  • Page 1 To Buy: Visit www.sylvane.com or call (800) 934-9194 For Product Support: Contact Haverhill at 770-224-7069 Use and Care Guide Dehumidifier Model: HD5020E & HD7020E...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS Table of Contents ��������������������������������������������������������������������������������������������������������2 Product Components ��������������������������������������������������������������������������������������������������3 Important Safety Instructions �������������������������������������������������������������������������������������4 Safety Precautions �������������������������������������������������������������������������������������������������4 Important Safeguards ��������������������������������������������������������������������������������������������5 Specifications ��������������������������������������������������������������������������������������������������������������6 Before Operation ���������������������������������������������������������������������������������������������������������7 Operating Instructions ������������������������������������������������������������������������������������������������8 Control Panel ���������������������������������������������������������������������������������������������������������8 Features ����������������������������������������������������������������������������������������������������������������9 Using the Dehumidifier �����������������������������������������������������������������������������������������9 Water Drainage �������������������������������������������������������������������������������������������������� 10 Care and Maintenance ��������������������������������������������������������������������������������������������...
  • Page 3: Product Components

    PRODUCT COMPONENTS Control Panel Indicator Light Front Grille Water Bucket Casters Front Side Air Filter Power Plug Back Side...
  • Page 4: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS SAFETY PRECAUTIONS WARNING: To prevent injury to the user or other people and property damage, the following instructions must be followed. Incorrect operation due to ignoring instructions may cause harm or damage� NEVER DO THIS: • DO NOT operate the dehumidifier in the presence of flammable substances or vapors •...
  • Page 5: Important Safeguards

    IMPORTANT SAFEGUARDS • The dehumidifier is not intended for use by young children or impaired people without supervision. • Young children should be supervised to ensure that they DO NOT play with the dehumidifier. • If the power cord is to be replaced, replacement work must be performed by authorized personnel only�...
  • Page 6: Specifications

    SPECIFICATIONS HD5020E HD7020E Capacity 50 Pints / 24 Hrs 70 Pints / 24 Hrs Voltage Rating 115 V AC, 60 Hz 115 V AC, 60 Hz Power Rating 540 Watts 740 Watts Product Dimensions 23.8” x 15.3” x 11.3” (H x W x D) 23.8”...
  • Page 7: Before Operation

    BEFORE OPERATION CHECK BEFORE OPERATION Before operation, please first check whether the float is properly placed. Below are the checking steps: 1� Hold the handles on both sides of the water bucket and pull it out following the arrow Figure A direction.
  • Page 8: Operating Instructions

    OPERATING INSTRUCTIONS CONTROL PANEL Figure C 1. Power Button Turn the dehumidifier on and off. 2. + / - Button Humidity level can be set within a range of 80% and 35% relative humidity in 5% increments or in Continuous operation. •...
  • Page 9: Features

    6. Continuous Button Press this button to set continuous dehumidify. NOTE: If Continuous operation is selected, the dehumidifier will operate continuously at its maximum dehumidification settings. The unit must be attached to a hose to drain when the water bucket is full� 7.
  • Page 10: Water Drainage

    • DO NOT connect the dehumidifier Figure D to an outlet with multiple sockets, Correct Wrong which is also being used for other electrical appliances� • Select a suitable location, making Above Below sure you have easy access to an 41°F (5°C) 41°F (5°C) electrical outlet�...
  • Page 11 3� Attach a water hose (not supplied) Figure H on the connector and lead it to the floor drain. (Figure I) 4� Replace the water bucket in the unit� The water bucket must be securely placed for the unit to operate.
  • Page 12: Care And Maintenance

    CARE AND MAINTENANCE GRILLE AND HOUSING CLEANING CAUTION: Turn the unit off and remove power supply cord from the wall outlet before cleaning the unit� • Use water and a mild detergent� DO NOT use bleach or abrasives� • DO NOT splash water directly onto the main unit� Doing so may cause an electrical shock, cause the insulation to deteriorate, or cause the unit to rust.
  • Page 13: Troubleshooting

    TROUBLESHOOTING TROUBLESHOOTING Problem Possible Causes Solution Unit does not Water bucket may be full Drain the water� start Power supply cord may not be Connect the power supply cord connected properly� properly into a wall outlet� House fuse may be blown or circuit Contact a service technician and breaker may be tripped�...
  • Page 14: Malfunction Codes

    MALFUNCTION CODES Display Code Malfunction Unit’s No� Possible Causes Name Condition Display Window • Ambient temperature sensor is loose or is poorly connected with the terminal of display board� • Some element of display board Ambient may have been put upside down Temperature and caused short circuit�...
  • Page 15: Warranty

    Any and all implied warranties including merchantability and fitness for a particular purpose are hereby limited to one year or the shortest period allowed by law� Haverhill is not liable for incidental or consequential damages and no representative or person is authorized to assume for us any other liability in connection with the sale of this product.
