your new ride, we have outlined 1. FTHPower electric bicycle important topics in this manual for your review. 2. 2 battery chargers Content 3.
Page 3: Service Record
Service Record Model: Dealer: Serial Numbers: Purchase Date: Check for damage 6 Weeks/200km Frame & Fork Date: Rims Shop: Cables & connections Mechanic: Lubricate 6 Months Chain Date: Derailleur Shop: Seatpost Mechanic: Adjust and Tension 12 Months Spokes Date: Gears Shop: Seat Mechanic:...
Page 4: Handlebar And Stem
Assembly Instructions 1.Unpack Your electric bike is shipped 85% assembled. Follow these steps to get it ready and safe for your Carefully lift the electric bike out from the carton (two first ride. people recommended for this task). Cut the nylon zip ties with suitable scissors and remove the foam To Prepare protection from the bike.
Page 5 Assembly Instructions 3. Seat 4.Pedals Release the seat post clamp lever and set the seat Attach the pedals to the cranks, please note letter L post height to the position which is suitable for you to and R on the axel, L means Left pedal. Note: the comfortably reach the ground when you are sitting on pedals have opposing threads –...
Page 6 Warning treat your eBike like any bicycle you would want to Note: The LCD battery display bars will dip under full last well… keep it stored somewhere secure and away load (on hills, etc). This is normal as running voltage from the elements.
Page 7 Warning top up your battery whenever possible. Lithium Note: A battery left for more than 3 months at a low batteries actually prefer shallow discharge (the exact voltage may suffer cell damage. This will not be opposite of older types of batteries that have memory covered under your warranty.
Page 8: Safe Riding Recommendations
Safe Riding Recommendations Please observe traffic regulations, and don't lend your your bicycle is equipped with correctly positioned and securely bicycle to anyone who is unfamiliar with it. The bicycle can mounted reflectors, wear light-colored, reflective clothing and or legally only be used on the road by one person age 14 years or accessories (any reflective device or light source that moves will over.
Page 9: Pre-Ride Checklist
Safe Riding Recommendations Pre-ride Checklist c. Front wheel axle nuts 30-35N.M d. Seat angle clamp bolt 24N.M Please make sure the brake lever sequence is e. Crank axle nuts R:42N.M correct for your country before riding. In UK, NZ and L: 46N.M Australia the left brake lever is for rear brake and f.
Page 10: Maintenance And Adjustment
Maintenance & Adjustment 1. Gear Adjustment 2. Cleaning your electric bike Warm soapy water and a cloth can be used to clean Adjust the rear derailleur cable tension to align guide pulley with the centre of the cogs (setting this in gear 3 the frame of your bike, but care must be taken not to or 4 is easiest).
Page 11: Other Maintenance
Maintenance & Adjustment 4. Other Maintenance 5. Fork adjustment Your bicycle must be returned to your servicing dealer RST front fork GUIDE 26-ML has springs that can be or bicycle/motorcycle mechanic after one month or rebound and adjust. 200km of riding (which ever comes first) to re-tension 1.1 The front fork is the suspension fork.
Page 12: Main Specifications
Main Specifications FRAME 26"x457 A6061-T6 HUBS Quanta double sealed bearing, Alloy 13G×135×180×36H 135mm travel, through axle, rebound FORK and lockout adjustment. SPOKES Black Stainless. SHOCK Front suspension, rebound lockout. ALLOY 26"*4.0 13G36H with eyelets HEAD SET Integrated tapered. TIRE 26*4.0 INNOVA Alloy ALLOY Bar Bore:Φ31.8 HANDLE BAR SL-TX50-7R, TOURNEY RIGHT 7-SPEED...
Page 13 VLCD Display Panel 1. Speed display 10. Select the magnetic steel number of the speed Show current speed, unit: Km/h and mile/h, be sensor, default value is 1. switchable. 11. Speed unit option 2. Consumption indicator Switch speed unit from Km/h or Mil/h, fault is Four horizontal blocks show energy of battery (each Km/h.
Page 14: Button Definition
VLCD Display Panel Controls 2.2 Pedal Assist 1.Button Definition There are 4 levels of power assist (none, low, medium, high). Press this button to adjust the power assist from low to high. Default is medium assist. 2.3 Mode There are 4 levels of mode (odometer, trip distance, average speed, one way time).Press this button to adjust the mode.
Page 15 VLCD Display Panel Controls 3.2 Odograph (ODO) 3.4 Movement time(TIME)Required time for a single Under the condition of in odometer, press the mileage. three buttons simultaneously for 10s to reset ODO. Mileage time 3.5 Show diagnostic code Odometer Show diagnostic code .Easy to detect the failure. Once the controller encounters an error, the related 3.3 Average speed(AVG) code will occur on the speed bar of the panel.
Page 16 VLCD Display Panel Controls 4. Hidden function and show 4.1 Wheel diameter selection(d1) Use the button to enter the speed units To show the hidden function, you should press these interface, press button to switch amongst two buttons simultaneously for 3 seconds on 14-32 inch.
Page 17 VLCD Display Panel Controls 4.3 Speed units selection(km/h mil/h) 4.5 Top speed selection (SD) Use the button to enter the speed units interface, Use the button to enter the speed limit press button to switch between km/h and mil/h. selection, press buttons to switch Default is Km/h.
Page 18 VLCD Display Panel Controls 5. Failure code 4.7 Mode selection (M) Use the button to enter the mold submenu, According to the failure condition, the diagnosis codes press button to switch between Japan and will be displayed. The fault detection will be launched Europe.
Page 19 VLCD Display Panel Controls 6. Torque signal value display 7. Initial value for torque signal display Press buttons simultaneous for 10 seconds Under submenu “TE1”, press again, it shows initial under ODO menu, then only press to show “ODO”, torque value, which is for service inspection use only “TRIP”, “AVG”, “TIME”...
Page 20: Battery Instructions
Battery Instructions Charging your Battery Battery Removal You can charge the battery on or off the bike. The To remove the battery, insert the key into the lock on charging port is located on the right of battery. Lift the the front left side of battery, turn the key, slide the rubber cap and plug in your charger.
Page 21 Battery Instructions Battery Capacitance Display Connections On the top front of the battery is the capacitance All ebike components (brake sensors, controller, etc) display button. When pushed in, the LED lights below on the FTH bikes have isolating marine-rated plugs, will glow for 4 seconds, indicating the battery output so, should you damage a component, replacement is power is live.
Page 22: Warranty
Warranty Limited Remedy: All FTHPower Electric Bicycles come with an 12-month warranty against manufacturing defects in materials or workmanship on its frame, battery, For any parts under warranty that need to be replaced within the 12- controller, and motor assembly. month time frame, FTHPower will cover the cost of freight to the customer.
